Sumake S Series User manual

SUMAKE PNEUMATIC TOOLS
Air Drive Coil Carton Stapler
CR-19S
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
Noise and Vibration:
Vibration
ISO 8662-11:1999
Noise
EN 12549:1999
EN ISO 4871
Remark
No Load:
1.3 m/s²
Sound Pressure Level
load: 89 dB(A)
Please always
wear ear
protector at
environment
noise level >
80 dB(A) due
to risk of
impaired
hearing!
Sound power level
load: 100 dB(A)
Uncertainty
K= 1.5 m/s²
Uncertainty
K= 3dB
Specification:
Type
S series
Shank
0.9x1.9mm
Nail Length
15mm & 18mm
(5/8” & 7/10”)
Tool Length (HxWxL)
230 x 115 x 233 mm
Tool Weight
2.38 kg (5.23 lbs)
Load Capacity
1000 pcs
CR-19S-S-2108A-CJF

INSTRUCTION MANUAL
ITEM NO.:CR-19I, CR-19S, CR-19T
CR-23I, CR-23IA
AIR DRIVE COIL CARTON STAPLER
CR-19I(19S)(19T)(23I)(23IA)-I-1305B-CJ

4
SAFETY INSTRUCTIONS
DANGER
1.READ THIS MANUAL AND UNDERSTAND ALL SAFETY INSTRUCTIONS
BEFORE OPERATION THE TOOL. IF YOU HAVE ANY QUESTIONS, PLEASE
CONTACT OURAUTHORIZED REPRESENTATIVES.
2.NEVER ALLOW TO USE TYPE OF FLAMMABLE GASES OXYGEN AS A
POWER SOURCE FOR THE TOOL. USE FILTERED, LUBRICATED,
REQULATED COMPRESSEDAIR ONLY.
3.NEVER USE GASOLINE OR OTHER FLAMMABLE LIQUIDS TO CLEAN
THE TOOL. VAPORS IN THE TOOL WILL IGNITE BY A SPARK AND
CAUSE THE TOOLTO EXPLODE.
4.DO NOT EXCEED MAXIMUM PERMISSIBLE OPERATING PRESSURE OF
THE TOOL (8 KG/Cm2)
5.DISCONNECT THE TOOL FROM AIR SUPPLY BEFORE CLEANING JAMS,
SERVICING, ADJUSTING, AND DURING NON-OPERATION.
WARNING
6.DO NOT PULL THE TRIGGER WHEN CARRYING OR HOLDING THE TOOL.
NEVER CARRY THE TOOL BY THE HOSE OR PULL THE HOSE TO MOVE
THE TOOL.
7.AT THE WORKPLACE, ALWAYS WEAR THE PROTECTIVE EQUIPMENT
SUCH AS SAFETY GLASSES, HEARING PROTECTION AND HEAD
PROTECTION.
8.DO NOT USE ACHECK VALVE OR ANY OTHER FITTING WHICH ALLOWS
AIR TO REMAIN IN THE TOOL.
9.DO NOT PLACE YOUR HAND OR ANY PART OF YOUR BODY IN THE
STAPLE CLINCHING AREA OR ADJUSTMENT WINDOW OF THE TOOL
WHEN CONNECTING OR DISCONNECTING AIR SUPPLY.
10. NEVER POINT ANY OPERATIONAL DRIVING TOOL AT YOURSELF OR
ATANY OTHER PERSON.

5
LUBRICATION AND MAINTENANCE
NOTE
YOUR TOOL REQUIRES LUBRICATION BEFORE YOU USE IT FOR THE FIRST
TIME.
DISCONNECT THE AIR SUPPLY FROM THE TOOL BEFORE LUBRICATING.
TURN THE TOOL SO THE INLET IS FACING UP AND PUT ONE DROP OF HIGH
SPEED SPINDLE OIL, UNOCAL RX22, OR 3-IN-1 OIL INTO AIR INLET. NEVER
USE DETERGET OIL ADDITIVES. OPERATE THE TOOL BRIEFLY AFTER ADDING
OIL.
WIPE OFF EXCESSIVE OIL AT THE EXHAUST, EXCESSIVE OIL WILL DAMAGE
ORINGS OF TOOL. IF IN-LINE OILER IS USED. MANUAL LUBRICATION
THROUGH THEAIR NILET IS NOT REQUIRED ON A DAILY BASIS.
AIR SUPPLY AND CONNECTIONS
NOTE
THE FOLLOWING ILLUSTRATION SHOWS THE CORRECT MODE OF
CONNECTION TO THE AIR SUPPLY SYSTEM WHICH WILL INCREASE THE
EFFICIENCYAND USEFULL LIFE OF THE TOOL.
MANYAIR TOOLUSERS FIND IT CONVENIENT TO USE OILER TO HELP PROVIDE
OIL CIRCULATION THROUGH TOOL AND INCREASE THE EFFICIENCY AND
USEFUL LIFE OF THE TOOL. CHECK OIL LEVEL IN THE OILER DAILY.
MANY AIR TOOL USER FIND IT CONVENIENT TO USE A FILTER TO REMOVE
LIQUID IMPURITIES WHICH CAN RUST OR WEAR INTERNAL PARTS OF THE
TOOL. A FILTER ALSO INCEREASE THE EFFICIENCY AND USEFUL OF THE
TOOL. THE FILTER MUST BE CHECKED ON A DAIL BASIS AND IF NECESSARY
DRAINED.

6
LOADING THE TOOL
DISCONNECT THE AIR SUPPLY
SLIGHTLY SQUEEZE COVER (044) BACK THEN PULL TO OPEN
COVER(044)
PLACE COIL STAPLES IN MAGAZINE. FEED FRONT END OF
COIL STAPLES INTO RIGHT COIL GUIDE (037), LEFT COIL
GUIDE (038), AND TOP GUIDE (035). PUSH FORWARD UNTIL
STOPPING IN DRIVER GUIDE UNIT (027).
SWING COVER CLOSEDAND SLIGHTLY SQUEEZE TO ENGAGE
MAGAZINE BOSSES.
NOTE : CHECK POSITION ENGAGEMENT.

7
CHECK STAPLE LENGTH
NOTE : DISCONNECT THE AIR SUPPLY
LOOSEN SET SCRCW (526) WITH 3MM HEXAGON WRENCH
KEY.
TURN ADJUSTING ROD (018)180°WITH A SCREW DRIVER TO
THE DESIRED ADJUSTMENT.
IF WANT TO SHOOT LONG LEG STAPLES. LET “L” ON
ADJUSTING ROD (018) UP. IF WANT TO SHOOT SHORT LEG
STAPLES, LET “S” ONADJUSTING ROD (018) UP.
IF WANT TO SHOOT LONG LEG STAPLES. LOOSEN ROUND
HEAD SCREW (542) WITH SCREW DRIVER. MOVE RIGHT
COIL GUIDE (017) AND LEFT COIL GUIDE (038) OUT. THEN
SET ROUND SCREW (542).
IF WANT TO SHOOT SHORT LEG STAPLES. LOOSEN ROUND
HEAD SCREW (542) WITH SCREW DRIVER. MOVE RIGHT
COIL GUIDE (017) AND LEFT COIL GUIDE (038) IN. THEN SET
ROUND HEAD SCREW (542).

8
CLINCH ADJUSTMENT
NOTE : DISCONNECT THE AIR SUPPLY
USE ROD(DIA 3 MM) OR 2.5G MM HEXAGON WRENCH KEY.
TURN COLLAR (006) THROUGH WINDOW CLOCKWISE TO
TIGHTEN CLINCH AND COUNTER-CLOCKVIDE TO LOOSEN
CHINCH.
NOTE : REMOVE ADJUDTING TOOL AFTER ADJUSTMENT IS
MADE.
DEPTH ADJUSTMENT
NOTE : DISCONNECT THE AIR SUPPLY
LOOSEN FRONT SCREW (527) WITH 6 MM HEXAGON WRENCH
KEY.
PUSH THE BODY (007) UPAND ADJUST TO DESIRED DEPTH.
WHEN TOP EDGE OF ADJUSTMENT PLATE (019) IS AT ITS
HIGHEST SETTING (NO.4), THE TEETH (021,022) ARE AT THEIR
SHALLOWEST PENETRATION. IF SET AT LOWEST SETTING
(NO.1) THE TEETH (021,022) ARE AT THEIR DEEPEST
PENETRATION.

9
OPERATING THE TOOL
PROTECT YOUR EYES AND EARS. WEAR SAFETY GLASSES WITH SIDE
SHIELDS. WEAR HEARING PROTECTION. EMPLOYERS AND USERS ARE
RESPONSIBLE FOR ENSURING THE USER OR ANYONE NEAR THE TOOL
WEAR THIS SAFETY PROTECTION.
TO PREVENTACCIDENTAL INJURIES : NEVER, PLACE A HAND OR ANY OTHER
PART OF BODY IN STAPLE CLINCHING AREA OR ADJUSTMENT WINDOW.
NEVER POINT TOOL TOWARD ANYONE ELSE. NEVER ENGAGE IN
HORSEPLAY. ALWAYS HANDLE THE TOOL WITH CARE. NEVER PULL
TRIGGER UNLESS TOOL IS IN PLACE OF CARTON.
CHECK AND REPLACE ANY DAMAGED OR WORN COMPONENTS ON THE
TOOL. THE SAFETY WARNING LABELS ON THE TOOL MUST ALSO BE
REPLACED IF THEYARE NOT LEGIBLE.
ADD A FEW DROPS OF UNOCAL R * 22 OR 3-IN –1 OIL INTO THEAIR INLET.
INSTALLA QUICK CONNECT FITTING TO THE TOOL
REAULATE THE AIR PRESSURE TO OBTAIN 6 KG/Cm2AT THE TOOL
INSERT STAPLES INTO YOUR TOOL FOLLOWING THE INSTRUCTIONS OF
LOADING THE TOOL.
RECONNECT THEAIR HOSE TO THE TOOL
WARNING
WARNING
NOTE

10
GRASP HANDLE WITH ONE HAND. POSITION ON BOX IN LINE WITH THE
DESIRED STAPLE LOCATION. THERE IS A SMALL PROJECTION ON EITHER
SIDE OF THE MAGAZINE SEAT (039) AS AN AID IN LOCATING THE POSITION
OF THE STAPLE.
PRESS TRIGGER (011) MOVE MACHINE TO NEXT STAPLE LOCATION WITH OR
WITHOUT RELEASING TRIGGER.
STRONGEST CLOSURE REQUIRES END STAPLES CLOSE TO END OF BOX.
CHECK PACKING REQUIREMENTS.
CHECK STAPLE CLINCHING IN SAMPLES OF BOX BOARD BEING USED.
ADJUSTMENTS FOR DEPTH OF PENETRATION & TIGHTNESS OF CLINCH ARE
EASY & INSTANTANEOUS, FULLADVANTAGE SHOULD BE TAKEN OF THEM.
CLEANING THE TOOL
DANGER
NEVER USE GASOLINE OR OTHER FLAMMABLE LIQUIDS TO CLEAN THE
TOOL. VAPORS IN THE TOOL WILL IGNITE BY A SPARK AND CAUSE THE
TOOL TO EXPLODE AND RESULT IN DEATH OR SERIOUS PERSONAL INJURY.
1.DISCONNECT THE AIR SUPPLY FROM THE TOOL.
2.REMOVE TAR BUILDUP WITH KEROSENE #2 FUEL OIL OR DIESEL FUEL.
DO NOT ALLOW SOLVENT TO GET INTO THE CYLINDER OR DAMAGE MAY
OCCUR. DRY OFF THE TOOL COMPLETELY BEOFRE USE.

11
CLEARING A JAM FROM THE TOOL
DISCONNECT THE AIR SUPPLY.
PRESS DOWN LEVER (043).
INSERT LONG NOSE PLIERS OR SCREW DRIVER TO CLEAR
JAM.
PULL BACK LEVER (043).

12
TROUBLESHOOTING
WARNING
STOP USING THE TOOL IMMEDIATELY IF ANY OF THE FOLLOWING PROBLEMS OCCUR.
SERIOUS PERSONAL INJURY COULD OCCUR. ANY REPAIRS OR REPLACEMENTS MUST BE
DONE BYAQUALIFIED PRESONORANAUTHORIZEDSERVICECENTERONLY.
PROBLEM CAUSE REMEDY
AIR LEAKAGE FROM TRIGGER. O-RINGS ON VALVE (016)OR
ON TUBE (017) ARE
DAMAGED. O-RINGS MUST BE REPLACED.
O-RINGS ON VALVE (016) OR
ON TUBE (017) ARE
DAMAGED. O-RINGS MUST BE REPLACED.
AIR LEAKAGE FROM EXHAUST
PORT. PISTON’S O-RING
(507) IS DAMAGED. O-RING MUST BE REPLACED.
AIR LEAKAGE FROM
CYLINDER. PISTON ROD PORT O-RING IS DAMAGED. REPLACE THE O-RING.
SLOW AND SHORT TRAVEL
CYCLING
CHECK FOR LOOSEND
SCREW (517) AND WEAR OF
PARTS (014, 009)
POSITION ECCENTRIC PIN (013)
AS SHOWN AND TIGHTEN
SCREW (517) RECHECK, FOR
MAXIMUM EFFICIENCY, SLIGHT
ADJUSTMENT OF PIN AT THE
POSITION SHOWN MUST BE
MADE UPWARD DIRECTION IF
SHORT TRAVEL OCCURS AND
DOWNWARD DIRECTION IF
SLOW CYCLING OCCURS.
SLOW AND SHORT TRAVEL
CYCLING.
CHECK AS NOTED IN SLOW
AND SHORT TRAVEL CYCLING
SECTION.
TEETH SCREWS LOOSE. TIGHTEN SCREWS
STAPLE SIZE IS WRONG. USE THE PROPER SIZE STAPLE
EXCESSIVE JAMS:
INSUFFCIENT LUBRICATION. CLEANING AND LUBRICATION
SUITABLY.
UNEVEN CLINCH WRONG STAPLE SIZE. CHECK FOR PROPER LEG
LENGTH & ADJUSTMENT
CLINCHER.
TEETH (021,022) LOOSE TIGHTEN TEETH (021,022)
TEETH (021,022)ARE REPLACE TEETH (021,022)
UNCLINCHED STAPLE
SLOW AND SHORT TRAVEL
CYCLING.
CHECK AS NOTED IN SLOW
AND SHORT TRAVEL CYCLING
SECTION.

13
NOTE : DISCONNECT THE AIR SUPPLY.
LOOSEN SCREWS (530) WITH 4 MM HEXAGON WRENCH KEY.
REMOVE THE MAGAZINE (039)ASSEMBLY.
LOOSEN SCREWS (532) WITH 3 MM HEXAGON WRENCH KEY.
CHANGE TEETH ONE ATA TIME TO PREVENT REVERS TEETH.
TEETH REPLACEMENT

14
DRIVER REPLACEMENT
NOTE : DISCONNECT THE AIR SUPPLY.
LOOSEN SCREWS (530) WITH 4 MM HEXAGON WRENCH KEY.
REMOVE THE MAGAZINE (039)ASSEMBLY.
LOOSEN SET SCREW (526) WITH 3 MM HEXAGON WRENCH
KEY TO UNLOCK ADJUSTING ROD (018)
SLIDE LINKAGE MECHANISM AND ADJUSTING ROD (018)
SIMULTANEOUSLY FROM COLLAR (006)
LOOSEN SCREWS (535) WITH 3 MM HEXAGON WRENCH KEY.
TAKE OFF THE SPRING PIN (537) WITH HAMMER AND 6 MM
STRAIGHT ROD.

15
VALVE’SAND TUBE’S O-RINGS REPLACEMENT
NOTE : DISCONNECT THE AIR SUPPLY
LOOSEN SCREWS (513) WITH FLAT SCREW DRIVER.
REMOVE SPRING (012) WITH LONG NOSE PLIERS.
REMOVE C-Ring (545) WITH C-Ring Pliers.
REMOVE VALVE (017) AND TUBE (016) WITH A LONG NOSE
PLIERS.

16
PISTON REPLACEMENT
NOTE : DISCONNECT THE AIR SUPPLY.
REMOVE SCREWS (530) WITH 4 MM HEXAGON WRENCH KEY.
REMOVE THE MAGAZINE (039)ASSEMBLY.
LOOSEN SET SCREW (526) WITH 3 MM HEXAGON WRENCH
KEY TO UNLOCK ADJUSTING ROD (018).
SLIDE LINKAGE MECHANISM AND ADJUSTING ROD (018)
SIMULTANEOUSLY FROM COLLAR (006).
LOOSEN COLLAR (006) WITH 3 MM STRAIGHT ROD.
REMOVE SPRING (005).
LOOSEN SCREW (510) WITH 3 MM HEXAGON WRENCH KEY.
REMOVE BLOCK (004) THROUGH WINDOW.
LOSSEN SCREWS (501) WITH 3 MM HEXAGON WRENCH KEY.
REMOVE CAP (001).
REMOVE PISTON ASSEMBLY.
LOOSEN NUT (504) WITH 10 MM SPANNER.
REMOVE PISTON (002)AND EXCHANGE A NEW ONE.

ECDECLARATION OF CONFORMITY
We: SUMAKE INDUSTRIAL CO., LTD.
4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan
declare in sole responsibility that the equipment
Equipment：AIR DRIVE COIL CARTON STAPLER
Model/ Serial No.：CR-19S
to which this declaration applies, complies with these normative documents:
Machinery Directive: 2006/42/EC
and conforms to the following EN standard,
EN ISO 12100: 2010
EN 792-13:2000+A1:2008
Name and Signature/Position Date and Place
2014/5/12
Mike Su –Managing Director Taipei, Taiwan
CR-19S-D-2108A-CJF

CR-19I
,
CR-19S
,
CR-19T
,
CR-23I
,
CR-23IA
AIR DRIVE COIL CARTON STAPLER
CR-19I
(
19S
)(
19T
)(
23I
)(
23IA
)
-P-1305B-CJ

CR-19I
,
CR-19S
,
CR-19T
,
CR-23I
,
CR-23IA
AIR DRIVE COIL CARTON STAPLER
PARTS LIST
No. Parts No. Descri
p
tion Q't
y
No. Parts No. Descri
p
tion Q't
y
1 CR19I-01 Ca
p
1 CR19I-41 Washer
[
For CR-19I, CR-19T
]
1
2 CR19I-02 Piston 1 CR19S-41 Washer
[
For CR-19S
]
1
3 CR19I-03 Piston Rod 1 CR23I-41 Washer
[
For CR-23I, CR-23IA
]
1
4 CR19I-04 Bloc
k
1 42 CR19I-42 Shaft 1
5 CR19I-05 S
p
rin
g
1 43 CR19I-43 Leve
r
1
6 CR19I-06 Colla
r
1 44 CR19I-44 Cove
r
1
7 CR19I-07 Bod
y
Uni
t
1 45 CR19I-45 Plate 2
CR19I-08A
A
ir Plu
g
(
Ja
p
anese T
yp
e
)
1 47 CR19I-47 Washe
r
1
CR19I-08B
A
ir Plu
g
(
U.S.A. T
yp
e
)
1 48 CR19I-48 Silence
r
1
CR19I-08C
A
ir Plu
g
(
Euro
p
ean T
yp
e
)
1 50 CR19I-50 Washe
r
1
9 CR19I-09 Bloc
k
1 51 CR19I-51 Washe
r
1
10 CR19I-10 S
p
rin
g
1 52 CR19I-52 Cove
r
1
11 CR19I-11 Tri
gg
er 1 53 CR19I-53 Shaft 1
12 CR19I-12 S
p
rin
g
1 501 CR19I-501 Hex.Soc.Hd.Bolt
(
M4x0.7-14
)
4
13 CR19I-13 Rod 1 503 CR19I-503 O-Rin
g
(
Φ1.78xΦ2.9
)
1
14 CR19I-14 Tri
gg
er's Control 1 504 CR19I-504 Hex.Nut
(
M6x1
)
1
15 CR19I-15 S
p
rin
g
1 505 CR19I-505 Washer
(
1/4"x5/8"x1T
)
1
16 CR19I-16 Valve 1 506 CR19I-506 O-Rin
g
(
Φ1.78xΦ7.65
)
1
17 CR19I-17 Tube 1 507 CR19I-507 O-Rin
g
(
Φ5.7xΦ47.6
)
1
18 CR19I-18
A
d
j
ustin
g
Rod 1 508 CR19I-508 Washer
(
Φ8xΦ23 x1.6T
)
1
19 CR19I-19
A
d
j
ustin
g
Plate 1 510 CR19I-510 Hex.Soc.Hd.Bolt
(
M4x0.7-10
)
1
CR19I-20 Front Plate [For CR-19I, CR-19S, CR-19T, CR-23I] 1 511 CR19I-511 S
p
rin
g
Pin
(
Φ2.5-14
)
1
CR23IA-20 Front Plate
[
For CR-23IA
]
1 512 CR19I-512 O-Rin
g
(
Φ1.78xΦ3.69
)
1
CR19I-21 Ri
g
ht Teeth
[
For CR-19I, CR-19T, CR-23I
]
1 513 CR19I-513 Tri
gg
er Screw
(
M4x0.7-7
)
2
CR19S-21 Teeth
[
For CR-19S
]
1 514 CR19I-514 S
p
rin
g
Washer
(
M4
)
2
CR23IA-21 Ri
g
ht Teeth
[
For CR-23IA
]
1 515 CR19I-515 S
p
rin
g
Pin
(
Φ3-20
)
1
CR19I-22 Left Teeth
[
For CR-19I, CR-19T, CR-23I
]
1 516 CR19I-516 Outside Teeth Washer
(
M4
)
1
CR23IA-22 Teeth
[
For CR-23IA
]
1 517 CR19I-517 Hex.Soc.Hd.Bolt
(
M4x0.7-10
)
1
CR19S-22 Teeth
[
For CR-19S
]
1 518 CR19I-518 S
p
rin
g
Pin
(
Φ3-10
)
1
23 CR19I-23 Teeth Sea
t
2 519 CR19I-519 O-Rin
g
(
Φ1.78xΦ12.42
)
1
24 CR19I-24 Plate 2 520 CR19I-520 O-Rin
g
(
Φ1.78xΦ7.65
)
2
CR19S-25 Driver
[
For CR-19S
]
1 521 CR19I-521 O-Rin
g
(
Φ1.6xΦ14.5
)
1
CR19I-25 Driver
[
For CR-19I, CR-19T
]
1 522 CR19I-522 O-Rin
g
(
Φ1.6xΦ15
)
1
CR23I-25 Driver
[
For CR-23I, CR-23IA
]
1 523 CR19I-523 O-Rin
g
(
Φ1.6xΦ15.5
)
1
CR19I-27 Driver Guide Unit
[
For CR-19I, CR-19T
]
1 524 CR19I-524 O-Rin
g
(
Φ1.6xΦ16
)
1
CR19S-27 Driver Guide
[
For CR-19S
]
1 525 CR19I-525 Rod
(
Φ4.9-23
)
2
CR23I-27 Driver Guide
[
For CR-23I, CR-23IA
]
1 526 CR19I-526 Hex.Soc.Hdless.Bolt
(
M6x1-14
)
1
CR19I-29 Anvil [For CR-19I, CR-19T, CR-23I, CR-23IA] 1 527 CR19I-527 Hex.Soc.Hd.Bolt
(
M8x1.25-16
)
1
CR19S-29
A
nvil
[
For CR-19S
]
1 528 CR19I-528 S
p
rin
g
Pin
(
Φ5-14
)
2
CR19I-30 Pusher
[
For CR-19I, CR-19T, CR-23I
]
1 529 CR19I-529 S
p
rin
g
Pin
(
Φ3-10
)
4
CR19S-30 Pusher
[
For CR-19S
]
1 530 CR19I-530 Hex.Soc.Hd.Bolt
(
M5x0.8-14
)
6
CR23I-30 Pusher
[
For CR-23I, CR-23IA
]
1 531 CR19I-531 Lock Nut
(
M5x0.8
)
1
31 CR19I-31 S
p
rin
g
2
32 CR19I-32
A
nvil Ca
p
1
33 CR19I-33 S
p
rin
g
1 CR19S-532 Hex.Soc.Flat Counter Snk Hd.Screw (M5x0.8-14) [For CS-39S] 2
34 CR19I-34 Plate 1 533 CR19I-533 Pin
(
Φ3.98-13
)
4
35 CR19I-35 To
p
Guide 1 534 CR19I-534 Pin
(
Φ6.05-8
)
2
36 CR19I-36 Leaf S
p
rin
g
1 537 CR19I-537 S
p
rin
g
Pin
(
Φ6-16
)
2
CR19I-37 Ri
g
ht Coil Guide
[
For CR-19S
]
1 538 CR19I-538 S
p
rin
g
Pin
(
Φ4-22
)
3
CR23I-37 Ri
g
ht Coil Guide
[
For CR-23I, CR-23IA
]
1 540 CR19I-540 Hex.Soc.Hd.Bolt
(
M5x0.8-20
)
1
CR19T-37 Ri
g
ht Coil Guide
[
For CR-19T
]
1 541 CR19I-541 Hex.Soc.Flat Counter Snk Hd.Screw (M5x0.8-8) 4
CR19S-37 Ri
g
ht Coil Guide
[
For CR-19S
]
1 542 CR19I-542 Round Hd.Screw
(
M3x0.5-6
)
4
CR19I38 Left Coil Guide
[
For CR-19I
]
1 543 CR19I-543 E-Rin
g
(
Φ2.5
)
2
CR23I-38 Left Coil Guide
[
For CR-23I, CR-23IA
]
1 544 CR19I-544 S
p
rin
g
Pin
(
Φ4-20
)
1
CR19T-38 Left Coil Guide
[
For CR-19T
]
1 545 CR19I-545 C-Rin
g
(
Φ20
)
1
CR19S-38 Left Coil Guide
[
For CR-19S
]
1 546 CR19I-546 E-Rin
g
(
Φ2.5
)
1
CR19I-39 Magazine Seat [For CR-19I, CR-19S, CR-19T] 1 548 CR19I-548 Plastic Pin 1
CR23I-39 Ma
g
azine Seat
[
For CR-23I, CR-23IA
]
1 549 CR19I-549 Wave Washer
(
Φ10
)
1
40 CR19I-40 Shaft 1 551 CR19I-551 Hex.Soc.Flat Counter
(
M4x0.7-12
)
3
CR-19I
(
19S
)(
19T
)(
23I
)(
23IA
)
-P-1305B-CJ
CR19I-532 2
Hex.Soc.Flat Counter Snk Hd.Screw (M5x0.8-12)
[For CR-19I, CR-19T, CR-23I, CR-23IA]
29
30
37
38
21
22
25
27
8
20
39
41
532

NOTE
www.SUMAKE.com
www.AIRCOMPRESSOR.com.tw
