Sunjoy A102007901 User manual

Country of Origin: China Production Number: XXXXXXXXXX
ASSEMBLY INSTRUCTION
ITEM#：A102007901
WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
[email protected]

∙ 2/24
CountryofOrigin:China
Caution!Properplacementofyourgazeboisessential.
Donotplacetheproductunderneathelectricallines.
Keepchildrenawayduringassembly.
Thisproductcontainssmallpartswhichcanbeswallowedbychildren.
Keepfingersawayfromtheplaceswheretheycanbepinchedortrapped.
Donotattempttoassemblethegazeboifanypartsaremissing.
•Thisproductisintendedfordomesticoutdooruseonly.
•Theproductshouldbeplacedonflat,horizontalground.
•Ensureenoughclearancearoundtheproduct.Beforeassemblingtheproduct,findlevel
groundnotlessthan6'(1.8m)awayfromanystructuresorobstructions,suchasfences,
garages,houses,overhangingbranches,laundrylines,orelectricalwires.
•Thisgazeboisnottoberegardedaspartofabuilding/housestructure.Thegazeboistobe
anchoredontothegroundforaddedsafety.Donotassemblethegazeboontosoil/earth
ground.Itisbestadvisabletohavethegazebobuiltontoawoodendeckorconcreteground
forstability.Ifitistobebuildontoawoodendeck/ground,doensurethatthewooden
deck/groundhasastrongfoundation.Itisadvisabletouseappropriatefloorplugs(not
provided)toanchorthegazeboontothewooden/concreteground.
•Somestructuresmayrequiretwoormorepeopletoinstallsafely.Checkforunderground
utilitiesbeforediggingordrivingstakesintotheground.
•Duringinstallation,followallsafetywarningsprovidedwithyourtools,andusesafetyglasses.
•Incaseyousetupmorethanonegazebo,keepaminimumdistanceof10'(3m)betweenthe
gazebos.
•Anyassemblyormaintenanceoftheproductmustbecarriedoutbyadultsonly.
•Arrangenecessarymanpowerwhenassemblingormovingtheproduct.
•Somepartsmaycontainsharpedges.Wearprotectiveglovesifnecessary.
•Keepchildrenandpetsawaywhilesettingupthegazebo.
•Checkallnutsandboltsperiodicallytoensurebolts/nutsaretightened.
•Repairingandreplacingpartsshouldbedonebyaqualifiedtechnician.
•Thisgazeboisintendedfordecorativeandsunshadepurposesonly,anditisnotdesignedto
withstandharshweather,includinghighwinds,rain,andsnow.
•Donotlightanyfiresinsideorneartheproduct!
•Staycalmiffirebreaksout.Searchforthenearestexit.Donotreturntothegazebobefore
firemenallowyoutodoso.
•Donothangheavyweightsontheroofframe.
•Donotclimbontotheroofofthegazebo.Fallingoffthegazebocanresultinseriousinjury.
•Retaintheoriginalpackagingtostorethegazebo.
Important Safety Instructions
Warning! Toreducetheriskofseriousinjury,readthefollowingsafetyinstructions
beforeassemblingandusingthegazebo.
Pleasecheckwithyourlocalgoverningauthority/localmunicipalcodesregarding
installationofstructuresbeforeassembl
y
.

∙ 3/24
CountryofOrigin:China
IMPORTANT:
•Please read and understand this manual before any assembly. Before beginning assembly of
product,makesureallpartsarepresent.Comparepartswithpackagingcontentslist.
•Whenassemblingwoodenparts,donotovertorquetheboltstoavoidsplittingthewood.See
imageillustration.
•Placeallpartsfromtheboxinaclearedareaandpositionthemonthefloorinfrontofyou.
•Removeallpackingmaterialsandplacethembackintothebox.Donotdisposeofthepacking
materialsuntilassemblyiscomplete.
•Neededforassembly:（Thefollowingtoolsarenotincluded）

∙ 4/24
CountryofOrigin:China
EXPLODED DRAWING

∙ 5/24
CountryofOrigin:China
Parts List
Label Part Number Description Qty Part Image
19 P000400931 Beam 8
20 P000200482 Post 8
10 P005000200 Arc Support 1 8
11 P005000201 Arc Support 2 8
A P000100342 Base 8
B P006100179 Base Cover 8
C P000501238 Slanting Beam
Connector 8
D P000501237 Top Frame 2
E P000601432 Big Roof Slanting
Beam 8
F P000501239 Top connector 1
G P000601436 Small Roof
Slanting Beam 8
H P000700640 Small Roof Cover 8
I P000800252
Small Roof
Slanting Beam
Cover
8
J P000900102 Small Roof Top
Cover 1

∙ 6/24
CountryofOrigin:China
P P005800001 Hook 1
L P000601435 Big Top Short Pipe
1 8
M P000601434 Big Top Short Pipe
2 8
N P000601433 Big Top Lower Pipe 8
O P000700637 Roof Panel 1 8
T P000700638 Roof Panel 2 8
Q P000700639 Roof Panel 3 8
R P000800251 Top Slanting Bar 8
S P005700694 Netting Pipe 8

∙ 7/24
CountryofOrigin:China
Hardware Pack
Label Part Number Description Qty Add Part Image
AA H010010306 Bolt M10*95 16 1
BB H050030001 Flat Washer
M6 237 12
CC H040010004 Nut M6 24 2
DD H030050058 Screw
ST4.8*30
56 3
EE H010020011 Bolt M6*15 156 8
FF H010020022 Bolt M6*40 33 2
GG H030030010 Screw ST8*35
64 4
HH H040050020 Non-slip Nuts
M10 16 1
II H050080007 Flat Washer
M8 64 4
JJ H050080008 Flat Washer
M10 48 3
KK H010010285 Screw
M10*65 16 1

∙ 8/24
CountryofOrigin:China
LL H070010003 Stake
Φ8*180 16 0
MM H010020025 Bolt M6*60 24 2
NN H090990002 M3 Drill 2 0
Z1 H090010017 Wrench M6 2 0
Z2 H090030005 Allen Key M8 2 0
Z3 H090010015 Wrench M10 2 0

∙ 9/24
CountryofOrigin:China
1

∙ 10/24
CountryofOrigin:China
2

∙ 11/24
CountryofOrigin:China
3

∙ 12/24
CountryofOrigin:China
4

∙ 13/24
CountryofOrigin:China
5

∙ 14/24
CountryofOrigin:China
6

∙ 15/24
CountryofOrigin:China
7

∙ 16/24
CountryofOrigin:China
8

∙ 17/24
CountryofOrigin:China
9

∙ 18/24
CountryofOrigin:China
10
0

∙ 19/24
CountryofOrigin:China
11
0

∙ 20/24
CountryofOrigin:China
12
0
