Sunjoy A101000700 User manual

Assembly Instructions
10x10 Gazebo W/ Awning
Menards SKU: 2721826
Model: A101000700
Production Number：2020300015
Made In China

Congratulations on your purchase of our SUNJOY 10x10 Gazebo W / Awning. Our
clear, easy to follow, step-by-step instructions will guide you through the assembly
process from start to finish.
IMPORTANT:
1. When installing and assembling your gazebo, it is recommended that two or more adults
are involved.
2. Do not use the gazebo during an electrical storm, as there is a remote chance of getting
struck by lightning.
3. Do not climb on top of the gazebo. Falling off the gazebo can result in serious injury,
possibly even death.
4. Do not leave the gazebo assembled when there is a risk of high wind, as possible
damage will occur to the structure.
5. Do not use lanterns that contain open flames.
6. This package contains small items and plastic bags that should be kept away from
children.
7. Ensure that all connectors & poles are firmly secured in position fully. It is important to do
that before use so as to avoid collapsing or damage to the item, which could result in injury.
8. KEEP ALL FLAME AWAY FROM THIS SHELTER FABRIC. The fabric may burn if it is
exposed to prolonged contact with a flame source. The application of any foreign
substance to the fabric may render the flame-resistant properties ineffective.
USE & CARE:
1. This gazebo is not a permanent structure. The canopy top should never be left on during
periods of extended or heavy rain nor any inclement weather where high winds or wind gusts
can occur. If left up, damage to the gazebo and surroundings can occur.
2. Do not repack your gazebo until completely dry.
3. Steel components for garden accessories and furniture are treated with rust inhibiting
paint that protects them from rust. However, due to the nature of steel, surface oxidation (rusting)
will occur if this protective coating is scratched. This is a natural process. To minimize this
condition, it is recommended that care be taken when assembling and handling the product in
order to prevent the paint from being scratched. Surface rust can be removed easily using a very
light application of common cooking oil. If surface oxidation (rusting) occurs and no measures are
taken to correct it, the oxidation may start dripping onto the deck or patio, which may cause
damaging stains that may be difficult to remove.

Stake Cover A P11533A01108
P10182A01108
P11113B01108
P11114B01108
P11115B01108
P11087B01108
P11088B01108
P11870A01108
P10824A01108
P10386A01108
P10387A01108
P10456A01108
P10457A01108
P12324A01108
P11871A01108
P10183A01108
P10235A01108
P10184A01108
P12601C01108
P14401A01108
P14102A01108
P11641A01108
Decorative part B
Stake plate C
Post 1 D1
Post 2 D2
Post 3 D3
Short beam E1
Long beam E2
Beam support tube E3
Middle beam connector F
Oblique beam G1
Oblique beam down tube G2
Middle beam H1
Middle beam down tube H2
Tabletop I
Tabletop support J
Small top connector K
Small top oblique beam L
Big top connector M
Hook N
Barometricbar S
Awning frame corner
part O1
4
1
4
2
1
1
4
4
4
4
4
4
4
4
1
1
1
4
1
1
2
2
Parts List
Description Part Qty Part Number Image

AA
BB
CC
II
Z
M6*15 Flat bolt
M6Washer
M6*20 Hex bolt 34PCS
58PCS
16PCS
8PCS
M6 Wrench 1 PC
Hardware Pack 1
Awning frame horizontal
pipe 1 O2 P14103A01108
P14104A01108
P14105A01108
P14106A01108
P14107A01108
P14302A01108
P00115A07037
P00116A07037
P00206A07023
H09015C11
H19001C11
H00001C12
Awning frame horizontal
pipe 2 O3
Awning frame vertical
pipe 1 O4
Awning frame vertical
pipe 2 O5
Awning frame support
pipe O6
Awning frame locating
piece O7
Big canopy P
Small canopy Q
Awning R
2
2
1
1
1
1
1
1
1
JJ 36PCS
M6*25 Hex bolt
M6 Spring Washer
H02020C11
H02025C11
H13001C11
Part Description Part Number Qty Image

BB M6 Washer H19001C11
H14001C11
H09040C11
DD M6 Nut
EE M6*40 Flat bolt
16 PCS
8 PCS
8 PCS
Hardware Pack 2
Fig.4: Use bolt (CC) ,Spring Washer(JJ) and washer (BB) to fasten the beams(E1,E2) on the posts(D1,D2,D3),
then use bolt (II) ,Spring Washer(JJ) and washer (BB) to fasten the beam support tube on the beam (E1, E2).
Fig.5: Firstly inset the tabletop (I) connector into the U plate on the posts (D2, D3). Then use bolt (CC) and
washer (BB) to fasten the tabletop on the post (D2, D3).
Fig.6: Use bolt (CC) and washer (BB) to fasten the tabletop support (J) beneath the table.
Fig.1: Firstly attach the bottom of posts (D1,D2, D3) into stake cover(A) and raise them up. Then use bolt
(AA) and washer (BB) to fasten the stake plate(C) on the bottom of posts.
Fig.2: Attach the short beam (E1) with long beam (E2) tightly using bolt (CC) ,Spring Washer(JJ) and washer
(BB).
Fig.3: Use bolt (AA) and washer (BB) to fasten the middle beam connector (F) on the assembled beams.
Part Description Part Number Qty Image

Fig.10: Firstly insert the middle beam (H1) into the down tube (H2).
Fig.11: Insert the middle beam (H1) into the big top connector (M), then attach the hook(N) on the
big top connector(M).
Fig.12: Use bolt (EE), washer(BB) and nut (DD) to fasten the middle beam down tube (H2) on
the middle beam connector(F), then cover the big canopy(P) but do not unfold it.
Fig.13: Attach the small top oblique beam (L) with small top connector (K).
Fig.14: Cover the small canopy (Q) on the assembled small top.
Fig.15: Attach the decorative part (B) on the small top.
Fig.7: Insert the oblique beam (G1) into the down tube (G2).
Fig.8: insert the oblique beam (G1) into the big top connector (M).
Fig.9: Use bolt (EE), washer (BB) and nut (DD) to fasten the oblique beam down tube (G2) on
the U plate of posts (D1, D2, D
3).

Hardware Pack 3
Attach the assembled small top on the tube of oblique beam (G1) through small top oblique
beam (L).
Fig.17-1: Cover the big canopy (P) on the big top, then button up canopy on the oblique beam
down tube (G2).
Fig.17-2: Cover the four cloth buttons which in the middle of big canopy (P) on the middle beam
CC M6* Hex bolt 28 PCS
H19001C11
H16001C11
H020 C11
P12401A01001
H09090C11
BB M6 Washer 28PCS
HH M6 antiskid nut 2PCS
FF Ø 8*180 Stake 8PCS
GG M6*90 Flat bolt 2PCS
Part Description Part Number Image Qty

Additional Hardware
BB
CC
DD
EE
GG
HH
AA
1 PC
1 PC
M6*15 Flat bolt
M6 Washer
M6* Hex bolt
M6*25 Hex bolt
PCS
PCS
PC
1 PC
H09015C11
H19001C11
H020 C11
H02025C11
H14001C11
H09040C11
M6 Nut
M6*40 Flat bolt
1 PC
H16001C11
M6 antiskid nut
H09090C11
M6*90 Flat bolt 1 PC
JJ 2PCS
M6 Spring Washer H13001C11
II
PartDescriptionQty Part NumberImage

Fig.18 Insert the awning frame part into the awning (R) as the pic. shows, and use velcro to fasten the
vertical pipe (O4,O5) on the awning (R). The outside horizontal pipe (O2,O3) and support pipe(O6)
also use velcro to fasten to awning (R),but the inside horizontal pipe (O2,O3) insert to awning (R).
Fig.18-1: Insert the horizontal pipe 2 (O3) into the horizontal pipe 1(O2), then use bolt (CC) and washer
(BB) to fasten it.

Fig. 18-2: Use bolt (CC) and washer (BB) to fasten the awning frame support pipe (O6) on
the assembled awning frame 1(O2) and awning frame 2(O3).
Fig.18-3: Insert the horizontal pipe 2(O3) and awning frame vertical pipe 2(O5) into the awning
frame corner part（O1）, then use bolt (CC) and washer (BB) to fasten it. Awning frame horizontal
pipe 1 (O2) and awning frame vertical pipe 1(O4) and awning frame corner part (O1）as the same
method.
Fig.18-4: Insert the horizontal pipe 1 (O2) into the vertical pipe (O4), then use bolt (CC) and
washer (BB) to fasten it. Awning frame horizontal pipe 2(O3) and Awning frame vertical pipe 2(O5) as
the same method.
Fig.19: Use bolt (GG) and nut (HH) to fix the assembled awning frame on the post (D2/D3).
Fig.20: Use bolt (CC) and washer (BB) to fasten Barometric bar to the awning and post (D2/
D3).
Fig.20-1: Use bolt (CC) and washer (BB) to fasten awning frame locating piece (O7) on the post
2(D2).
Your 10x10 gazebo is now ready for use.
Please do not return this product to the store. For technical assistance on assembly,
replacement parts, or warranty questions email [email protected]
Fig.20-2: When lay down the awning frame, pl hook it using awning frame locating piece lest
wind blows it up.
Fig.21: Use stake (FF) to fix the gazebo on the lawn.
