Sunjoy SummerCove A103003000 User manual

Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
ITEM/Article #：A103003000
WE HAVE YOU IN MIND, LET US SERVE YOU!
Nous pensons en vous, laissez nous vous aider!
Questions? Issues?/ Questions? Problèmes?
CONTACT US / Contactez-nous
[e-mail]
www.sunjoyonline.com

2/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
This product is intended for domestic outdoor use only.
The product should be placed on flat, horizontal ground.
Ensure enough clearance around the product. Before assembling the product, find level
ground not less than 6' (1.8 m) away from any structures or obstructions, such as fences,
garages, houses, overhanging branches, laundry lines, or electrical wires.
This gazebo is not to be regarded as part of a building/house structure. The gazebo is to be
anchored onto the ground for added safety. Do not assemble the gazebo onto soil/earth
ground. It is best advisable to have the gazebo built onto a wooden deck or concrete ground
for stability. If it is to be build onto a wooden deck/ground, do ensure that the wooden
deck/ground has a strong foundation. It is advisable to use appropriate floor plugs (not
provided) to anchor the gazebo onto the wooden/concrete ground.
Some structures may require two or more people to install safely. Check for underground
utilities before digging or driving stakes into the ground.
During installation, follow all safety warnings provided with your tools, and use safety glasses.
In case you set up more than one gazebo, keep a minimum distance of 10' (3 m) between the
gazebos.
Any assembly or maintenance of the product must be carried out by adults only.
Arrange necessary manpower when assembling or moving the product.
Some parts may contain sharp edges. Wear protective gloves if necessary.
Keep children and pets away while setting up the gazebo.
Check all nuts and bolts periodically to ensure bolts/nuts are tightened.
Repairing and replacing parts should be done by a qualified technician.
This gazebo is intended for decorative and sunshade purposes only, and it is not designed to
withstand harsh weather, including high winds, rain, and snow.
Do not light any fires inside or near the product！
Stay calm if fire breaks out. Search for the nearest exit. Do not return to the gazebo before
firemen allow you to do so.
Do not hang heavy weights on the roof frame.
Do not climb onto the roof of the gazebo. Falling off the gazebo can result in serious injury.
Retain the original packaging to store the gazebo.
Important Safety Instructions
Warning! To reduce the risk of serious injury, read the following safety instructions
before assembling and using the gazebo.
Please check with your local governing authority/local municipal codes regarding
installation of structures before assembly.
Caution!
Proper placement of your gazebo is essential.
Do not place the product underneath electrical lines.
Keep children away during assembly.
This product contains small parts which can be swallowed by children.
Keep fingers away from the places where they can be pinched or trapped.
Do not attempt to assemble the gazebo if any parts are missing.

•
•
•



•





•

•

•

•
•
•
•
•

•
•

•
•

•
•

•
Consignes de sécurité importantes
ATTENTION! 





Avertissement!



Country of Origin: China
Pais d’origine: Chine
Production Number: xxxxxxxxxx
Numéro de fabrication: xxxxxxxxxx
3 / 23

4/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
• Please read and understand this manual before any assembly. Beforebeginning
assembly of product, make sure all parts are present. Compare parts with packaging
contents list.
•When assembling wooden parts, do not overtorque the bolts to avoid splitting the wood.
See image illustration.
•Place all parts from the box in a cleared area and position themon the floor in front of you.
•Remove all packing materials and place them back into the box. Do not dispose of the
packing materials until assembly is complete.
•Read each step carefully before beginning any assembly and makesure you understand each
step. If you are missing a part, please email [email protected].
•Needed for assembly:（The following tools are not included）
•Veuillez lire et bien comprendre ce guide avant de procéder à l’assemblage. Avant de
procéder à l'assemblage du produit, assurez-vous que toutes les pièces sont présentes.
•Lors de l’assemblage de pièces en bois, ne serrez pas trop les boulons afin d’éviter de
fendre le bois.
•Consultez l'illus tration dans les schémas. Mettez toutes les pièces de la boîte dans une
zone dégagée et positionnez-les sur le sol devant vous.
•Retirez tous les matériels d’emballage et remettez-les dans la boîte. Ne les jetez pas avant
d'avoir terminé l'assemblage.
•Nécessaire pour l’assemblage : les outils suivants ne sont pas inclus.
IMPORTANT:
Cordless drill Hammer Screwdriver Ladder 3 people

5/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
EXPLODED DRAWING / VUE ÉCLATÉE

6/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
Parts List
Label Part Number Description Qty Part Image
A P00020063601 Post 1 2
B P00020063701 Post 2 2
C P00610016901 Base Cover 4
D P00010029301 Post Base 4
E P00040123001 Short Screen 2
F P00040122901 Long Screen 2
G P00060097101 Big Roof Top Beam 4
J P00050102501 Big Top Connector 1
K P00110053901 Big Canopy 1
L P00570058701 Adjustable Tube 4
M P00110054001 Small Canopy 1
N P005800001 Hook 1
P P00220034201 Fence 2
Q P005800028 Hook Rack 5
R P00210050201 Table Top 2
S P00500061501 Support Bar 1 2
T P00500063201 Support Bar 2 2

7/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
Hardware Pack
Label Part Number Description Qty Add Part Image
H1 H100010068 Bolt M6*15 36 2
H2 H100010069 Bolt M6*35 8 1
HS H070010001 Stake Φ6*180 8 0
HW H090010017 Wrench M6 1 0

8/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
Liste de Pièces
Étiquette Numéro de la
Pièce Description Quantité Numéro de la Pièce Diagramme
A P00020063601 Poteau 1 2
B P00020063701 Poteau 2 2
C P00610016901 Cache de base 4
D P00010029301 Base de poteau 4
E P00040123001 Écran court 2
F P00040122901 Écran long 2
G P00060097101 Grande poutre de toit 4
J P00050102501 Connecteur chapiteau 1
K P00110053901 Grande verrière 1
L P00570058701 Tube réglable 4
M P00110054001 Petit auvent 1
N P005800001 Accrocher 1
P P00220034201 Clôture 2
Q P005800028 Crochet Rack 5
R P00210050201 Dessus de la table 2
S P00500061501 Barre de soutien 1 2
T P00500063201 Barre de soutien 2 2

9/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
Pack Quincaillerie
Étiquette Numéro de la
Pièce Description Quantité Add Numéro de la Pièce Diagramme
H1 H100010068 Boulon M6*15 36 2
H2 H100010069 Boulon M6*35 8 1
HS H070010001 Pieu Φ6*180 8 0
HW H090010017 Clé M6 1 0

10 / 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
1

11 / 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
2

12/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
3

13/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
4

14/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
5

15/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
6

16 / 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
7

17/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
8

18/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
9

19/ 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
10

20 / 23
Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
11
