Sunjoy A102009100 User manual

ASSEMBLY INSTRUCTION
ITEM#：A102009100
Country of Origin: China
WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
[e-mail]
Production Number: XXXXXXXXXX
Production Number: XXXXXXXXXX

2
•This product is intended for domestic outdoor use only.
•The product should be placed on flat, horizontal ground.
•Ensure enough clearance around the product. Before assembling the product, find level
ground not less than 6' (1.8 m) away from any structures or obstructions, such as
fences,
garages, houses, overhanging branches, laundry lines, or electrical wires.
•This gazebo is not to be regarded as part of a building/house structure. The gazebo is
to be anchored onto the ground for added safety. Do not assemble the gazebo onto
soil/earth ground. It is best advisable to have the gazebo built onto a wooden deck or
concrete ground for stability. If it is to be build onto a wooden deck/ground, do
ensure that the wooden deck/ground has a strong foundation. It is advisable to use
appropriate floor plugs (not provided) to anchor the gazebo onto the wooden/concrete
ground.
•Some structures may require two or more people to install safely. Check for
underground utilities before digging or driving stakes into the ground.
•During installation, follow all safety warnings provided with your tools, and use safety glasses.
•In case you set up more than one gazebo, keep a minimum distance of 10' (3 m)
between the gazebos.
•Any assembly or maintenance of the product must be carried out by adults only.
•Arrange necessary manpower when assembling or moving the product.
•Some parts may contain sharp edges. Wear protective gloves if necessary.
•Keep children and pets away while setting up the gazebo.
•Check all nuts and bolts periodically to ensure bolts/nuts are tightened.
•Repairing and replacing parts should be done by a qualified technician.
•This gazebo is intended for decorative and sunshade purposes only, and it is not
designed to withstand harsh weather, including high winds, rain, and snow.
•Do not light any fires inside or near the product!
•Stay calm if fire breaks out. Search for the nearest exit. Do not return to the gazebo before
firemen allow you to do so.
•Do not hang heavy weights on the roof frame.
•Do not climb onto the roof of the gazebo. Falling off the gazebo can result in serious injury.
•Retain the original packaging to store the gazebo.
Important Safety Instructions
Warning! To reduce the risk of serious injury, read the following safety instructions
before assembling and using the gazebo.
Please check with your local governing authority/local municipal codes regarding
installation of structures before assembly.
Caution! Proper placement of your gazebo is essential.
Do not place the product underneath electrical lines.
Keep children away during assembly.
This product contains small parts which can be swallowed by children.
Keep fingers away from the places where they can be pinched or trapped. Do
not attempt to assemble the gazebo if any parts are missing.
Country of Origin: China

3
•Please read and understand this manual before any assembly. Beforebeginning
assembly of product, make sure all parts are present. Compare parts with packaging
contents list.
•When assembling wooden parts, do not overtorque the bolts to avoid splitting the wood.
See image illustration.
•Place all parts from the box in a cleared area and position themon the floor in front of
you.
•Remove all packing materials and place them back into the box. Do not dispose of the
packing materials until assembly is complete.
•Needed for assembly:（The following tools are not included）
IMPORTANT:
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
Country of Origin: China

4
Part Part Number Description Quantity
H1 H100010047 Bolt M6*20 198+10
H2 H100010046 Bolt M6*40 52+3
H3 H100010074 Bolt M6*75 16+1
H4 H050030001 Flat washer M6 16+1
H5 H040010004M6 Nut 16+1
HR P005100264 Plastic ring 52+3
HS H070010003 Dia. 8 * 180 Stake 8
HW1 H090010017 Wrench M6 2
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
H1 H2
H3 H4 H5
HR HS HW1
Country of Origin: China

5
Pre-installation (continued)
PACKAGE CONTENTS
A
C
E
F
J
G
D
K
L
T
B
U
Q
S
W
V
X
R
P
M
N
Y
AA
Country of Origin: China

6
AB
AE
AC
AL
AR
AS
AP
AQ
AT
AU
AM
AV
AF
AG
AJ
AK
AN
AD
Country of Origin: China

7
Pre-installation (continued)
Part
Part Number
Description
Quantity
AL
P00070095901
Big roof long side upper
panel (Left)
2
AM
P00070096801
Big roof long side upper
panel (Right)
2
AN
P00070094901
Big roof short side upper
panel
2
AP
P00070099101
Big roof long side bottom
panel (Left)
2
AQ
P00070100201
Big roof long side bottom
panel (Right)
2
AR
P00070098601
Big roof short side bottom
panel (Left)
2
AS
P00070099601
Big roof short side bottom
panel (Right)
2
AT
P00080033601
Slanting beam cover
4
AU
P00080034701
Middle beam cover
4
AV
P00120027101
Mosquito netting
1
Part
Description
A
P00020060101
Post
4
B
P00010025901
Stake base
4
C
P00610021801
Stake cover
4
D
P00050025001
Slanting beam connector
4
E
P00040115901
Long cross beam (Left)
2
F
P00040116001
Long cross beam (Right)
2
G
P00040116101
Short cross beam ( Right )
2
J
P00040116201
Short cross beam ( Left )
2
K
P00050104301
Middle beam connector 1
4
L
P00050104401
Middle beam connector 2
4
M
P00570034303
Long pipe
4
N
P00570034203
Short pipe
4
P
P00500035401
Curve support
8
Q
P00050156702Big top long connector tube
2
R
P00050157202Big top short connector tube
2
S
P00050157503Big top connector
4
T
P00060196801
Slanting beam
4
U
P00060197401
Middle beam 2
4
V
P00050156303
Small roof connector
1
W
P00060023402Small roof support beam
4
X
P005800001
Hook
1
Y P00060202601
Small Roof Panel
Flashing(Long Side)
2
AA P00060202001
Small Roof Panel
Flashing(Short Side)
2
AB
P00070022301Small roof short panel
2
AC
P00070022201Small roof long panel
2
AD
P00080009701 Small roof support beam cover
4
AE
P00090015201
1
AF
P00060199402
Big roof long side beam
4
AG
P00060198602
Big roof short side beam
4
AJ
P00060200601 Big roof long side lower beam
4
AK
P00060200501 Big roof short side lower beam
4
Quantity
Part Number
Small roof cover
Country of Origin: China

8
1
20X
4X
4X 4X 4X
