Steelcase Adjustable Keyboard and Mechanism User manual

Adjustable Keyboard and Mechanism
®
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©2000 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
Keyboard Replacement
Arm Assembly Replacement
Keyboard Adjustment Release Replacement
Cylinder Replacement
Page 1 of 4
939504211 Rev D

Page 2 of 4
939504211 Rev D
Keyboard Adjustment Release
Replacement
1. Remove screws and keyboard adjustment
release.
2. Install new keyboard adjustment release with 2
screws.
3. See cylinder replacement on Page 4 to
complete cable replacement.
Keyboard Replacement
1. Remove Keyboard and keyboard adjustment
release
.
2. Replace Keyboard and keyboard adjustment
release.
B
A
A. Context:
Others:
B. Context:
Others:
After May 10, 1996
After June 22, 1997
Before May 10, 1996
Before June 22, 1997

Page 3 of 4
939504211 Rev D
Arm Assembly Replacement
1. Remove retainer ring and pin.
2. Remove Screws and Arm Assembly and
Keyboard Adjustment Release.
3. Install Arm Assembly and Keyboard
Adjustment Release.
1.
2. 3.

Page 4 of 4
939504211 Rev D
Cylinder Replacement
1. Remove retainer ring and pin.
2. Turn cylinder and remove.
3. Turn replacement cylinder in until contact points just
meet.
4. Lightly grease pin and replace pin and retainer.
5. If the cable does not fully unlock the cylinder, allowing
keyboard to move freely, repeat step 1. Then turn the
cylinder in 1/2 turn. If actuator is not completely closed
when cable is fully activated, repeat Step 1. Then
turn the cylinder out 1/2 turn.
Evaluate and repeat this step if necessary.
6. Finger tighten cylinder nut.
12
6
6
Keyboard Unlocked Position
Keyboard Locked Position
34
Contact
Points
Completely
Closed
.625 .125
+
