Sunjoy L-BG011PST-1 User manual

Garden Bridge
Assembly Instructions
ITM./ART. 452795
Product #: L-BG011PST-1
Bridge Rail A 2 PCS
Bridge Surface B 2 PCS
Side Rail C 2 PCS
Middle Rail D 1 PC
Decorative Top E 4 PCS
Foot Plate F 4 PCS
M8X 20 mm Bolt
(TBZ00308020HS）a 12
PCS
M8 Spring Washer
(TBZ10508HS) b 18
PCS
M8 Flat Washer
(TBZ10808HS) c 18
PCS
M8 Nuts
(TBZ20108HQ) d 6
PCS
M6X 15 mm Bolt
(TBZ00306015HS) e 24
PCS
M6 Flat Washer
(TBZ10806HS) f 24
PCS
260 mm Ground
Stake(TBZ10608260HQ) g 8
PCS
For technical assistance or replacement parts call Sunjoy Monday through Friday from 8:30 AM to 5:30 PM ET at following:
US 1-866-578-0101 or e-mail: [email protected].
NOTE: Please read instructions prior to assembly. It is recommended to use two people for assembly.
For outdoor use only. Keep instructions for future reference.
Ground stakes are included for use on dirt and grass. Ensure surface is level for secure staking.
For ease of cleaning and safety, do not assemble less than 6 ft / 1.8 m from any obstruction such as a fence, garage,
house, overhanging branches, laundry line or electrical wires.
When assembling and using this product, basic safety precautions should always be followed to reduce the risk of
personal injury and damage to equipment.
Install on level ground.
Check all bolts for tightness before and during usage.
WARNING: Assemble as per instructions only. Do not alter the construction of the bridge. Children and pets should be
supervised when they are in area of the bridge.
Notes before assembly: Permanent installation recommended. To ensure safe use of this bridge, it may be necessary
to install foot plates permanently into poured concrete blocks or railroad ties or similar using suitable bolts. Consult a
qualified contractor or representative at your local hardware store or home center.
M8, M10 90 mm
Wrench W1PC
Parts List

NOTE: Gently set parts on a flat, non-abrasive surface. Verify there are no missing parts.
Assembly Diagram:
Step 1: Attach Foot Plate (F) to Bridge Rail (A) with 4 Bolts
(e) and 4 Flat Washers (f). See Fig. 1-1. Repeat for the
other 3 Bridge Rail Posts. Please note that the holes
should be facing out for ease of installing stake/expansion
bolts as illustrated in Fig. 1-2. Fully tighten hardware.
Step 2: Insert the bolt under Side Rail (C) to the pre-attached hole on
the leg of Bridge Rail (A) and fasten with Flat Washer (c), Spring
Washer (b) and Nut (d). Secure Bridge Rail (A) with Bolt (a), Spring
Washer (b) and Flat Washer (c). Fully tighten hardware. Repeat for
other 3 Bridge Rail Posts. See Fig. 2.
Step 3: Attach Middle Rail (D) to Bridge Rail (A) with Flat
Washer (c), Spring Washer (b) and Bolt (a). Fully
tighten hardware. Repeat for opposite end of Middle Rail.
See Fig. 3.
Fig. 1-2

E
CARE INSTRUCTIONS:
Clean gently with environmentally-friendly soap solution and water using a sponge. Do not use abrasive materials, wire
brushes, chemicals, cleansers or bleach. Do not use a pressure washer. Rinse well. Allow to air dry.
If there are nicks, chips and scratches, go to you local hardware store or home center and obtain a closest match touch-up
paint suitable for outdoor metal use. Follow instructions that come on the paint can.
MADE IN CHINA
Step 4: Attach Bridge Surface (B) to Middle Rail (D) and Side Rail
(C) with Flat Washer (c), Spring Washer (b) and Bolt (a). Do
not fully tighten hardware. The side with the label (OUT) should be
attached to Side Rail (C). See Fig. 4.
Step 5: Attach Decorative Top (E) to Bridge Rail (A) with Bolt
(e) and Flat Washer (f). See Fig. 5. Tighten all bridge bolts
securely. Alternate tightening all bolts so that all sides are
tightened evenly.
