OPERATOR / SERVICE MANUAL
Hausted®Pediatric Care Stretcher
Models 4160
(07/18/06) 069216

i
069216
A WORD FROM STERIS CORPORATION
©2006, STERIS Corporation. All rights reserved. Printed in U.S.A.
This manual contains important information on proper use and
maintenance of the Horizon Stretcher. All personnel involved in the
use and maintenance of this equipment must carefully review and
comply with the warnings, cautions and instructions contained in this
manual. These instructions are important to protect the health and
safety of personnel operating a Horizon Stretcher and should be
retained in a conveniently accessible area for quick reference.
Complete instructions for unpacking this unit are provided in
SECTION 2 of this manual.
STERIS carries a complete line of accessories for use with this
stretcher. A STERIS representative will gladly review these with you.
Indications for Use The Hausted®Pediatric Care Stretcher is designed for pediatric-age
patients transport, treatment and recovery.
Service Information A thorough preventive maintenance program is essential to safe and
proper unit operation. This manual contains maintenance schedules
and procedures which should be followed for satisfactory equipment
performance.
You are encouraged to contact STERIS concerning our
comprehensive Annual Maintenance Agreements. Under the terms
of these agreements, preventive maintenance, adjustments, and
replacement of worn parts are done on a scheduled basis to assure
equipment performance at peak capability and to help avoid
untimely or costly interruptions. STERIS maintains a global staff of
well equipped, factory-trained technicians to provide this service, as
well as expert repair services. Please contact your STERIS
representative for details.
Advisory A listing of the safety precautions to be observed when operating
and servicing this equipment can be found in SECTION 1 of this
manual. Do not operate or service the equipment until you have
become familiar with this information.
Any alteration of this equipment not authorized or performed by
STERIS Engineering Service which could affect its operation will void
the warranty; could violate national, state, and local regulations; and
could jeopardize your insurance coverage.

ii
069216
Manufactured by:
STERIS Corporation
2720 Gunter Park East
Montgomery, AL 36109 • USA
Equipment not suitable for use in the
presence of a flammable anesthetic
mixture with air or oxygen or nitrous oxide.
EC Authorized Representative
STERIS Ltd.
STERIS House
Jays Close
Viables
Basingstoke
Hampshire
RG22 4AX
STERIS Corporation,
Montgomery, Alabama is an
ISO 13485 certified facility.
The base language of this document is
ENGLISH.Anytranslationsmustbemade
from the base language document.

iii
Table of Contents Operator / Service Manual 069216
TABLE OF CONTENTS
Section
Number Description Page
1 Safety Precautions ........................................................................................................................1-1
2 Unpacking Instructions.................................................................................................................2-1
3 Operating Instructions..................................................................................................................3-1
3.1 Braking and Steering Operation ............................................................................................................3-1
3.1.1 Applying The Brakes....................................................................................................................3-1
3.1.2 Releasing The Brakes..................................................................................................................3-1
3.1.3 Applying The Steering Lock.........................................................................................................3-1
3.1.4 Releasing The Steering Lock.......................................................................................................3-2
3.2 Stretcher Top Height Adjustment...........................................................................................................3-2
3.2.1 Height Adjustment........................................................................................................................3-2
3.2.2 Lowering Litter Top ......................................................................................................................3-2
3.2.3 Trendelenburg Adjustment...........................................................................................................3-2
3.2.4 Reverse Trendelenburg Adjustment ............................................................................................3-3
3.3 Fowler Operation ...................................................................................................................................3-3
3.3.1 Raising the Fowler .......................................................................................................................3-3
3.3.2 Lowering the Fowler.....................................................................................................................3-3
3.4 Rail Operation........................................................................................................................................3-4
3.4.1 Raising the Rail to Full Height......................................................................................................3-4
3.4.2 Raising the Rail to Half Height.....................................................................................................3-4
3.4.3 Lowering the Rail .........................................................................................................................3-4
4 Recommended Preventive Maintenance.....................................................................................4-1
5 Recommended Optional Accessories.........................................................................................5-1
6 Replacement Parts ........................................................................................................................6-1
6.1 How to Use the Illustrated Parts Breakdown .........................................................................................6-1
6.2 List of Illustrations..................................................................................................................................6-3

1-1
Safety Precautions Operator / Service Manual 069216
1
The following Safety Precautions must be observed when operating or servicing this Hausted®Pediatric Care
Stretcher. WARNING indicates the potential for personal injury and CAUTION indicates the potential for damage
to equipment. For emphasis, certain Safety Precautions are repeated throughout the manual. It is important to
review ALL Safety Precautions before operating or servicing the unit.
Strictly following these Safety Precautions enhances your ability to safely and effectively utilize the unit and helps
the customer avoid improper maintenance methods which may damage the unit or render it unsafe. It is important
to understand that these Safety Precautions are not exhaustive; customers are encouraged to develop their own
safety policies and procedures to enhance and compliment these Safety Precautions.
WARNING – LACERATION HAZARD:
WARNINGS – PERSONAL INJURY:
When cutting bands always use a tool specifically designed for that purpose. This will help to avoid per-
sonal injuries frequently incurred when bands are cut and tension released.
Do not sit on end – tipping may occur.
!
!
SAFETY PRECAUTIONS 1

2-1
Unpacking Instructions Operator / Serivce Manual 069216
Important: Report any shipping damage immediately! Inform shipper
of any damages – leave carton intact. Leave the Horizon Stretcher in
the receiving area until inspection is complete.
Your Hausted®Pediatric Care Stretcher has been carefully packaged
at our manufacturing plant to ensure safe shipment to you medical
facility. There are several procedures you must follow to put your new
Horizon Stretcher into service. These procedures only take a few
minutes to complete and are required to ensure proper operation of
the Horizon Stretcher.
Step 1 – Cut the two bands around the shipping carton.
Step 2 – Remove the top half of the carton and cut one side of the
bottom half.
Step 3 – Remove the Hausted®Pediatric Care Stretcher from the
carton. Cut the bands from around the stretcher.
Step 4 – Check to see if all features of the stretcher work properly. If
all features work properly, go to step 5. If any of the features
of the Hausted®Pediatric Care Stretcher do not work
properly, call STERIS for service.
Step 5 – Clean the Horizon Stretcher using a mild detergent to
remove any dirt accumulated during shipment.
Step 6 – Place the stretcher into service.
WARNING – LACERATION
HAZARD: When cutting bands
always use a tool specifically
designed for that purpose.
This will help to avoid
personal injuries frequently
incurred when bands are cut
and tension released.
!
UNPACKING INSTRUCTIONS 2

3-1
Operating Instructions Operator / Service Manual 069216
3.1 Braking and
Steering Operation
3.1.1 Applying The Brakes
The four wheel central braking system is activated by depressing the
red pedal at any of the four corners of the unit (Figure 3-1). To fully
engage the brakes, the pedal should be pressed to approximately
45º. All four caster wheels should be locked from swiveling and
rotating.
3.1.2 Releasing The Brakes
Depress the green pedal at any of the four corners of the unit, until
the pedal is in a horizontal position (Figure 3-2). All four wheels
should rotate and swivel freely.
NOTE: Brakes should always be activated when unit is not in
transport.
3.1.3 Applying The Steering
Lock
From the head end of the stretcher, depress the green pedal
downward into locked position (Figure 3-3). Push the stretcher
forward. One caster at the foot end will lock into a non-swivel mode.
This allows straight steering by the attendant, when pushing from the
head end.
Figure 3-1
Figure 3-2
Figure 3-3
OPERATING INSTRUCTIONS 3

3-2
069216 Operator / Service Manual Operating Instructions
3.1.4 Releasing The Steering
Lock
Depress the red pedal at any of the four corners of the unit, until the
pedal is in a horizontal position (Figure 3-2). All four wheels should
rotate and swivel freely.
3.2 Stretcher Top
Height Adjustment
3.2.1 Height Adjustment
Press the pump pedal to the floor (Figure 3-4), then release. Repeat
this process until desired height is obtained. Use smooth strokes on
pump pedal to ensure patient comfort.
3.2.2 Lowering Litter Top
Press down on the two release pedals at the same time (Figure 3-5)
until desired height is obtained.
NOTE: Do Not Stand On Release Pedals.
3.2.3 Trendelenburg
Adjustment
Place the unit at maximum height, see SECTION 3.2‚ STRETCHER TOP
HEIGHT ADJUSTMENT‚ PAGE 3-2. Press down on the release pedal
nearest the head end (Figure 3-6) until desired position is obtained
then remove pressure.
Figure 3-4
Figure 3-5
Figure 3-6

3-3
Operating Instructions Operator / Service Manual 069216
3.2.4 Reverse Trendelenburg
Adjustment
Place the unit at maximum height, see SECTION 3.2‚ STRETCHER TOP
HEIGHT ADJUSTMENT‚ PAGE 3-2. Press down on release pedal nearest
the foot end (Figure 3-7) until desired position is obtained, then
remove pressure.
3.3 Fowler Operation
3.3.1 Raising the Fowler Grasp the fowler frame tube (Figure 3-8A), and lift up on the fowler.
When desired height is reached, lower the fowler slightly until the
ratchet plates are engaged (Figure 3-8B). Be sure the fowler is
locked into place by pushing down slightly on the fowler before
releasing the tube.
3.3.2 Lowering the Fowler
Grasp the fowler frame tube with hand and grasp the ratchet release
handle with finger tips (Figure 3-9). Squeeze the ratchet release
handle and the fowler frame tube together while lifting slightly on the
fowler. Once the ratchet supports are disengaged, while lowering
fowler to desired position, continue squeezing ratchet release
handle (Figure 3-8B). Be sure the fowler is locked into place by
pushing down slightly on the fowler before releasing the tube.
Figure 3-7
A B
Figure 3-8
Figure 3-9

3-4
069216 Operator / Service Manual Operating Instructions
3.4 Rail Operation
3.4.1 Raising the Rail to Full
Height
Grasp the rail top tube in the center of the rail (Figure 3-10A), with
free hand squeeze the rail trigger (Figure 3-10B). Lift the rail all the
way up (Figure 3-10C). Once the rail is all the way up, release the rail
trigger and lower the rail slowly until the trigger engages. Check rail
lock by trying to squeeze the rail trigger, if you cannot squeeze the
trigger the rail is locked securely, release the rail top tube.
NOTE: Be sure rail is locked securely before leaving patient.
3.4.2 Raising the Rail to Half
Height
Grasp the rail top tube in the center of the rail (Figure 3-10A), raise
the rail until it engages. Check rail lock by trying to squeeze the rail
trigger, if trigger will not squeeze, the rail is locked securely. Release
rail top tube.
NOTE: Be sure rail is locked securely before leaving patient.
3.4.3 Lowering the Rail
Grasp the rail top tube in the center of the rail, with free hand
squeeze the rail trigger (Figure 3-10C) while lifting slightly on the rail.
This should allow the rail trigger to release the trigger lock. Lower the
rail slowly (Figure 3-11). If “half height” is desired, release the rail
trigger as soon as the rail starts lowering. If “full down” is desired
continue to squeeze the trigger until the rail is all the way down.
NOTE: Be sure rail is locked securely before leaving patient.
NOTE: Never leave the patient unattended with the rail down.
A B C
Figure 3-10
Figure 3-11

4-1
Recommended Preventive Maintenance Operator / Service Manual 069216
NOTE: If units are pressure washed or steam cleaned, lubrication of all hinging, moving, and sliding points should
be done afterwards. (Pressure washing and steam cleaning are not recommended procedures and can void
warranty.)
For more details information, please contact:
STERIS Corporation at:
1-800-333-8828
Procedure Schedule Material
Lubricate all moving and sliding parts and
hinge points.
6 Months Lubricating oil, light-duty grease,
wax stick lubricant or Never-Seez
lubricant.
Inspect all fasteners to ensure proper fit,
position and tightness (including nuts,
bolts, etc.).
3 Months Proper size wrench and screw-
driver.
Cleaning mattresses and pads Periodically Medium strength cleaners, soap
and water. (DO NOT pressure
clean or steam clean.)
Inspect all surfaces and remove any user
developed sharp or burred areas. Apply
touch-up paint where required.
Periodically Metal File, proper color paint
(specify color when ordering).
Clean external surface to remove blood,
dirt, lint, and any other deposits.
Periodically Medium strength anti-bacterial
cleaners, stainless steel cleaner &
polish.
RECOMMENDED PREVENTIVE MAINTENANCE 4

5-1
Recommended Optional Accessories Operator / Service Manual 069216
Number Description
00011P-00 1” Thick Foam Padded Side And End Rails, Color: Mauve
000012-00 Restraint Straps with Buckle
APC012-00 Restraint Straps With Velcro
000E17-00 I.V. Rod 42” Stainless Steel
000018-00 Telescoping I.V. Rod, 27” To 60” 2 Section, With Holder, Stainless
126740-00 Infusion Pump I.V. Pole 1-1/8” Diameter, 42” Long, Removable
128450-00 Vertical Oxygen Tank Holder
IVSTOW-00 Mobile I.V. Stand Attachment
069060 Fifth Wheel Assembly
RECOMMENDED OPTIONAL ACCESSORIES 5

6-1
Recommended Replacement Parts Operator / Service Manual 069216
6
No indentation – part
number of assembly
One indentation –first
subassembly, part of
assembly under which it
is indented
6-2- P 146655 023 ARM AND LIGHTHEAD ASSEMBLY.......................................
1 P 136807 181 CAP..........................................................................................
2 P 136807 981 FUNNEL CONE ASSEMBLY ...................................................
P 136807 979 • CAP, Shield............................................................................
P 129362 378 • CLIP, Locking.........................................................................
P 93911 304 • CONE, Cap............................................................................
P 136807 980 • FUNNEL, Cap ........................................................................
3 P 83628 001 SCREW, Button Head, #6-32 x 3/8 Lg.....................................
4 P 19684 061 LOCKWASHER, Helical, #6.....................................................
5 P 90713 061 LOCKWASHER, Helical, #4.....................................................
6 P 47760 091 SCREW, Button Head, #4-40 x 1/4 Lg.....................................
Typical Indentation Example (Parts Shown are Examples Only)
REPLACEMENT PARTS
Significant assemblies and components of the Hausted®Pediatric Care Stretchers are illustrated and identified in
this section. The part number, the description and the quantity required for each usage are given. Each indentation
in the description represents the assembly level. The UNITS PER ASSEMBLY column is specific for the given
assembly or subassembly level.
6.1 How to Use the Illustrated Parts Breakdown
1. Determine the function and application of the part required. Select the most appropriate title from the List of
Illustrations in the Table of Contents. Note the illustration page number.
2. Turn to the page indicated and locate the desired part on the illustration.
3. From the illustration, obtain the item number assigned to the desired part. Refer to the accompanying tabular
list (usually on the facing page) for the part number and description of the part.

6-3
Recommended Replacement Parts Operator / Service Manual 069216
6.2 List of Illustrations
Figure 6-1. Model 4160 Base Final Assembly (Part 1 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Figure 6-1. Model 4160 Base Final Assembly (Part 2 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Figure 6-2. Fowler Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Figure 6-3. Pediatric Rail Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
Figure 6-4. Locking Guide Tube - Pediatric Rail Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Figure 6-5. Final Assembly (Part 1 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Figure 6-5. Final Assembly (Part 2 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
Figure 6-6. 4160 Fifth Wheel Center Track Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18

6-4
069216 Operator / Service Manual Recommended Replacement Parts
Figure 6-1. Model 4160 Base Final Assembly (Part 1 of 2)

6-5
Recommended Replacement Parts Operator / Service Manual 069216
Figure 6-1. Model 4160 Base Final Assembly (Part 2 of 2)

S
V
CDESCRIPTION
FIG. &
ITEM
NO.
PART
NUMBER UNITS PER
ASSEMBLY
6-6
069216 Operator / Service Manual Recommended Replacement Parts
6-1 P 150830 734 MODEL 4160 BASE FINAL ASSEMBLY.......................................... X
1 069026 ASSEMBLY, Short Base Frame......................................................... 1
2 075271 CASTER, 8" Tente, Brake Total/Lock (Units made after 1-3-98)....... 3
069018 CASTER, 6" Tente, Twin Brake Total/Lock (Units made before 1-3-98) 3
3 075270 CASTER, 8" Tente Steer/Lock (Units made after 1-3-98).................. 1
069019 CASTER, 6" Tente Twin, Swivel Lock (Units made before 1-3-98).... 3
4 031090 LOCKWASHER, 1/4 Internal Tooth.................................................... 8
5 069022 SCREW, Socket Head Cap Screw, M6 x 1.0 x 10.0.......................... 8
6 031080 WASHER, 5/16................................................................................... 1
7 068209 JACK, Head End Hydraulic................................................................ 1
8 066049 CHAIN, Anti-Static.............................................................................. 1
9 031416 SCREW, Type A Self-Tapping, #10 x 1/2 .......................................... 1
10 062684 LEVER, Cam...................................................................................... 4
11 069008 ROD, Long Brake............................................................................... 2
12 069009 ASSEMBLY, Left Brake Pedal ........................................................... 2
13 069010 ASSEMBLY, Right Brake Pedal......................................................... 2
14 069478 PLATE, Jack Mounting Reinforcement .............................................. 4
15 068338 COLLAR, Worm ................................................................................. 4
16 068207 JACK, Foot End Hydraulic.................................................................. 1
17 035115 WASHER, Nylon, 5/16 ....................................................................... 1
18 035122 SCREW, Hex Head Cap, 1/4-20 x 1-3/4............................................ 4
19 031337 SCREW, Hex Head Cap, 1/4-20 x 3/4 ............................................... 4
20 031076 WASHER, USS Flat, 3/4 OD x 5/16 ID .............................................. 4
21 031055 NUT, Lock, 1/4-20.............................................................................. 13
22 P 150830 741 COLLAR, Stop, 1/4............................................................................. 2
23 075243 ASSEMBLY, Jack Link....................................................................... 1
24 P 150830 742 SCREW, Set, #10-32 ......................................................................... 2
25 P 150830 599 ASSEMBLY, Pump Pedal .................................................................. 1
26 068126 NYLINER, 1/2..................................................................................... 2
27 068379 BAR, Pump Pedal Hinge.................................................................... 1
28 031359 WASHER, Flat.................................................................................... 4
29 068355 ANGLE, Vertical Guide....................................................................... 1
30 068417 CLIP, Rue, 5/16.................................................................................. 1
31 068418 NYLINER, Type 7, 1/4........................................................................ 2
32 031006 SCREW, Hex Head Cap, 1/4-20 x 1-1/2............................................ 2
33 031321 SCREW, Hex Head Cap, 1/4-20 x 2 .................................................. 9
34 031054 NUT, Free Thread, 1/4-20.................................................................. 2
35 069492 BUMPER, Stop................................................................................... 1
36 075249 TAPE, Teflon, 2.5 x .75...................................................................... 1
37 031076 WASHER, Special Flat....................................................................... 10
38 069481 BRACKET, Axle Bearing.................................................................... 2
39 068512 LOOP, Velcro..................................................................................... 1
40 068377 PLATE, Push...................................................................................... 2
41 068890 SCREW, Hex Head Cap, #10-32 x 1/2 .............................................. 2
42 068380 TAPE, Teflon, 3/4 x 1-1/2................................................................... 4
43 068381 TAPE, Teflon, 1/2 x 3/4...................................................................... 2
44 068530 WASHER, Nylon Shoulder................................................................. 2
45 P69484 PEDAL, Release ................................................................................ 2
46 P 150830 746 SUB-ASSEMBLY, Head Release Link............................................... 1
47 P 150830 749 SUB-ASSEMBLY, Foot Release Link ................................................ 1
48 031057 NUT, Lock, 5/16-18............................................................................ 4
49 062688 BOLT, Eye.......................................................................................... 4
50 031058 NUT, Free Thread, 5/16-18................................................................ 4
51 069091 BAR, Short Brake Connecting............................................................ 2
52 065807 BOLT, Shoulder, 3/8 x 3/8.................................................................. 4

S
V
CDESCRIPTION
FIG. &
ITEM
NO.
PART
NUMBER UNITS PER
ASSEMBLY
6-7
Recommended Replacement Parts Operator / Service Manual 069216
6-1 P 150830 734 MODEL 4160 BASE FINAL ASSEMBLY.......................................... X
53 P 150830 756 NUT, Lock, 5/16-18............................................................................ 4
54 069097 ASSEMBLY, Stabilizer....................................................................... 2
55 069072 GLIDE, Spacer................................................................................... 2
56 068513 HOOK, Velcro, 2.0 x 5/8 (Not Shown)................................................ 12
57 068512 PILE, Velcro, 2.0 x 5/8........................................................................ 12
58 068376 SPACER, Cover................................................................................. 4
59 069030 COVER, Base .................................................................................... 1
60 068475 TAPE, Double Sided, 2.0 x 1/2........................................................... 8
61 069212 TUBE, Cover Support......................................................................... 4
62 069280 COVER, Foot End Horizon Bottom.................................................... 1
63 069281 COVER, Head End Horizon Bottom................................................... 1

6-8
069216 Operator / Service Manual Recommended Replacement Parts
Figure 6-2. Fowler Assembly

S
V
CDESCRIPTION
FIG. &
ITEM
NO.
PART
NUMBER UNITS PER
ASSEMBLY
6-9
Recommended Replacement Parts Operator / Service Manual 069216
6-2 069497 FOWLER ASSEMBLY ...................................................................... X
1 068128 SCREW, Button Head Socket, 1/4-20 x 1-1/4 .................................... 2
2 069041 ASSEMBLY, Fowler............................................................................ 1
3 069085 SUPPORT, Pediatric Fowler............................................................... 1
4 062038 SCREW, Button Head Socket, 1/4-20 x 3/4........................................ 2
5 069079 HANDLE, Manual Fowler Adjustment................................................. 1
