Sunjoy A103000100 User manual

Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-578-6569 from 8 am EST to 8 pm PST, Monday - Friday,
or email to [e-mail] or visit www.sunjoyonline.com.
Grill Gazebo
Français p. 9
Español p. 18
ITEM # 0754694 / 38115271
MODEL # A103000100

1
PART
A1
A2
A3
B
C
D
E
F
2
1
1
4
1
4
2
2
1
Post (1)
Post (2)
Post (3) with Bottle Opener
pre-assembled
DESCRIPTION QUANTITY
Big beam
Glass Panel 1
Big connector
Small beam
Long screen
Short screen
G1
PART
Hook
Big canopy
Small canopy
LED light
J
K
L
M
Hook rackH 1
Glass Panel 2G2 1
1
1
1
4
DESCRIPTION QUANTITY
PACKAGE CONTENTS
D
C
L
B
M
E
F
H
A3
A1
A2
J
K
G1
G2

HARDWARE CONTENTS
2
Qty. 8
Qty. 20 Qty. 3
6×230 mm
Stake
FF
Bolt 1
I II
Bolt 2
WARNING
liable for any loss of the product or other items due to the failure to take down the item during any
inclement weather.
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or install the product.
lightning.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 10 minutes
No Tools Required for Assembly.

ASSEMBLY INSTRUCTIONS
1. Attach the Long Screen (E) and the Short Screen (F)
to Post (A1 A2 A3) with the Bolt (I).
3
x 16
Bolt 1
Hardware Used
I
K
1
I
EF
A 1 A 2 A3

C
L
B
ASSEMBLY INSTRUCTIONS
2. Attach the Big Beam (B) to the Big Connector (C),
attach the Hook (L) to the Big Connector (C).
3. Insert the lower connector tube of the Big Beam (B)
into the upper tube of Post (A1 A2 A3), then put
the Big Canopy (J) on big top, do not fully spread.
4. Attach the lower connector tube of Small beam (D)
to the upper tube of Big beam (B).
4
B
B
B
2
3
A1 A2 A3
F
E
B
4
B
D

ASSEMBLY INSTRUCTIONS
5
5. Extend the Small Canopy (K) onto the small top by
fixing the canopy at four corners of Small Beam (D).
6. Take off the back cover of LED light (M), and
match 3 pieces AAA batteries into sockets.
Attach back cover to LED light (M).
Note: Batteries are not included.
6-1. Hang the assembled LED light (M) into holes
of Big Beam (B) (Note: Pull down forward
tightly after LED lights hung into Beam holes).
6-1
6
M
B
M
5
J
D
K
K

ASSEMBLY INSTRUCTIONS
6
x 3
Bolt 2
Hardware Used
II
7. Extend the Big Canopy (J) onto the big top by fixing
the canopy at four corners of Big Beam (B).
7-1. Attach the Hook (H) to Glass Panel (G2) with the Bolt (II).
G1
G2
J
H
7
B
J
J
B
7-1
H
II II II
G2

ASSEMBLY INSTRUCTIONS
7
x 8
Hardware Used
FF
x 4
Bolt 1
Hardware Used
I
8
8. Insert the Glass Panel (G1,G2) into the Post (A1, A2,
A3), then attached them tightly with the Bolt (I).
9. Fix the gazebo to the lawn by using the Stake (FF).
CARE & MAINTENANCE
To extend the life of grill gazebo, do not use when there are high winds. Disassemble and pack away
when the gazebo will not be used for an extended period.Ensure that the canopies and metal parts
are all dry before packing away.
SIX-MONTH LIMITED WARRANTY
This limited warranty is extended to the original purchaser and applies to defects in material and
workmanship of your item provided the item is maintained with care and used only for personal,
residential purposes. The manufacturer warrants this item to be free from defects in material and
workmanship for a period of 6 MONTHS. If any defect is found, please call our customer service
department at 1-866-578-6569 for help. The manufacturer will not cover transportation or delivery
costs or compensate the individual or any outside party for assembling or disassembling the product.
This warranty gives you certain rights, and you may have other rights that vary from state to state.
I
G1 G2
9
A1 A2 A3
9
FF FF

8
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-866-578-6569 from 8 am EST to
8 pm PST, Monday - Friday.
Printed in China
Production number: 2021200027
FF
I
II
II
PART
A1
A2
A3
Post (1)
Post (2)
Post (3) with Bottle
Opener pre-assembled
DESCRIPTION
B
C
D
E
F
Big beam
Big connector
Small beam
Long screen
Short screen
H
J
K
Hook rack
Big canopy
Small canopy
L
M
Hook
LED light
IBolt 1
II Bolt 2
FF
G1 Glass Panel 1
G2 Glass Panel 2
PART NUMBER
D
C
L
B
M
E
F
H
J
K
G1
G2
P000200335
P000200336
P000200337
P000601055
P000500850
P000601054
P000400704
P000400705
P002100218
P002100219
P005800142
P001100420
P001100421
P005800001
P006000006
H070010001
P005100242
P005100243
