Sundstrom SR562 Installation and user guide

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 1

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 2
…assemble the SR562 head-top
BEFORE YOU START:
Check that the equipment is complete in
accordance with the packing list and has not
been damaged in transport.
Packing list:
•Hood with breathing hose.
•User instructions
•Cleaning tissue
Place the head top in the flow meter and start
the fan unit.
Grip the lower part of the bag to seal around the
breathing hose.
Grip the flow meter tube with the other hand so
that the tube points vertically upwards from the
bag.
Read the position of the ball in the tube. This
should hover at a level with or slightly above the
upper marking on the tube.
If minimum flow is not achieved, check that:
–The flow meter is held upright.
–The ball moves freely.
–The bag seals well around the hose.
Check that the O-ring of the hose is in place

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 3
Connect the hose to the fan unit and turn it
clockwise about 1/ 8 of a turn.
…put on the hood
Grip the hose mounting with one hand and the
neck section of the hood with the other. Insert
your chin into the hood. Keep your grip of the
hood and draw it over your head.
Adjust the hood so that it seals all the way round
your face and fits closely and comfortably. The
rubber band in the face seal can be adjusted to
the required length.
If necessary, adjust the circumference of the
head harness by means of the knob at the rear of
the head harness.
The knob is on the inside of the hood behind the
hose. You can reach it without taking off the
hood. Turn clockwise to tighten and counter
clockwise to widen.

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 4
If necessary, adjust the head harness in height by
lengthening or shortening the strap for the top
of the head.
Make sure that the breathing hose runs along
your back and is not twisted.
…remove the hood
Leave the polluted area before taking the
equipment off.
Slacken the neck band. In emergency situations,
the hood can be taken off with the rubber band
tightened.
Take the hood off. Switch off the fan, release the
belt and take the fan unit off.

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 5
…clean the head-top
Sundström cleaning tissues SR 5226 that clean
and disinfect are recommended for daily care.
If the equipment is more heavily fouled, use a
soft brush or sponge moistened with a solution
of water and dishwashing detergent or the like.
Rinse the equipment and leave it to dry.
N.B. Never use a solvent for cleaning.
…store the head-top and parts
After cleaning, store the equipment in a dry and
clean place at room temperature. Avoid
exposing it to direct sunlight. The flow meter can
be turned inside out and can be used as storage
bag for the head-top.
…schedule maintenance
The schedule represents the minimum
requirements for maintenance routines in order
to ensure that equipment will always be in
functional condition.

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 6
…change the sweatband
The sweatband is secured with velcro tape to the
forehead band. Proceed as follows: Pull the
sweatband off.
Fit the velcro strip with the ruffled side towards
the forehead strap and with relief upwards.
…change the Tyvek hood
Release the face seal rubber band secured to the
forehead band next to the Velcro tapes.
Remove the Velcro tapes.
Release the three press studs at the top edge of
the visor.

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 7
Lift the head harness out of the hood and
withdraw the hose.
Place the new hood in front of you, with the
visor facing up.
Thread the hose from the inside of the hood,
through the passage at the rear of the hood.
During this operation, the head harness should
rest with the opening facing upwards. Note that
the hose should not be drawn all the way
through, and around 20 cm should be left on the
inside of the hood.

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 8
Grip the front part of the head harness with one
hand and insert the head harness into the hood,
first inserting the rear part fitted with the hose.
Make sure that the Velcro tape is stretched
under the forehead band of the head harness.
Secure the hood by means of the press-studs at
the top edge of the visor.
Fold the Velcro tapes around the forehead band
and secure them as firmly as possible.
Take the face seal rubber band and insert the
knot into the keyhole opening in the head
harness.

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 9
Secure it by pulling the rubber band into the
narrow part of the slot.
Check that the head harness is straight in the
hood and that the hose passage of the hood is
not twisted around the hose.
…change the hose
Release the face seal rubber band secured to the
forehead band next to the Velcro tapes.
Remove the Velcro tapes.

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 10
Release the three press studs at the top edge of
the visor.
Lift the head harness out of the hood and
withdraw the hose.
Turn the locknut a quarter of a turn and remove
it. Use polygrip pliers if the lock nut is stiff to
turn.
Thread the pin on one side of the hose coupling
down through the recess in the head harness,
turn the hose through 180 degrees and insert
pin.
Pull the hose out of the hood.

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 11
One coupling of the hose is fitted with an o-ring.
Thread the new hose with this end first from the
inside of the hood, through the passage at the
rear of the hood.
Note that the hose should not be drawn all the
way through, and around 20 cm should be left
on the inside of the hood.
Fit the new hose to the head harness in the
reverse order.
Grip the front part of the head harness with one
hand and insert the head harness into the hood,
first inserting the rear part fitted with the hose.
Make sure that the Velcro tape is stretched
under the forehead band of the head harness
and secure them as firmly as possible.
Secure the hood by means of the three
press-studs at the top edge of the visor.

SR562 supplied-air hood —How to Copyright © 2020 by The S.E.A. Group 12
Fold the Velcro tapes around the forehand
band and secure them as firmly as
possible.
Take the face seal rubber band and insert
the knot into the keyhole opening in the
head harness.
Secure it by pulling the rubber band into
the narrow part of the slot.
Check that the head harness is straight in the
hood and that the hose passage of the hood is
not twisted around the hose.
…change the head harness
Follow relevant parts of the above instructions
dealing with changing the hose.
