Sunjoy L-GZ472PST-C-A User manual

Assembly Instructions
Item#: L-GZ472PST-C-A
Production Number:2018xxxx
1
2019+工厂代码

Table of Contents
Table of Contents .......................................................... 2
Safety Information ......................................................... 2
Warranty ......................................................................... 2
What is Covered ......................................................... 2
What is Not Covered .................................................. 2
Pre-Assembly ................................................................ 3
Planning Assembly ..................................................... 3
Hardware Included ..................................................... 3
Package Contents ................................................... 4-5
Assembly .................................................................... 6-8
Care and Cleaning ........................................................ 9
Important ………………………………….…………...…..9
Safety Information
1. Some parts may contain sharp edges. Wear
protective gloves.
2. When assembling and using this product, basic
safety precautions should always be followed to
reduce the risk of personal injury and damage to
equipment. Please read all instructions before
assembly and usage.
DANGER: This unit is heavy! Do not assemble this
item alone.
WARNING: Do not leave the gazebo where there is
a risk of high wind, as possible damage will occur to
the structure.
CAUTION: Do not climb on top of the gazebo.
Falling off the gazebo can result in serious injury,
possibly even death.
NOTICE: For outdoor use only.
Warranty
1 YEAR LIMITED WARRANTY
WHAT IS COVERED
This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your
item provided the item is maintained with care and used only for personal, residential purposes. The item is warranted to
be free from defects in material or workmanship for a period of 1 year.
WHAT IS NOT COVERED
We do not reimburse for transportation of delivery costs, or compensate the individual or any outside party for assembling
or disassembling the product.
Contact the Customer Service Team at 1-866-578-6569 or visit www.sunjoyonline.com.
2

Pre-Assembly
PLANNING ASSEMBLY
Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included and
Package Contents lists. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for
replacement parts.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Description
Part#
Label
Qty
M6 X 15 Bolt
H02015C11
AA
28
M6 Flat washer
BB
96
M6 X 35 bolt
H02035C11
CC
28
M6 Nut
H14001C11
DD
12
Big ring P90701B07007 FF 104
Dia. 6 X 230 Stake P12412C01001 GG 24
M6 X 25 bolt H02025C11 HH 32
M6 Wrench H00001C12 II 2
H19001C11
3

PACKAGE CONTENTS
Description
Part#
Label
Qty
Big post
A
4
Small post
P11176B01108
B
8
Fence
P11224A01108
C
8
Long screen 1
P11023D01108
D
2
Long screen 2
P11024D01108
E
2
Short screen 1
P11025D01108
F
2
Short screen 2
P11026D01108
G
2
Long mosquito net
tube
P12169A01108
H
4
Short mosquito net
tube
P12170A01108
I
4
Middle beam 1
P10407B01108
J
2
Middle beam 2
P10408B01108
K
2
Oblique beam
P10332B01108
L
4
Oblique beam
connector
P10333B01108
M
4
Big roof connector
P10141B01108
N
1
Small roof connector
P10142B01108
O
1
Small roof oblique
beam
P10264A01108
P
4
Decoration
P10039A01108
Q
1
Hook
P12601A01108
R
1
P11175B01108
4

Description
Part#
Label
Qty
Straight pipe
connector
P10839A01108
S
4
Small canopy
P00155B07011
T
1
Big canopy
P00156B07011
U
1
Mosquito net
P00340B01902
V
1
Wall
P00218B07011
W
1
5

Assembly
1
Attaching the long and short
screens
2
Attaching the screens to the
post
□ Insert the long screen 1 (D) into long screen 2 (E). Then
install straight pipe connector (S between the two
screens (D and E) using bolts (AA) and flat washers
(BB). Repeat this step to attach short screen 1 (F) and
short screen 2 (G).
□ Install the assembled screens to the big posts (A) using
bolts (CC) and flat washers (BB). You should now have
a rectangular frame.
3
Attaching the fence to the
post
4
Assembling the mosquito
netting tubes
□ Attach the fences (C) to the big posts (A) and small
posts (B) using bolts (HH) and flat washers (BB).
□ Attach the long mosquito net tubes (H) to the long
screens (D and E) and the short mosquito net tubes (I)
to the short screens (F and G) using bolts (AA) and flat
washers (BB).
6

Assembly (continued)
5
Assembling the oblique
beams
6
Assembling the roof
□ Insert the oblique beams (L) into oblique beam
connectors (M). Secure the oblique beam connectors
(M) to the U-shaped assembly using bolts (CC), flat
washer and nuts (DD).
NOTE: To avoid destroying the finish, please handle
it with care.
□ Insert the oblique beams (L) into the connecting tube of
big roof connector (N). Secure the hook (R) to the big
roof connector (N). Please note Connector (N) is marked
with K & L labels for insertion into proper tubes.
7
Attaching the middle beams
to the roof connector
8
Securing the middle beams
□ Insert the middle beams (J and K) into the big roof
connector (N). Follow labels on (N) for proper tube
insertion.
□ Install either middle beams 1 (J) or middle beams 2 (K)
to the U-shaped piece of the straight pipe connectors (S)
using bolts (CC), flat washers (BB) and nuts (DD).
Place the big canopy (U) on the assembled big roof.
Do not unfold it completely.
7

Assembly (continued)
9
Attaching the small roof
oblique beams
10
Attaching the decoration
□ Insert the small roof oblique beams (P) into the small
roof connector (O).
□ Assemble the small canopy (T) to the small roof oblique
beam (P) and assemble the decoration (Q) to the small
roof connector (O).
11
Attaching the small roof
oblique beam
12
Completing the assembly
□ Attach the small roof oblique beams (P) to the holes of
the oblique beams (L) using bolts (CC), flat washers
(BB), and nuts (DD). Put the big canopy (U) on top of
the assembly.
□
Use the big rings (FF) to hang the mosquito net (V) to
the mosquito net tubes (H and I). Please note there is a
short side (12 rings) and long side (14 rings) to netting.
Use the big rings (FF) to hang the wall (W) to the upper
screen tube. Secure the assembled gazebo to the lawn
using the Stakes (GG).
8

Care and Cleaning
Before using, clean the product completely with a soft, dry towel. When not in use, wipe free of any dirt or loose objects,
wash with a mild solution of soap and water; rinse thoroughly and dry completely.
•Do not use strong detergent or abrasive cleaners.
•Do not machine wash.
•Bolts can loosen over time. Be sure to check bolts occasionally, tightening as needed.
•This gazebo is not a permanent structure and should be disassembled & stored away after use.
•Our iron/steel components for garden accessories and patio items are coated with rust inhibiting paint that protects it
from rusting. However, due to the nature of iron, surface oxidation (rusting) will occur once these protective coatings are
scratched. This is a natural process and is not a defect! To minimize this condition, we recommend care when
assembling & handling the product to prevent scratching the paint. Should any scratching or damage occur, we
recommend immediate touch-up with rust inhibiting paint. Surface rust can also be easily removed with a very light
application of common cooking oil. If surface oxidation (rusting) occurs and if no measure is taken to prevent this, the
oxidation may start dripping on to deck or patio and cause damaging stains, which may be difficult to remove. This can
be prevented if measure is taken to keep the product from oxidizing
Important
Please do not return this product to the store. For technical assistance or replacement parts, please call Sunjoy Group at
1 [phone] anytime. You may fax your replacement parts form (which is included in the packaging) to
1 [phone] or email to custom[email protected]
Made in China
2018-01
9
出货年份2019+月份
