Sunjoy L-GZ519PST-C User manual

Assembly manual
Item# L-GZ519PST-C

2
Table of contents
Important safety instructions..................................................................................................................................................2
Packaging content.......................................................................................................................................................................3
Assembly preparation................................................................................................................................................................4
Assembly instructions................................................................................................................................................................4
Cleaning and maintenance...................................................................................................................................................... 11
Technical data.............................................................................................................................................................................. 12
Warranty........................................................................................................................................................................................ 12
Important ........................................................................................................................................................................................ 12
Important safety instructions
Warning!
•To reduce the risk of serious injury, read the following safety instructions before assembling
and using the gazebo.
•This product is intended for domestic outdoor use only.
•The product should be placed on flat, horizontal ground.
•Ensure enough clearance around the product. Before assembling the product, find level ground not less
than 6' (1.8 m) away from any structures or obstructions, such as fences, garages, houses, overhanging
branches, laundry lines or electrical wires.
•The gazebo must be anchored with stakes onto the ground for added safety. It cannot be permanently
attached to a concrete floor or platform. Do not assemble the gazebo on sandy, muddy or loose soil,
as stakes do not have enough anchorage in these types of soil.
•If you set up more than one gazebo, keep a minimum distance of 10' (3 m) between the gazebos.
•Any assembly or maintenance of the product must be carried out by adults only.
•Arrange necessary manpower when assembling or moving the product.
•Some parts may contain sharp edges. Wear protective gloves if necessary.
•Keep children and pets away while setting up the gazebo.
•Check all nuts and bolts periodically for tightness. When required, tighten them again.
•Repairing and replacing parts should be done by a qualified technician.
•This gazebo is intended for sunshade purposes only, and is not designed to withstand harsh weather,
including high winds, rain and snow.
•Always remove the canopy in heavy wind conditions, otherwise it might tip over and cause damage to
the product or injuries to people nearby.
•Always ensure that the roof canvas is tensioned, so as to avoid water accumulation on the roof.
•Remove accumulated water on the roof canvas immediately or disassemble the gazebo in order to
avoid damage.
•If the product will not be used for a long period (e.g., winter time), it should be stored in a clean, dry
environment.
•Do not light fires inside or near the product!
•Stay calm if fire breaks out. Search for the nearest exit. Do not return to the gazebo before firefighters
allow you to do so.
•Do not hang any weights on the roof frame.
•Retain the original packaging for storing the gazebo.
•Caution! Always keep children under close supervision while they are using or around this product.
Never leave children unattended.
IMPORTANT: READ CAREFULLY AND RETAIN
FOR FUTURE REFERENCE.

3
Packaging content
Name Part # Qty Illustration Name Part # Qty Illustration
Pole A 4 Screw AA 48
M6x15
Stake
Connector B 8 Flat
Washer BB 136 M6
Fence C 8 Screw CC 12
M6x15
Fence
Pole D 8 Screw DD 16
M6x35
Long Bar 1 E 2 Screw EE 12
M6x40
Long Bar 2 E1 2 Nut FF 12
M6
Short Bar 1 F 2 Small
Plastic Ring GG 52
Short Bar 2 F1 2 Large
Plastic Ring HH 52
Long
Netting Tube G 4 Stake II 16 6x180
Short
Netting Tube H 4 Screw JJ 32
M6x25
M6x6
Top Bar 1 I1 2
Screw KK 8
Iron Panel U 4
Wrench W 1
Top Bar 2 I2 2
Top Bar
Connector J 4
Long
Top Bar K 4
Short
Top Bar K1 4
Large Top
Connector L 1
Small Top
Connector M 1
Small
Top Bar N 4
Finial O 8
Hook P 1
Small
Canopy Q 1
Large
Canopy R 1
Net S 1
Gazebo
Wall T 1

4
Assembly preparation
Place all parts from the box in a cleared area and position them on the floor in front of you.
Remove all packing materials and place them back in the box. Do not dispose of the packing
materials until assembly is complete. Read each step carefully before beginning assembly and
make sure you understand each step. If you are missing a part, please call our toll-free number
for assistance 1-866-578-6569
Caution!
•Proper placement of your gazebo is essential. Do not place the product underneath
electrical lines.
•Keep children away during assembly. This product contains small parts that can be
swallowed by children.
•Keep fingers away from the places where they can be pinched or trapped.
•Do not attempt to assemble the gazebo if any parts are missing.
You will need the following for assembly:
Assembly instructions
Note:
•When using screws and nuts to assemble the product, always use a Flat Washer (BB)
between the tube and the screw and/or nut. This is to protect the parts from tear and wear.
1
D
AA BB
O
AA
BB
(D) x 8
(O) x 8
(AA) x 16
(BB) x 16
Insert the Finials (O) into the Fence Poles (D), and fasten each one of them
with two M6x15 Screws (AA) and two M6 Flat Washers (BB).

5
Assembly instructions
2
D
JJ
A
B
C
JJ
AA
AA
BB
BB
BB
BB
BB
BB
JJ
JJ
(A) x 4
(B) x 8
(C) x 8
(AA) x16
(BB) x 48
(JJ) x 32
Connect the Fences (C) and the Stake Connectors (B)to the four Poles (A) on
one side and to the Fence Poles (D
M6x25 Screws (JJ) and four M6 Flat Washers (BB) on the upper portion of
the Fence, and two M6x15 Screws (AA) and two M6 Flat Washers (BB) on the
lower portion. The Fences (C) can be installed in whatever orientation the user
prefers.
3
A
CC
F1
F
A
A
A
D
B
C
F1/E1
F/E
J
CC
BBBB
E1
E
(E) x 2
(E1) x 2
(F) x 2
(F1) x 2
(J) x 4
(BB) x 8
(CC) x 8
Insert Short Bars 1 (F) into Short Bars 2 (F1), and Long Bars 1 (E) into Long Bars 2
(E1). Attach a Top Bar Connector (J) to the connecting points between the
Short and Long Bars (F, F1, E, and E1), and fasten with two M6x15 Screws (CC)
and two M6 Flat Washers (BB) on each Top Bar Connector (J).

6
Assembly instructions
4
AA
F1
F
F1/E1
F/E
AA
BB
BB
E1
E
H/G
H/G
(G) x 4
(H) x 4
(AA) x16
(BB) x 16
Attach the Short Netting Tubes (H) to Short Bars 1 and 2 (Fand F1), and
fasten with two M6x15 Screws (AA) and two M6 Flat Washers (BB). Follow
the same procedure to attach the Long Netting Tubes (G) to Long Bars 1 and
2 (Eand E1).
5
DD
F1
F
F/E
DD
BB
BB
E1
E
A
A
(BB) x 16
(DD)x16
F, F1, E, and E1) to the upper part
of the Poles (A), using two M6x35 Screws (DD) and two M6 Flat Washers
(BB)
for each corner.

7
Assembly instructions
6
K
CC
K1
BB
(K) x 4
(K1) x 4
(BB) x 4
(CC) x 4
Insert the Short Top Bars (K1) into the Long Top Bars (K), and fasten with one
M6x15Screw(CC)and one M6 Flat Washer (BB)for each one ofthe top barconnections.
7
K
P
I1
L
K
I2
(I1) x 2
(I2) x 2
(L) x 1
(P) x 1
Insert the Long Top Bars (K) and Top Bars 1 and 2 (I1 and I2) into the Large Top
Connector (L), alternating the bars as shown in the illustration above. Then
screw the Hook (P) into the Large Top Connector (L) until it is firmly secured.

8
Assembly instructions
8
EE
F1
FF BB
BB
E
A
K1
(BB) x 8
(EE) x 4
(FF) x 4
Insert the Short Top Bars (K1) into the U-shaped plates located in the upper
part of the Poles (A), securing each of the Short Top Bars (K1) with one
M6x40 Screw (EE), one M6 Nut (FF) and two M6 Flat Washers (BB).
Note: This step should beperformed together with step 7.
9
EE
F/E FF
BB
BB
J
I1/I2
F1/E1
(R) x 1
(BB) x 8
(EE) x 4
(FF) x 4
Insert Top Bars 1 and 2 (I1 and I2) into the U-shaped plates in the Top
Bar Connectors (J), securing each of the Top Bars (I1 and I2) with one M6x40
Screw (EE), one M6 Nut (FF) and two M6 Flat Washers (BB). Place the Large
Canopy (R) on top of the assembled frame, but do not lay it out completely
at this point.
Note: This step should be performed together with step 7 and 8.

9
Assembly instructions
0
N
M
N
N
(M) x 1
(N) x 4
Insert the Small Top Bars (N) into the Small Top Connector (M).

EE
FF
BB
K
N
R
(Q) x 1
(BB) x 4
(EE) x 4
(FF) x 4
Fasten the Small Top Bars (N) to the Long Top Bars (K), with one M6x40
Screw (EE), one M6 Nut (FF) and one M6 Flat Washer (BB) for each corner.
Place the Small Canopy (Q) on the assembled small top. Lay out both Canopies
(Q and R) completely at this point and tie them to the gazebo frame.

10
Assembly instructions
T
HH
S
GG
F1/E1/F/E
G/H
12 (S) x 1
(T) x 1
(GG) x52
(HH) x
(U) x 4
(BB) x 8
(KK) x 8
52
Attach the Small Plastic Rings (GG) to the Netting Tubes (G and H), and use
the Rings (GG) to hang the Net (S). Then attach the Large Plastic Rings (HH)
to the Short and Long Bars (F, F1, E, and E1), using the Rings (HH) to hang the
Gazebo Wall (T).
C
C
C
B
KK
BB KK
BB
B
UA
II
B
II
(II) x 16
Use the provided 6x180 Stakes (
Connect the Iron Panel (U) to Stake Connector (B),securing them with
eight M6x6 Screws (KK) and eight M6 Flat Washers (BB).
II) to attach the gazebo to the ground through the
Stake Connectors (B).
14
13

11
Assembly instructions
Now your gazebo is ready for use.
Enjoy!
Cleaning and maintenance
•Disassemble the gazebo in the reverse order of the assembly steps. Always disassemble the gazebo
completely. A partially disassembled gazebo is not stable enough to resist wind and bad weather, and
therefore can be damaged and/or cause damage.
•Clean the gazebo with mild soap and water. Rinse thoroughly, and wait until the product is dry before
reassembling it.
•For washing the fabric parts:
- Spread the fabric out and use a soft bristle brush to clean.
- Always use a natural soap, never detergent.
- Water should be cold to lukewarm, never more than 25°C (77°F).
- Air dry only. Do not spin in washing machine or hand squeeze.
•Do not use bleach, acid, or other abrasive cleaners on the canopies or frame parts.
•Steel components of garden accessories and furniture are treated with rust-inhibiting paint. However,
due to the nature of steel, surface oxidation (rusting) will occur if this protective coating is scratched.
This is a natural process. To minimize this condition, it is recommended that care be taken when
assembling and handling the product, in order to prevent the paint from being scratched. Surface rust
can be removed easily using a very light application of common cooking oil. If surface oxidation occurs
and no measures are taken to correct it, the oxidation may start dripping onto the assembly surface,
15

12
Technical data
Dimensions (L x W x H) : 144 x 120 x 111 1/2" (366 x 305 x 283 cm)
Product weight : 152 lb (69 kg)
W
Important
arranty
T
Please do not return this product to the store. For technical assistance on assembly or replacement
parts. Please call Sunjoy Industries at 1-866-578-6569 from 8:00 am EST to 8:00 pm PST or fax the
replacement part form which is in the box to 1-740-283-3549 or Email [email protected]
for assistance.
his product carries a one (1) year warranty against defects in workmanship and materials.
Sunjoy agrees to replace the defective product free of charge within the stated warranty
period, when returned by the original purchaser with proof of purchase. This product is not
guaranteedagainst wear or breakage due to misuse and/or abuse.
Made in China
2016-4
