Sunjoy Bellevue L-GZ238PST-10-1 User manual

Production Number: 2018xxxx
Sunjoy Bellevue Hardtop Grill Gazebo
L-GZ238PST-10-1
Owner’s Manual
IMPORTANT
Thank you very much for choosing Sunjoy Group.
Please take time to read these instructions thoroughly and follow each step carefully for safe and
easy operation. Keep this manual for future reference.
We would like to hear from you with any comments or suggestions. You can call us toll-free at
1-866-578-6569 anytime 24 hours / 7 days a week. You can also send the email to
[e-mail] or visit www.sunjoyonline.com to get tech. assistance or to
place your replacement part order form.

Cautions:
1. Keep all children and pets away from assembly area. Children and pets should be supervised when
they are in the area of gazebo construction.
2. Always keep children under close supervision when they are using or are around this product. Never
leave children unattended.
3. This unit is heavy. Do not assemble this item alone. Four people are recommended for safe assembly.
4. Some parts may contain sharp edges. Wear protective gloves if necessary during assembly.
5. When assembling and using this product, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment. Please read all instructions before
assembly and use.
6. This product is for outdoor use only. Do not climb on top of the gazebo. Do not use the unit during an
electrical storm. Install on level, horizontal ground.
7. Before assembling the product, find level ground no less than 6 ft. away from any structures or
obstructions, such as fences, garages, houses, overhanging branches, laundry lines, or electrical wires.
8. The gazebo must be anchored with stakes onto the ground for added safety.
9. It cannot be permanently attached to a concrete floor or platform. Do not assemble the gazebo on
sandy, muddy or loose soil, as stakes do not have enough anchorage in these types of soil. Check all
bolts for tightness before and during usage.
10. Check all bolts for tightness before and during usage.
Assembly Instructions:
Our clear, easy-to-follow, step-by-step instructions will guide you through the project from start to finish.
The final product will be a quality piece that will go together smoothly and give years of enjoyment.
Loading limit of the hook is 26 lbs.
Loading limit of the glass side bar top is 33 lbs.
Parts identification: For ease of identification, all parts are labeled to correspond to the Step number in
which the part is used.

Label
Description
No.
QTY
Spare
AA
M6x15 Bolt
H09015C11
84 PCS
9PCS
BB
M6 Flat Washer
H19001C11
181 PCS
19PCS
CC
M6x25 Hexagon Bolt
H02025C11
16 PCS
2PCS
DD
M6x15 Hexagon Bolt
H02015C11
28 PCS
3PCS
EE
M6x55 Bolt
H09055C11
16 PCS
2PCS
FF
M6 Nut
H14001C11
16 PCS
2PCS
GG
M6x35 Bolt
H09030C11
20 PCS
2PCS
HH
M6 Cap Nut
H23001C11
1 PC
0
II
Φ8x180 Round Stake
P12401A01001
16 PCS
0
W1
M6 Wrench
H00001C12
1 PC
0
Hardware Pack

Post 1
A1
P11181B01108
2
Post 2
A2
P11182B01108
2
Base Cover
C
P11553A01108
4
Post Base
B
P11666A01108
4
Long Beam
D
P11033D01108
2
Short Beam
E
P11034D01108
2
Middle Top Beam
Connector
F
P10841A01108
2
Corner Beam Connector 1
G1
P10746A01108
2
Corner Beam Connector 2
G2
P10747A01108
2
Top Strap
H
P10146B01108
1
Corner Top Beam 1
I1
P10339B01108
2
Corner Top Beam 2
I2
P10340B01108
2
Middle Top Beam
J
P10410B01108
2
Roof Cover of Long Side 1
K1
P11986B01108
2
Roof Cover of Long Side 2
K2
P11987B01108
2
Roof Cover of Long Side 3
K3
P11988B01108
2
Roof Cover of Long Side 4
K4
P11989B01108
2
Roof Cover of Short Side 1
L1
P11990B01108
2
Roof Cover of Short Side 2
L2
P11991B01108
2
Roof Cover of Short Side 3
L3
P11992B01108
2
Parts List

Roof Cover of Small
Top Long Side
M1
P11993B01108
2
Roof Cover of Small
Top Short Side
M2
P11994B01108
2
Long Side Support
Beam 1
N1
P13040B01108
2
Long Side Support
Beam 2
N2
P13041B01108
2
Long Side Support
Beam 3
N3
P13042B01108
2
Long Side Support
Beam 4
N4
P13043B01108
2
Long Side Support
Beam 5
N5
P13044B01108
2
Long Side Support
Beam 6
N6
P13045B01108
2
Short Side Support
Beam 1
O1
P13046B01108
2
Short Side Support
Beam 2
O2
P13047B01108
2
Short Side Support
Beam 3
O3
P13048B01108
2
Corner Cover Panel
of Long Top 1
P1
P12066A01108
2
Corner Cover Panel
of Long Top 2
P2
P12070A01108
2
Middle Cover Panel of
Long Top
Q
P12067A01108
2
Small Top Beam
R
P10266A01108
4
Small Top Connector
S
P10147B01108
1
Hook
T
P12601C01108
1
Cover Panel of Small
Top 1
U1
P12068A01108
2
Cover Panel of Small
Top 2
U2
P12071A01108
2
Top Cover of Small
Top
V
P12069A01108
1
Countertop
W
P12345A01108
2
Parts List

AA
M6x15 Bolt
H09015C11
8 PCS
BB
M6 Flat Washer
H19001C11
36 PCS
CC
M6x25 Hexagon Bolt
H02025C11
16 PCS
DD
M6x15 Hexagon Bolt
H02015C11
12 PCS
W1
M6 Wrench
H00001C12
1 PC
Hardware Pack 1

Fig.1: Attach Base Cover (C) to Post 1, 2 (A1, A2), then fix Post Base (B)
on lower end of Post 1, 2 (A1,A2) with Bolt (AA) and Flat Washer (BB).
Fig.2: Attach Short Beam (E) to Post 1, 2 (A1, A2) with Hexagon Bolt (CC)
and Flat Washer (BB). Repeat this step for Long Beam (D) and Post 1, 2
(A1,A2). After this step, a frame has been completed.
Fig.3: Attach Corner Beam Connector 2 (G2) to upper beams of Post
2(A2) with Hexagon Bolt (DD) and Flat Washer (BB). Repeat this step for
Corner Beam Connector 1 (G1 ).
Fig.4: Attach Middle Top Beam Connector (F) to middle of Long Beam (D)
with Hexagon Bolt (DD) and Flat Washer (BB).
Fig.5、Fig.6: Connect one top of Corner Top Beam 1 (I1) and Corner Beam Connector 1 (G1) with
Hexagon Bolt (EE), Flat Washer (BB) and Hexagon Nut (FF). Connect another top of Corner Top
Beam 1 (I1) and Top Strap (H) with Hexagon Bolt (DD) and Flat Washer (BB). Repeat this step for
Corner Top Beam 2 (I2) and Corner Beam Connector 2 (G2).
Fig.7、Fig.8: Connect one top of Middle Top Beam (J) and middle of Top Strap (H) with Hexagon Bolt
(DD) and Flat Washer (BB). Connect another top of Middle Top Beam (J) and Middle Top Beam
Connector (F) with Bolt (EE), Flat Washer (BB), and Hexagon Nut (FF).
AA
M6x15 Bolt
H09015C11
40 PCS
BB
M6 Flat Washer
H19001C11
84 PCS
DD
M6x15 Hexagon Bolt
H02015C11
12PCS
EE
M6x55 Bolt
H09055C11
16 PCS
FF
M6 Nut
H14001C11
16 PCS
Hardware Pack 2

Fig.9、Fig.10: Attach one top of Long Side Support Beam 3 (N3/N1/N5) to Corner Top Beam 1/2(I1/I2)
with Bolt (AA) and Flat Washer (BB), and another top to Middle Top Beam (J) with Bolt (AA) and Flat
Washer (BB). Repeat this step for Long Side Support Beam 2/4/6 (N2/N4/N6).
Fig.11、Fig.12: Attach one top of Short Side Support Beam 3 (O3) to
Corner Top Beam 1 (I1), and then attach another top to Corner Top
Beam 2 (I2). Repeat this way for Short Side Support Beam 1, 2
(O1, O2).
Fig.13: Attach Hook (T) onto Small Top Connector (S), then using Bolt
(EE), Flat Washer (BB) and Hexagon Nut (FF) to link Small Top Beam
(R) and Small Top Connector (S).
Fig.14: Insert Small Top Beam (R) into Top Strap (H) and tighten them
with Bolt (AA) and Flat Washer (BB).
AA
M6x15 Bolt
H09015C11
36 PCS
BB
M6 Flat Washer
H19001C11
61 PCS
DD
M6x15 Hexagon Bolt
H02015C11
4 PCS
GG
M6x35 Bolt
H09030C11
20 PCS
HH
M6 Cap Nut
H23001C11
1 PC
II
Φ8x180 Round Stake
P12401A01001
16 PCS
Hardware Pack 3

Fig.15: Lock Roof Cover of small top (M1, M2) with Bolt (AA) and Flat Washer (BB).
Fig.16: Lock Cover Panel of small top (U1, U2) with Bolt (GG) and Flat Washer (BB), then tighten Top
Cover of Small Top (V) with Flat Washer (BB) and Cap Nut (HH).
Fig.17: Tighten all Roof Cover (K1, K2, K3, K4, L1, L2, L3) with Bolt (AA) and Flat Washer (BB).

Fig.18: Lock Corner Cover Panel of Long Top 1/2 (P1/P2) and Middle Cover Panel of Long Top (Q) with
Bolt (GG) and Flat Washer (BB).
Fig.19:Attach Countertop (W) onto Post 1/2 (A1/A2) with Hexagon Bolt (DD) and Flat Washer (BB).
Fig.20: Lift up Base Cover (C), use Stake (II) to fasten the gazebo on the ground. Put down Base
cover (C) and now your gazebo is ready for use.

Care & Maintenance:
Our steel components for garden accessories and furniture are treated with rust inhibiting paint that
protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur
once these protective coatings are scratched. This is not a defect and thus not covered by the
warranty. To minimize this condition, we recommend care when assembling & handling the product
to prevent scratching the paint. Should any scratching or damage occur, we recommend immediate
touch-up with rust inhibiting paint.
Surface rust can also be easily removed with a very light application of any rust removing solution,
we also recommend WD-40, which is readily available in all major stores. If no measure is taken to
prevent this, the oxidation may start dripping on to deck or patio and caused damaging stains, which
may be difficult to remove. This can be prevented if the above-mentioned measures are taken to
keep the product from oxidizing.
Limited Manufacturer’s Warranty:
This limited warranty is extended to the original purchaser and applies to defects in materials and
Workman ship of your item provided the item is maintained with care and used only for personal,
residential purposes.
The item is warranted to be free from defects in material or workmanship for a period of one (1)
year. We don't reimburse for transportation or delivery costs, or compensate the individual or any
outside party for assembling or disassembling the product.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged due to
acts of nature, vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of
hardware is not covered. Proof of purchase (dated register receipt) is required for warranty claims.
Warranty is to the original purchaser and is non-transferable. Any replacement of warranted items
will be in the original style and color, or a similar style and color if the original is unavailable or has
been discontinued. As some states do not allow exclusions or limitations on an implied warranty,
the above exclusions and limitations may not apply. This warranty gives you specific rights, and you
may also have other rights, which vary from state to state.
