Sunjoy L-GZ098PST-1B User manual

1/ 7
IMPORTANT:
Please read and follow all safety statements, warnings, assembly instructions, use & care
directions, before attempting to assemble.
WARNINGS:
1. Assembly Instructions must be followed.
2. Pegs supplied must be used to hold this gazebo in place when upright.
3. Warranty does not cover damage due to extreme weather conditions.
4. Do not use candles, matches or open flames of any kind in or near a tent.
5. Do not cook inside the tent.
6. Build campfires downwind and several meters away from a tent and be sure to fully
extinguish campfires before leaving a campsite or before retiring for the night.
Assembly Instruction
ITEM# L-GZ098PST-1B

2/ 7
7. Exercise extreme caution when using fuel-powered lanterns or heaters inside a tent and use
battery-operated lanterns whenever possible.
8. Do not refuel lamps, heaters or stoves inside a tent.
9. Extinguish or turn off all lanterns before going to sleep.
10. Do not smoke in a tent.
11. Do not store flammable liquids inside a tent
12. KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC. This tent is
made of flame-resistant fabric. It is not fireproof. The fabric will burn if left in continuous contact
with a flame source.
Please note parts AA, BB, and CC MUST be used in order to assure stability of this unit.
USE & CARE:
1. This gazebo is not a permanent structure and should be disassembled & stored away after
use.
2. Do not repack your gazebo until completely dry.
3. This gazebo must be assembled by two adults or more.
4. This gazebo must not be left erect in windy conditions.
5. Loading limit of the hook is 33 lbs.
6. Steel components for garden accessories and furniture are treated with rust inhibiting paint
that protects them from rust. However, due to the nature of steel, surface oxidation (rusting)
will occur if this protective coating is scratched. This is a natural process. To minimize this
condition, it is recommended that care be taken when assembling and handling the product in
order to prevent the paint from being scratched. If scratching or damage occurs, it is
recommended that the area be touched-up immediately with rust inhibiting paint, which is
included in the package. Surface rust can be removed easily using a very light application of
common cooking oil. If surface oxidation (rusting) occurs and no measures are taken to correct
it, the oxidation may start dripping onto the deck or patio, which may cause damaging stains
that may be difficult to remove.

3/ 7
1 Pole1 4
2 Pole2 4
3 Long Support Pole3 8
4 Short Support Pole4 4
5 Pole5 4
6 Pole6 4
A Base plate 4
B Corner connector 4
C Top connector 1
D Small Canopy 1
E Big Canopy 1
F Mosquito netting 1
AA ￠4x180 Stake 8PCS
BB Rope 8PCS
CC Rope peg 8PCS
DD Plastic loop 40
Parts List

4/ 7
Fig.1: Insert the Short Support Pole 4 into Long Support Pole 3, then insert the other end of Long
Support Pole 3 into the Corner Connector B as above drawing.
Fig.2: Insert the Pole 5 into Pole 6 (Note: Before last Pole 5 inserted into Pole 6, put Big Canopy E onto the
Big Top, do not fully spread). Then insert Pole 6 into Top Connector C.
Fig.3: Insert pole 5 into the corner connector B.

5/ 7
Fig.4: Put Small Canopy D onto Small Top. Then insert the spring clip end of Pole 1 into the Corner
Connector B. Please make sure the Pole 1 is completely inserted into Connector B.
Fig.5: Insert the spring clip end of Pole 2 into Pole 1, and then insert Pole 2 into Base Plate A, then
fix gazebo by using Stake AA through Base Plate A.

6/ 7
Limited Warranty:
This limited warranty is extended to the original purchaser and applies to defects in materials and
workmanship of your item provided the item is maintained with care and used only for personal,
residential purposes.
The item is warranted to be free from defects in material or workmanship for a period of 6 months. We
don't reimburse for transportation or delivery costs, or compensate the individual or any outside party
for assembling or disassembling the product.
Fig.6: Fully Spread Big Canopy E on the top frame. Hang the Big canopy metal hook into hole of
Pole 2 first, and then hang the plastic hook into Base plate A.
Fig 7: Tie Rope BB onto four corner of Big Canopy, and then use Rope Peg CC to secure it to the
ground. Finally, hang Mosquito Netting to Pole (3&4) with Plastic loop DD.

7/ 7
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of
nature, vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is
not covered. Proof of purchase (dated register receipt) is required for warranty claims. Warranty is to
the original purchaser and is non-transferable. Any replacement of warranted items will be in the
original style and color, or a similar style and color if the original is unavailable or has been
discontinued. As some states do not allow exclusions or limitations on an implied warranty, the above
exclusions and limitations may not apply. This warranty gives you specific rights, and you may also
have other rights, which vary from state to state.
Maintenance:
Our iron/steel components for garden accessories and patio items are coated with rust inhibiting paint
that protects it from rusting. However, due to the nature of iron, surface oxidation (rusting) will occur
once these protective coatings are scratched.
This is a natural process and is not a defect! To minimize
this condition, we recommend care when assembling & handling the product to prevent scratching the
paint. Should any scratching or damage occur, we recommend immediate touch-up with rust inhibiting
paint. Surface rust can also be easily removed with a very light application of common cooking oil. If
surface oxidation (rusting) occurs and if no measure is taken to prevent this, the oxidation may start
dripping on to deck or patio and cause damaging stains, which may be difficult to remove. This can be
prevented if measure is taken to keep the product from oxidizing.
Important: Please do not return this product to the store. For technical assistance on
assembly or replacement parts. Please call Sunjoy Industries at 1-866-578-6569 from 8:00 am
EST to 8:00 pm PST or fax the replacement part form which is in the box to 1-740-283-3549 or
Email [e-mail] for assistance.
Made in China
2016-04
