Sunjoy L-PG044PST User manual

NOTE: THIS UNIT IS HEAVY! For safety, DO NOT assemble this item alone. 4 people
are recommended for safe assembly.
WARNINGS:
Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the assembly area of the gazebo.
Some parts may contain sharp edges. Wear protective gloves.
When assembling and using this product, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment. Please read all
instructions before assembly and usage.
For outdoor use only. Install on level ground.
Check all bolts for tightness before and during usage.
Post Screen A 2
Post Screen B 2
Post Screen C 2
Post Screen D 2
Beam Screen E 2
Side Panel F 2
Top Screen G 6
Connect Bar H 2
Parts List
Note: It is recommended to use 4 people to complete the assembly steps.
It is recommended to use 2 ladders taller than 8.2 ft / 2.4 m when installing the top screens.
Garden Pavilion
ITEM#L-PG044PST
ASSEMBLY INSTRUCTIONS

AA M6X15 Bolt
TBZ00106015HQ 8 PCS
BB M6 Washer
TBZ10406HQ 8 PCS
CC M6X65 Bolt
TBZ00108040HQ 20 PCS
DD M6 Nut
TBZ20108HQ 20 PCS
GG M6 Washer
TBZ10408HQ 40PCS
W M6 Wrench 2 PC
Hardware Pack 1
Fig.1: Unfold the Side Panel F and keep it flat by the Connecting Bar H, the Bolt AA and the Washer BB. See
Fig.1A
Fig.1B: Place the unfold Side Panel F on a flat surface, attach it to the Post Screen C and the Post Screen D at
the two ends of the Side Panel F with the Bolt CC and the Washer GG. See Fig.1B.
Fig.2: Attach the Post Screen A to the Post Screen C with the Bolt CC and the Washer GG. Repeat the same step
to attach the Post Screen B to the Post Screen D.

AA M6X15 Bolt
TBZ00106015HQ 4 PCS
BB M6 Washer
TBZ10406HQ 4 PCS
CC M6X65 Bolt
TBZ00108040HQ 8PCS
DD M6 Nut
TBZ20108HQ 8 PCS
GG M6 Washer
TBZ10408HQ 16PCS
8
Hardware Pack 2
Fig.4: Unfold the Beam Screen E and keep it flat by the Bolt AA and Washer BB. See Fig.4
Fig.5: Attach the Beam Screen E to Post Screen A and Post Screen B with Bolt CC, the Nut DD and Washer
GG. See Fig. 5.

E
Step 3:
Step 6: Unfold Top Screen (G) and securely attach it with Bolt (CC) and Flat Washer (BB). See Fig.4A.
Repeat until all 6pc of Top Screens (G) are assembled.
Step 7: Attach both ends of assembled Top Screens (G) to Semicircular Screen (F) with Bolt (DD) and Flat
Washer (BB). See Fig. 4B. Repeat until all 6 Top Screens (G) are attached to semi-circular screens.
Step 8: Fasten the assembled pavilion to the lawn with Stakes (EE). See Fig. 4C.
For technical assistance on assembly or replacement parts, please call Sunjoy Industries at 1(866) 578-6569
from 8:30 AM to 5:30 PM EST Monday to Friday or fax the replacement part form which put into the package
to (740)-283-3549 or Email [e-mail] for assistance.
MADE IN CHIA
BB M6 Flat Washer 48 PCS
CC M6X15Bolt 24 PCS
DD M6X30 Bolt 24 PCS
EE Φ8*260MM Stake 8 PCS
Hardware Pack 3
Important: Pleasedo not return this product to the store.
