Stryker Adel Maternity Bed Series User manual

AdelrMaternity Bed
Model 4700 & 5012
OPERATIONS MANUAL
For Parts or Technical Assistance
1−800−327−0770

Table of Contents
Introduction 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning / Caution / Note Definition 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bed Symbols 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Tips And Guidelines 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Unpacking Instructions and Set−Up Procedures 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bed Illustration 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Siderail Operation Guide 7−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pendant Operation Guide 10−12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Bed Features
Using the Brake And Steer Pedals 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Manual Motor Crank 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Activating Instant CPR 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Locking Out the Siderail Controls 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removing the Head Board 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Labor Grips 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjustable Seat Depth 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nurse Call Battery 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Night Light Usage 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating the Foot Section 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lumbar and Perineal Pillows 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Patient Positioning
Birthing Bed Positioning 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Birthing Chair Positioning With Labor Bar 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Delivery Table Positioning 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trendelenburg Positioning 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pelvic Tilt 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using Accessories
Using Leg Supports 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Labor Bar 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Arm Board 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Permanently Attached I.V. Pole 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preventative Maintenance Checklist 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Limited Warranty
Obtaining Parts and Service 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supplemental Warranty Coverage 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Return Authorization 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Freight Damage Claims 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction
2
INTRODUCTION
This manual is designed to assist you with the operation of the Stryker AdelrMaternity Bed. Read it thorough-
ly before using the equipment or beginning any maintenance on it.
SPECIFICATIONS
Maximum Weight Capacity 500 pounds (227 kilograms)
Bed Length/Width 90”x 41”(with siderails up) −37”(with siderails down)
229 cm x 104 cm (with siderails up) −94 cm (with siderails down)
Bed Height (to top of seat) Low −19”(49 cm), High −37”(95 cm) (w/8”Casters)
Mattress Size Head −49.5”(126 cm) x 33”(84 cm) x 5”(13 cm), Foot −31”(79 cm) x
30”(77 cm) x 3”(8 cm), Patient Sleep Surface −81”(206 cm)
Critical Angles Maximum Elevation −Head 70_, Trendelenburg 8_
Break−Away Point from Wall 60”(152 cm)
Electrical Standard 4 motor function: Head−Bed−Foot−Trendelenburg
120 VAC, 60 Hz, 6 Amp −105 to 135 VAC operating range.
Optional: 230 VY, 50/60 Hz, 6 A −220 to 240 VAC operating range
Current leakage less than 100 microamperes.
Hospital grade plug and 3−wire heavy duty cord.
Compatible with non−flammable anesthetic agents and oxygen by nasal
catheter or mask.
Caster Size 8”Standard; 6”Optional
Stryker reserves the right to change specifications without notice.
WARNING / CAUTION / NOTE DEFINITION
The words WARNING, CAUTION and NOTE carry special meanings and should be carefully reviewed.
WARNING
The personal safety of the patient or user may be involved. Disregarding this information could result in injury
to the patient or user.
CAUTION
These instructions point out special procedures or precautions that must be followed to avoid damaging the
equipment.
NOTE
This provides special information to make maintenance easier or important instructions clearer.
To ensure its proper use and the safety of patients and staff, the Stryker AdelrMaternity Bed has been marked
with the following caution and warning labels:
DANGER Explosion Hazard −do not use in the presence of flammable anesthetics.
CAUTION This unit is equipped with a hospital grade attachment plug. Grounding reliability can be
achieved only when equipment is connected to equivalent receptacle.
CAUTION Electrical shock hazard. Do not remove cover panels. Refer all servicing to qualified personnel.
CAUTION Disconnect power cord before using the back up hand crank. Remove hand crank from back
up outlet before connecting power cord.

Bed Symbols
3
Warning, Refer to Service/Maintenance Manual
Alternating Current
Type B Equipment: equipment providing a particular degree of protection against elec-
tric shock, particularly regarding allowable leakage current and reliability of the protec-
tive earth connection.
Class 1 Equipment: equipment in which protection against electric shock does not rely
on BASIC INSULATION only, but which includes an additional safety precaution in that
means are provided for the connection of the EQUIPMENT to the protective earth con-
ductor in the fixed wiring of the installation in such a way that ACCESSIBLE METAL
PARTS cannot become live in the event of a failure of the BASIC INSULATION.
Mode of Operation: Continuous
IPX4: Protection from liquid splash
Dangerous Voltage Symbol
Protective Earth Terminal
Potential Equalization Symbol
Medical Equipment Classified by Underwriters Laboratories Inc. with Respect to Elec-
tric Shock, Fire, Mechanical and Other Specified Hazards Only in Accordance with UL
2601−1 and CAN/CSA C22.2 No. 601.1
~

Introduction
4
SAFETY TIPS AND GUIDELINES
Before operating the Stryker Adel Maternity Bed, it is important to read and understand all information in this
manual. Carefully read and strictly follow the safety guidelines listed on this page.
It is important that all users have been trained and educated on the inherent hazards associated with the
usage of electric beds.
WARNING
SThe Stryker Adel Maternity Bed is equipped with a hospital grade plug for protection against shock haz-
ard. It must be plugged directly into a properly grounded three−prong receptacle. Grounding reliability
can be achieved only when a hospital grade receptacle is used.
SPowered bed mechanisms can cause serious injury. Operate bed only when all persons are clear of the
mechanisms.
STo help reduce the number and severity of falls by patients, always leave the bed in the lowest position
when the patient is unattended.
SLeave the siderails fully up and locked when the patient is unattended. When raising the siderails, listen
for the ”click”that indicates the siderail has locked into the up position. Pull firmly on the siderail to ensure
it is locked into position. Siderails are not intended to be a patient restraint device. It is the responsibility
of the attending medical personnel to determine the degree of restraint necessary to ensure a patient will
remain safely in bed.
SAlways apply the caster brakes when a patient is getting on or off the bed. Always keep the caster brakes
applied when a patient is on the bed (except during transport). Serious injury could result if the bed moves
while a patient is getting in or out of bed. After the brake pedal is applied, push on the bed to ensure the
brakes are locked. When moving the bed, toggle the steer pedal to put the bed in the steer mode. This
locks the swivel motion of the right foot end caster and makes the bed easier to move.
SThe instant CPR release is for emergency use only. When activating the instant CPR, all persons and
equipment must be removed from the area below and around the Fowler (back rest) section of the bed
or serious personal injury or damage to the equipment could occur.
SWhen large spills occur in the area of the circuit boards, 110 volt cables and motors, immediately unplug
the bed power cord from the wall socket. Remove the patient from the bed and clean up the fluid. Have
maintenance completely check the bed. Fluids can have an affect on operational capabilities of any elec-
trical product. DO NOT put the bed back into service until it is completely dry and has been thoroughly
tested for safe operation.
SDo not steam clean or hose off the bed. Do not immerse any part of the bed. The internal electric parts
may be damaged by exposure to water. Hand wash all surfaces of the bed with warm water and mild
detergent. Dry thoroughly. Inspect the mattress cover after each use. Discontinue use if any cracks or
rips are found in the cover which may allow fluids to enter the mattress. Exposure to fluids may cause
injury to patient and/or user.
SPreventative maintenance should be performed at a minimum of annually to ensure all bed features are
functioning as designed. Close attention should be given to safety features including, but not limited to:
SSafety side latching mechanisms, SCaster braking system,
SFrayed electrical cords and components, SLeakage current 100 MA max.
SNo controls or cabling entangled in bed mechanisms,
SAll electrical controls return to off or neutral position when released,
SFor additional maintenance information, refer to your maintenance manual.
SAlways unplug bed during service or cleaning. When working under the bed with the bed in the high posi-
tion, always place blocks under the litter frame and set the brakes to prevent injury in case the Bed Down
switch is accidently pressed.
SUnplug the bed power cord from the wall socket before using the hand crank. Remove the hand crank
before plugging the power cord into the wall socket or personal injury could result.

Unpacking and Initial Set−Up Procedures
5
UNPACKING INSTRUCTIONS
Refer to unpacking instructions attached to the bed inside the crate.
SET−UP PROCEDURES
It is important that the Stryker AdelrMaternity Bed is working properly before it is put into service. The follow-
ing list will help ensure that each part of the bed is tested.
SPlug the bed into a properly grounded, hospital grade wall receptacle.
WARNING
The Stryker AdelrMaternity Bed is equipped with a hospital grade plug for protection against shock hazard.
It must be plugged directly into a properly grounded three−prong receptacle. Grounding reliability can be
achieved only when a hospital grade receptacle is used.
SEnsure the siderails raise and lower smoothly and lock in the up position.
SEnsure that the brakes hold when the brake pedal is engaged.
STest each function on the (optional) hand pendant to ensure that each function is working properly.
Beds equipped with nurse communication siderail control option only:
SPlug the interface cable into the 37 pin connector in the litter frame at the head end of the bed, and into
the ”Patient Station”, ”Head Wall”, ”Docker Station”, or equivalent (whichever applies).
SRun through each function on the siderail control panels to ensure that each function is working properly.
NOTE
To prevent a low battery condition when the bed is not plugged in, position the cord out switch at the head
end of the bed to the off position. The switch is identified by the label shown below. If the switch is not posi-
tioned as shown below and the bed power cord and pendant cord are unplugged, the life of the back−up bat-
tery will be significantly reduced.
If the siderail lights LED (located on the outside of both siderails) is flashing, the Nurse Call battery needs
to be replaced. The battery is located on the patient’s right side at the head end of the bed. No tools are
required to replace the battery. Unplug the bed power cord from the wall socket and replace the battery. After
replacing the battery, verify the siderail lights LED is no longer flashing and operates normally when the differ-
ent light settings are selected.

6
Bed Illustration
WARNING
Potential pinch points

Siderail Operation Guide
7
OPERATING SIDERAILS
To engage the head end siderail, grasp the rail and swing it upward to full height. When the siderail is being
raised, it does not lock in the intermediate position. To lower the siderail, push in the release handle and rotate
the siderail until it locks in the intermediate position. To lower the siderail fully, push in the release handle again
and rotate the siderail until it is completely lowered.
NOTE
To activate the siderail bypass mechanism, the rail must be fully lowered. If the rail is not completely lowered,
the siderail will lock in the intermediate position when it is raised.
USING THE SIDERAIL CONTROL PANEL LIGHTS
The bed is equipped with lights to illuminate the head end siderail control panels and the red nurse call
switches. Four settings are available for the control panel lights. Push once to turn on the lights at low intensi-
ty, again to change to high intensity, a third time to leave just the nurse call light on, and a fourth time to turn
all lights off.
INSIDE SIDERAIL FUNCTION GUIDE
1. Push to raise Fowler (back rest).
2. Push to raise foot section.
3. Push to lower Fowler (back rest).
4. Push to lower foot section.
1. Push to activate Nurse Call
NOTE
Yellow LED will light when button is pushed. Red LED will light
with Nurse Station acknowledgement.
1. Push to turn TV or radio on and to select a channel.
2. Push to increase volume.
3. Push to decrease volume.
1.
1.
2.
3.

Siderail Operation Guide
8
INSIDE SIDERAIL FUNCTION GUIDE (CONTINUED)
1. Push to turn the television on and to select a channel.
2. Push to increase the television volume.
3. Push to decrease the television volume.
1. Push to turn the room light on.
Push again to turn off.
2. Push to turn the bed overhead light on.
Push again to turn off.
1. Push for more support to the patient’s lower back.
2. Push for less support to the patient’s lower back.
3. Push for more support to the patient’s seat section.
4. Push for less support to the patient’s seat section.
5. Push to change the channel on the television.
6. Push to change the channel on the television.
1.
2.
1.
2.
3.

Siderail Operation Guide
9
OUTSIDE SIDERAIL FUNCTION GUIDE
1. Push to raise Fowler (back rest).
2. Push to raise bed height.
3. Push to raise foot section.
4. Push to lower Fowler (back rest).
5. Push to lower bed height.
6. Push to lower foot section.
1. Push to lower head end of bed (Trendelenburg position).
(This function is also used for pelvic tilt).
2. Push to toggle siderail lights to different settings:
A. LOW
B. HIGH
C. NURSE CALL ONLY
D. OFF
3. Push to raise head end of bed and/or return bed to level.
4. Push to lock out all bed motion. Push again to unlock.
(LED will light when bed motion is locked.)
5. Push to activate Nurse Call.
1. Push to decrease seat depth.
2. Push to increase seat depth.
NOTE: The Fowler (back rest) must be raised until the “EN-
ABLED”LED lights (a minimum of 35_) before the depth can
be changed.

10
Communication Pendant Operation Guide

11
Motion Pendant Operation Guide

12
Motion Pendant with Nurse Call Operation Guide

13
Operating Bed Features
USING THE BRAKE AND STEER PEDALS
The brake pedals are located at the center of the base frame on both sides of the bed. To engage the brakes,
depress the pedal to the brake position. To disengage the brakes, depress the pedal to the neutral position.
The steer pedal is located at the head end of the bed. To engage the steering function, depress the pedal
to the ON position. To disengage the steering function, depress the pedal to the OFF position.
BRAKE PEDAL STEER PEDAL
USING THE MANUAL MOTOR CRANK
WARNING
To avoid serious personal injury or damage to the equipment, unplug the bed power cord from the wall recep-
tacle before using the hand crank and remove the hand crank from the motor before plugging in the power cord.
If there is a loss of electrical power to the bed, there is a manual motor crank stored in clips on the head end
of the bed. Center the notch in the end of the crank on the roll pin on the bed motor assembly or the Fowler
motor assembly and crank the bed to the desired position.
ACTIVATING INSTANT CPR
The CPR release lever is located at the head section on both sides of the bed. To activate the CPR release,
grasp the lever and squeeze tightly. The Fowler (back rest) will lower to the lowest position instantly.
WARNING
The instant CPR release is for emergency use only. Before activating the instant CPR, verify all persons and
equipment are away from the area below and around the Fowler (back rest) section of the bed or serious
personal injury or damage to the equipment could occur.
LOCKING OUT THE SIDERAIL CONTROLS
The lock out feature disables the siderail bed motion controls. Lock out
buttons are located on the outside of both siderails. Lock out the bed mo-
tion controls by depressing the button once. The bed motion lockout
LED will light. Reactivate the controls by pressing the button again.

14
Operating Bed Features
REMOVING THE HEAD BOARD
To remove the head board, lift it straight up and off the bed. To replace the head board, align the plastic inserts
on the bottom of the head board with the pins on the bed and lower the head board until it completely engages
the pins.
USING THE LABOR GRIPS
To position the labor grips, grasp the handle and pull the grip out and up above the mattress until the mecha-
nism locks into position. To lower the grips, pull the lever to release the grip and, as it begins to rotate, release
the lever and lower the grip to the stored position.
ADJUSTABLE SEAT DEPTH (OPTIONAL)
To accommodate patients of different sizes, the depth of the seat can be adjusted up to 4 inches (from 12.5
to 8.5 inches).
SThe Fowler (back rest) must be raised to a minimum of 35_before the seat depth can be changed. Once
the Fowler (back rest) is elevated to 35_, the “ENABLED”LED on the outside of the siderail will light and
the seat depth can be changed. When the Fowler (back rest) is lowered (either electrically or using the
emergency CPR release), the bed will automatically adjust the seat depth to 12.5”.
STo reduce seat depth, depress the button on the siderail or the hand pendant to move the Fowler
(back rest) toward the foot end of the bed. Release the button when the desired seat depth is attained.
STo increase seat depth, press the button to move the Fowler (back rest) toward the head end
of the bed.
NURSE CALL BATTERY
To prevent a low battery condition when the bed is not plugged in, position the cord out switch at the head
end of the bed to the off position. The switch is identified by the label shown below. If the switch is not posi-
tioned as shown below and the bed power cord and pendant cord are unplugged, the life of the back−up bat-
tery will be significantly reduced.
If the siderail lights LED (located on the outside of both siderails) is flashing, the Nurse Call battery needs
to be replaced. The battery is located on the patient’s right side at the head end of the bed. No tools are
required to replace the battery. Unplug the bed power cord from the wall socket and replace the battery. After
replacing the battery, verify the siderail lights LED is no longer flashing and operates normally when the differ-
ent light settings are selected.

15
Operating Bed Features
NIGHT LIGHT USAGE
The bed is equipped with a night light to illuminate the floor area around the bed. There is a switch on the
light to turn it on and off.
OPERATING THE GLIDEAWAY FOOT SECTION/ATTACHABLE CALF SUPPORTS
SRotate the foot rest into position by pulling it out and up over the foot end mattress until it clicks into place.
Ensure the foot rest is securely locked in the upright position by grasping and attempting to move it.
SAfter they are in position, the foot rests are adjustable six ways:
1. Abduct/Adduct (pivoting)
Pivoting in and out allows the clinician to position the patient’s feet and legs at the desired width. Pull down
on the knob located below the foot mattress. Pivot the foot rest into the desired position and release the
knob to lock the foot rest into place.
2. In/Out
The in/out motion allows patients of different heights to be accommodated comfortably. Pull the lever
marked with the PULL label to increase the distance of the foot rest from the Perineal edge. Release
the lever when the foot rest is in the desired position.
3. Height
The foot end high/low adjustment allows the foot end of the bed to be positioned 6”below the top of the
seat mattress to accommodate different sized patients when the foot rest or calf supports are being used.
STo store the foot rests, loosen the ball screws on the self−storing calf supports (if used). Ensure the foot
rests are pointing toward the end of the bed. Pull the lever marked “PULL”located at the bottom of the
foot rest support and the foot rest will glide under the foot mattress.
REMOVING THE FOOT SECTION MATTRESS
Before removing the foot mattress, put the foot rests into position above the foot mattress. Place the patient’s
feet in the contoured foot rests. To remove the foot mattress, pull up on the red release handle on either side
of the mattress and slide the mattress straight off the bed.
NOTE
If the foot section mattress is placed with the perineal edge toward the floor, it will stand independently.
To reinstall the foot section of the bed, set the foot mattress back on the bed and slide it straight in until it locks
into place. Pull on the handles to ensure it is securely installed.
OPTIONAL LUMBAR PILLOW AND PERINEAL WEDGE
SUse the one−touch lumbar and seat buttons on the siderail to adjust the amount of support given to the
patient’s lumbar and seat areas if the bed is equipped with this option.
NOTE
Be sure the locating pins on the underside of the mattress are inserted in the holes in the steel seat support.

16
Operating Bed Features
BIRTHING BED POSITIONING
SPosition the patient’s feet in the foot rests.
SRaise or lower the foot rests to a position comfortable for the patient.
SRemove the foot section and tuck the drape into the drainage pan.
SRaise the bed to a comfortable height by pressing the “Bed−Up”control on the siderail and position the
patient’s perineum out and over the edge of the seat section.
DELIVERY TABLE POSITIONING
SSlide the patient down to the perineal edge.
SLower the foot section to its lowest position.
SPosition the attached calf supports and place the patient’s legs in the supports.
TRENDELENBURG POSITIONING
Lower the Fowler (back rest) by pressing the control on the siderail or by squeezing the CPR lever. Press
the Trendelenburg button on the siderail or the control pendant to lower the head end of the bed to the desired
angle.
PELVIC TILT
Use the Trendelenburg button on the siderail or the control pendant to provide more pelvic tilt and comfort
for the patient when the Fowler (back rest) is raised.

17
Using Optional Accessories
USING LEG SUPPORTS
To use full−length leg supports on the bed, insert the leg support bar into the receptacle near the labor grips
at the perineal edge.
USING THE LABOR BAR
To use the labor bar, insert it into the holes on each side of the seat section, under the mattress at the perineal
edge. The labor bar can be used by the patient to aid with various birthing positions such as squatting or
kneeling.
USING THE ARM BOARD
The arm board is held in place between the mattress and the frame. The arm board is provided with a remov-
able mattress. The weight of the patient retains the arm board in the desired position.

18
Using Optional Accessories
OPERATING OPTIONAL 3−STAGE PERMANENTLY ATTACHED I.V. POLE
B
D
A
C
E
A
E
DETAIL OF I.V. POLE LATCH
DETAIL OF I.V. POLE GRIP
B
D
C
NOTE
The 3−stage permanently attached I.V. pole is an option and can only be installed at the head end of the bed.
To use the 3−stage permanently attached I.V. pole:
1. Lift and pivot the pole from the storage position and push down until it is locked into the receptacle.
2. To raise the height of the pole, pull up on the telescoping portion (A) until it locks into place at its fully raised
position.
3. For a higher I.V. pole, pull up on section (B). Release section (B) at any desired height and it will lock
into place.
4. Rotate the I.V. hangers (C) to the desired position and hang the I.V. bags.
5. To lower the I.V. pole, push up on the red portion of grip (D) while holding onto section (B) until it lowers.
Turn latch (E) clockwise until section (A) lowers.
CAUTION
To avoid damage, the weight of the I.V. bags should not exceed 40 pounds.
To avoid damage while transporting the bed, verify the I.V. pole is at a low enough height to allow it to pass
safely through door openings.

19
Cleaning
WARNING
Hand wash all surfaces of the bed with warm water and mild detergent. Dry thoroughly. DO NOT STEAM
CLEAN, PRESSURE WASH, HOSE OFF OR ULTRASONICALLY CLEAN. Using these methods of cleaning
is not recommended and may void this product’s warranty.
Inspect the mattress cover after each use. Discontinue use if any cracks or rips are found in the cover which
may allow fluids to enter the mattress. Exposure to fluids may cause injury to patient and/or user.
In general, when used in those concentrations recommended by the manufacturer, either phenolic type or
quaternary type disinfectants can be used. Iodophor type disinfectants are not recommended for use be-
cause staining may result. The following products have been tested and have been found not to have a harm-
ful effect WHEN USED IN ACCORDANCE WITH MANUFACTURERS RECOMMENDED DILUTION.*
TRADE NAME DISINFECTANT
TYPE MANUFACTURER *MANUFACTURER’S
RECOMMENDED
DILUTION
A33 Quaternary Airwick (Professional Products Division) 2 ounces/gallon
A33 (dry) Quaternary Airwick (Professional Products Division) 1/2 ounce/gallon
Beaucoup Phenolic Huntington Laboratories 1 ounce/gallon
Blue Chip Quaternary S.C. Johnson 2 ounces/gallon
Elimstaph Quaternary Walter G. Legge 1 ounce/gallon
Franklin Phenomysan F2500 Phenolic Purex Corporation 1 1/4 ounce/gallon
Franklin Sentinel Quaternary Purex Corporation 2 ounces/gallon
Galahad Phenolic Puritan Churchill Chemical Company 1 ounce/gallon
Hi−Tor Quaternary Huntington Laboratories 1/2 ounce/gallon
LPH Phenolic Vestal Laboratories 1/2 ounce/gallon
Matar Phenolic Huntington Laboratories 1/2 ounce/gallon
Omega Quaternary Airwick (Professional Products Division) 1/2 ounce/gallon
Quanto Quaternary Huntington Laboratories 1 ounce/gallon
Sanikleen Quaternary West Chemical Products 2 ounces/ gallon
Sanimaster II Quaternary Service Master 1 ounce/gallon
Vesphene Phenolic Vestal Laboratories 1 1/4 ounce/gallon
Wexcide Phenolic Wexford Labs 1/2 ounce/gallon
Quaternary Germicidal Disinfectants, used as directed, and/or Chlorine Bleach products, typically 5.25% So-
dium Hypochlorite in dilutions ranging between 1 part bleach to 100 parts water, and 2 parts bleach
to 100 parts water are not considered mild detergents. These products are corrosive in nature and
may cause damage to your stretcher if used improperly. If these types of products are used to clean
Stryker patient handling equipment, measures must be taken to insure the stretchers are rinsed with clean
water and thoroughly dried following cleaning. Failure to properly rinse and dry the stretchers will leave a cor-
rosive residue on the surface of the stretcher, possibly causing premature corrosion of critical components.
NOTE
Failure to follow the above directions when using these types of cleaners may void this product’s warranty.
REMOVAL OF IODINE COMPOUNDS
This solution may be used to remove iodine stains from mattress cover and foam footrest pad surfaces.
1. Use a solution of 1−2 tablespoons Sodium Thiosulfate in a pint of warm water to clean the stained area.
Clean as soon as possible after staining occurs. If stains are not immediately removed, allow solution
to soak or stand on the surface.
2. Rinse surfaces which have been exposed to the solution in clear water before returning bed to service.
