Stanley Omnilock 45HOM Installation and operating instructions

Stanley Omnilock
a Product Group of Stanley Security Solutions, Inc.
45HOM Extreme Weatherized Mortise Locks
This addendum begins at step 11 of Installation Instructions for Stanley
Omnilock 45HOM Mortise Locks T83312.
1 Insert the escutcheon standoffs into the predrilled holes.
2 Thread connecting cables, motor wire and grounding wire through the
door cable hole. Use screws and washers to attach the escutcheon from
the inside of the door. See Figure 1.
Note: Ensure that no wires are pinched when attaching the escutcheon to the
door.
3 Thread the connecting cables motor wire and grounding wire through the
module bracket wire inlet.
4 Attach the module bracket to the door with the proper mounting screws.
5 Connect the wires and batteries as shown in Figure 2.
6 Secure the module cover with the security screws provided. See Figure 3.
7 Continue with step 14 of the Installation Instructions for Stanley Omnilock
45HOM Mortise Locks T83312 to complete the installation.
Escutcheon mounting screws
Connecting cables Grounding
wire
Wire inlet
Module bracket
Figure 1 Inside circuit module
Figure 2 Wire connections to circuit module
10 Pin
Connector
Grounding
wire
12 Pin
Connector
Cover
grounding
wire
Wire inlet
Security
screws
Figure 3 Inside view of weatherized model
Installation Addendum for
Stanley Omnilock 45HOM
Extreme Weatherized Locks
T83317/Rev A 0000000 ER-7991-12 Jan 2010

To ensure accurate door preparation, use only factory-
printed templates. Do not use copies or facsimiles.
1/8 in
3mm
Horizontal centerline
of lock
Horizontal centerline
of lever
7/8 in
23 mm
3/8 in
10 mm
1/2 in
13 mm
3/16 in
5mm
Through hole
F
3/16 in
5mm
Through hole
C
H
B
Align to vertical centerline
Inside Door
F
D
D
J
K
1/8 in
3mm
H
1/8 in
3mm
1/8 in
3mm
J
1/8 in
3mm
J
1/8 in
3mm
J
3/4 in
19 mm
Hole Descriptions
BThumb turn (1)
CLever (1)
DTrim mounting (2)
F
J
Thumb turn mounting screws (2)
H
K
Weatherized module bolts (4)
Module bolt (2)
Cables
Through hole
TV model only
3/8 in
10 mm
Vertical centerline
of lever
TV model only
7 29/64 in
189 mm
