Sumake SS-1207 User manual

SUMAKE PNEUMATIC TOOLS
Hvlp Air Gravity Spray Gun
W/125cc Plastic Cup
SS-1207A
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
Specification:
Free Type Gravity
Standard Nozzle 0.8 mm
Option Nozzle 1.0mm, 1.2mm
Capacity Of Cup 0.125 L
Air Consumption 4.9 CFM (139 L/min)
Air Inlet (NPS) 1/4” (6.35 mm)
Air Hose (NPS) 3/8” (10 mm)
Air Pressure 29psi (2kg/cm²) (2Bar)
Net Weight 0.77 lbs (0.35 kg)
Noise and Vibration:
Vibration Noise Remark
0.186 m/s²
Sound Pressure Level
: 71 dB(A) Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
hearing!
Sound power level
: 82 dB(A)
Uncertainty
K= 1.5 m/s²Uncertainty
K= 3dB
SS-1207A-S-1909A-GWF

ECDECLARATION OF CONFORMITY
We: SUMAKE INDUSTRIAL CO., LTD.
4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan
declare in sole responsibility that the equipment
Equipment：HVLP AIR GRAVITY SPRAY GUN W/125cc PLASTIC
Model/ Serial No.：SS-1207A
to which this declaration applies, complies with these normative documents:
Machinery Directive: 2006/42/EC
and conforms to the following EN standard,
EN ISO 12100: 2010
EN 1953: 1998 +A1:2009
Name and Signature/Position Date and Place
2013/2/22
MikeSu–ManagingDirector Taipei, Taiwan
SS-1207A-D-1909A-GWF

SS-1207A
HVLP AIR GRAVITY SPRAY GUN W/125cc PLASTIC CUP
PARTS LIST
No. Parts No. Description Q'ty No. Parts No. Description Q'ty
1 1207-01 Air Cap 1 15 1207-15 Fluid Adj. Guide Set 1
1207A-02-1A Fluid Nozzle 0.8 1 1207-16A Fluid Needle 0.8 1
1207A-02-1B Fluid Nozzle 1.0 1 1207-16B Fluid Needle 1.0 1
1207A-02-1C Fluid Nozzle 1.2 1 1207-16C Fluid Needle 1.2 1
3A 1207-03A Needle Packing Set [Incl. 3 & 4] 1 17 1207-17 Needle Spring 1
5 1207A-05 Body Set [Incl. 2-2] 1 18 1207-18 Fluid Adj. Knob 1
6 1207-06 Fluid Nipple 1 19 1207-19 Air Inlet Nipple 1
7 1207-07 Pattern Adj. Set 1 20 1207-20 Air Adj. Set 1
8 1207-08 Air Valve Shaft 1 21 1207-21 Trigger 1
9 1207-09 Packing Holder 2 22 1207-22 Gasket 2
10 1207-10 O-Ring 2 23 1207-23 Trigger Stud 1
11 1207-11 Gasket 1 24 1207-24 E-Ring 1
1207-12 Air Valve Seat Set 25 1207-25 Spanner 1
1207-12-1 O-Ring 26 1207-26 Filter 1
1207 13
AiVl S tSt
27
1207 27
Pl ti C 125
1
1
2-1 16
12
1207-13
A
ir Valve Seat Set 27 1207-27 Plastic Cup 125cc 1
1207-13-1 O-Ring 28 1207-28 Cover 1
14 1207-14 Air Valve Spring 1 30 1207-30 Plastic Grip Brush 1
SS-1207A-P-1909G-GW
13 1
