Sunjoy S-GZ1182PST User manual

Pop up gazebo with extension roof
Use and Care Guide
S-GZ1182PST
Thank you for your purchase! We are pleased that you have chosen Sunjoy for your outdoor
furniture purchase.
Our clear, easy to follow, step by step instructions will guide you through the project from start
to finish.
Item identification: For ease of identification, all parts are labeled to correspond to the Step
number in which the part is used.
Production Number: xxxxxxxx

Part List
Hardware
Assembly instruction:
Fig.1 Take out the frame (A) from Bag (F).
。
Description Label Qty Image
Frame A 1
Big canopy B 1
Small canopy C 1
Connector 1 D 8
Connector 2 E 4
Bag F 1
Description Label Qty
Stake
φ5*170mm AA 8
Stake
φ7*210mm BB 4
Rope 3m CC 4
Fig. 1

Fig.2 Place the gazebo frame (A) upright and have four people holding the corner posts and
pulling outwards
Fig.3 Cover the big canopy(B）on frame（A），fix big canopy（B）to frame（A）by using
Velcro loop ( line up and close the short velcro firstly, then line up and close the long velcro).
Fig.4 Cover the small canopy（C）on frame（A）
Fig.5 Pull the gazebo post (A) upwards to the spring buckle to secure in place.
Fig.6 Fix the frame（A）on ground by using stake（AA）.
Fig.3
A
B

Fig.7 Insert connector (E) into the other end of the connector (D).
Fig.8 Insert the assembled connector (D）into the big canopy（B）.
Fig.9 Put the connector end（D）on frame support（A）.
Fig.10 Insert frame（A）support in the frame post（A）.

Fig11 Put the rope（CC）through big canopy loop and fix on ground by using stake (BB）.
Fig.12 Fix fourside rope on ground。
\
Fig.12

Warranty:
Six (6) months warranty
Thank you for purchasing this SUNJOY product. These products have been made to
demanding, high-quality standards and are guaranteed for domestic use against
manufacturing faults. This warranty does not affect your statutory rights.
The product is guaranteed if used for normal, residential purposes. Any warranty is invalid if
the product has been overloaded or subject to neglect, improper use or an attempted repair
other than by an authorized agent. Heavy-duty or daily professional/commercial usage is not
guaranteed. Due to continuous product improvement, we reserve the right to change the
product specifications without prior notice.
Care & Maintenance:
Our steel components for garden accessories and furniture are treated with rust inhibiting paint
that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will
occur if these protective coatings are scratched. This is not a defect and thus not covered by
the warranty.
To minimize this condition, we recommend care when assembling & handling the product to
prevent scratching the paint. Should any scratching or damage occur, we recommend
immediate touch-up with rust inhibiting paint.
Surface rust can also be easily removed with a very light application of common cooking oil. If
surface oxidation (rusting) occurs and if no measure is taken to prevent this, the oxidation may
start dripping onto deck or patio and caused damaging stains, which may be difficult to remove.
This can be prevented if the above-mentioned measures are taken to keep the product from
oxidizing.
Note: The gazebo’s roof and structure are not guaranteed against extreme weather
conditions (storms, high winds, etc.). If the gazebo is not dismantled for the winter, snow must
be cleaned off regularly. Any damage caused by snow accumulation is not covered by the
warranty.
Important
Please do not return this product to the store. For technical assistance or replacement parts,
please call Sunjoy Group at 1 [phone] between 8:00 AM EST and 8:00 PM PST. You
may fax your replacement parts form (which is included in the packaging) to 1 [phone]
or email to [email protected]
Made in china
2017-8
