Sunjoy L-GG032PST-C User manual

Sunjoy L-GG032PST-C 8’X5’ Kent Hard-top Grill Gazebo
Owner’s Manual
IMPORTANT
Thank you very much for choosing Sunjoy Group.
Please take time to read these instructions thoroughly and follow each step carefully for safe
and easy operation. Keep this manual for future reference.
We would like to hear from you with any comments or suggestions. You can call us toll-free at
1-866-578-6569 from 8:00 a.m. EST to 8:00 p.m. PST. You can also send the email to
[email protected] or visit www.sunjoyonline.com to get tech. assistance or to
place your replacement part order form.
Production Number:xxxxxxxx

Cautions:
1. Keep all children and pets away from assembly area. Children and pets should be supervised when they
are in the area of gazebo construction.
2. The area for assembly should not be less than 6 feet from any obstruction such as fence, garage, house,
overhanging branches, laundry line or electrical wires.
3. The unit is heavy. Don’t assemble alone. Four people are recommended for safe assembly.
4. Some parts may contain sharp edges. Wear protective gloves if necessary during assembly.
5. When assembling and using this product, basic safety precautions should always be followed to reduce the
risk of personal injury and damage to equipment. Please read all instructions before assembly and use.
6. For outdoor use only. Install on level ground. Stakes are provided to secure the gazebo in the ground.
7. Check all bolts for tightness before and during usage, periodically check and tighten bolts as necessary.
8. Warranty does not cover damage due to extreme weather conditions.
9. Gazebo is for setting purpose only. Standing on or misuse of bench may result in damage or injury. Not
intended for commercial use.
Assembly Instructions:
Our clear, easy-to-follow, step-by-step instructions will guide you through the project from start to finish.
Inside this carton you will find enclosed hardware and parts listed above. Please check the contents of this
package to ensure you have received all of the required parts, and that there is no breakage.
You will need a screwdriver (not included).
Parts identification: For ease of identification, all parts are labeled to correspond to the Step number in which
the part is used.

Roof Vent A 2pcs
Base B 4pcs
Base Cover C 4pcs
Support Bar 1 D1 2pcs
Support Bar 2 D2 2pcs
Top Bar E 1pc
Top Horizontal
Beam1 F1 2pcs
Top Horizontal
Beam2 F2 2pcs
Top Horizontal
Beam3 F3 4pcs
Hook G 1pc
Big Roof Cover 1 H1 2pcs
Big Roof Cover 2 H2 2pcs
Big Roof Cover 3 H3 2pcs
Small Roof Cover 1 I1 2pcs
Small Roof Cover 2 I2 2pcs
Small Roof Cover 3 I3 2pcs
Cover Plate J 1pc
Post 1 K1 2pcs
Post 2 K2 2pcs
Slanting Support L 4pcs
Countertop M1 2pcs
Tile M2 14cps
Press Slice 1 M3 24pcs
Parts List

Hardware Pack 1
Fig.1: Insert Support Bars ( D1, D2 ) into Roof Vent ( A ) ,then connect Top Horizontal Beam2 ( F2 ) by Bolt
( AA ) and Flat Washer( BB ).
Fig.2: Rotate Hook (G) onto Top Bar (E).
Fig.3: Attach Top Bar (E) to Roof Vent (A) by Hex Bolt (AA) and Washer (BB).
Press Slice 2 M4 8pcs
Top Screen N 2pcs
Bottom Screen P 2pcs
Press Panel Q 6pcs
AA M6x20 Hex Bolt 44PCS
BB M6 Flat Washer 44PCS
Z M6 Hex Wrench 2 PCS

Fig.4: Connect Top Horizontal Beam3 (F3) and Roof Vent (A) by Bolt (AA) and Washer (BB).
Fig.5: Connect Top Horizontal Beam 3 (F3) and Support Bars (D1, D2) by Bolt (AA) and Washer (BB).
Fig.6: Connect Top Horizontal Beam 1 (F1) and Support Bars (D1, D2) by Bolt (AA) and Washer (BB).
BB M6 Flat Washer 42PCS
CC M6x15 Cross Bolt 40PCS
DD M6x35 Cross Bolt 2 PCS
Hardware Pack 2

Fig.7: Tighten Big Roof Cover (H1, H2 and H3) with Press Panel (Q) by Bolt (CC) and Washer (BB).
Fig.8: Place Small Roof Cover (I1, I2 and I3) to be well, and then tighten them with Press Panel (Q) by
Bolt (CC) and Washer (BB).
Fig.9: Tighten Cover Plate (J) by Cross Bolt (DD) and Washer (BB).
AA M6x20 Hex Bolt 40PCS
BB M6 Flat Washer 56PCS
CC M6x15 Cross Bolt 8PCS
EE M6x35 Hex Bolt 8PCS
II Φ8x180 Stake 16 PCS
JJ M4x10 Screw 32 PCS
Hardware Pack 3

Fig.10: Attach Base Cover (C) on Post (K1, K2), then tighten Base (B) with Post (K1, K2) by Bolt (CC) and
Washer (BB)
Fig.11: Raise up the assembled Large Roof, then insert the Post (k1, k2) into the Roof and tighten them by
Bolt (AA) and Washer (BB).
Fig.12: Attached Top Screen (N) onto the Posts (K 1, K2) by Bolt (AA) and Washer (BB).

Fig.13: Attach one end of slanting support (L) to Post (K1, K2) and the other end to Support Bar (D1,
D2) by Bolt (AA) and Washer (BB).
Fig.14: Tighten Bottom Screen (P) to Posts (K1) and (K2) by Bolt (EE) and Washer (BB).
Fig.15: Place Countertop (M1) on Bottom Screen (P), then tighten Countertop (M1) t o Post (K1, K2),
by Bolt (AA) and Flat Washer (BB)
Fig.16: Put up Base Cover (C), to fix Gazebo on the ground by Stake (II)
Step: Place Tile (M2) into the empty frame of Countertop (M1), then to tighten them with Cross
Screw (JJ) and Press Slice (M3, M4).
Countertop Assemble

Care & Maintenance:
Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it
from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once these protective
coatings are scratched. This is not a defect and thus not covered by the warranty.
To minimize this condition, we recommend care when assembling & handling the product to prevent
scratching the paint. Should any scratching or damage occur, we recommend immediate touch-up with rust
inhibiting paint.
Surface rust can also be easily removed with a very light application of common cooking oil. If surface
oxidation (rusting) occurs and if no measure is taken to prevent this, the oxidation may start dripping on to
deck or patio and caused damaging stains, which may be difficult to remove. This can be prevented if the
above-mentioned measures are taken to keep the product from oxidizing.
Limited Manufacturer’s Warranty:
This limited warranty is extended to the original purchaser and applies to defects in materials and
workmanship of your item provided the item is maintained with care and used only for personal, residential
purposes.
The item is warranted to be free from defects in material or workmanship for a period of one (1) year. We
don't reimburse for transportation or delivery costs, or compensate the individual or any outside party for
assembling or disassembling the product.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of
nature, vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not
covered. Proof of purchase (dated register receipt) is required for warranty claims. Warranty is to the original
purchaser and is non-transferable. Any replacement of warranted items will be in the original style and color,
or a similar style and color if the original is unavailable or has been discontinued. As some states do not allow
exclusions or limitations on an implied warranty, the above exclusions and limitations may not apply. This
warranty gives you specific rights, and you may also have other rights, which vary from state to state.
Made in China
