Sunnydaze Decor RTA-089 User manual

Lavina
WINE CABINET WITH GLASS & BOTTLE STORAGE
RTA- 089
Carefully review assembly and care instructions before using this product. Save this document for future reference.

Thank you for choosing Sunnydaze Decor. We stand behind our brand and the quality of the items we sell.
Replacement parts or products will be sent at our discretion within the 1-year warranty period. Proof of purchase, with
the date of purchase as well as photos of the merchandise defect, must be provided. Photos are used to determine
the cause of defects and for future quality control. Register your warranty at https://tiny.cc/SunnydazeWarranty
If you have any questions, comments or concerns, feel free to contact us by phone at 833-982-1977, by email:
[e-mail], or via our contact us page at https://tiny.cc/SunnydazeContact
Purchase Date: / / Order/Customer Reference Number:
  
ABottom Panel 1
BLeft Panel 1
CRight Panel 1
DMiddle Panel 1
ETop Panel 1
FLeft Shelf 3
GRight Shelf 1
HLeft End Panel 2
IRight End Panel 1
JRight Side Middle Panel 1
KRight Side Small Shelf 2
LDiagonal Panel 4
MDoor 1
NLeft Backing Board 1
ORight Backing Board 1
Inspect packaging to ensure all
parts are accounted for before
disposing of packing materials.
CHOKING HAZARD — This item contains small parts that can be
swallowed. Keep children and pets away during assembly.
WARNING
  
1Wood Dowel 52
2Spreading Bolt 31
3Cam Lock 31
4Cover Cap 31
5Handle + 3/4" Screws 1
6Door Stop 2
7Hinge + M8 x 1/2" Screws 2
8Nail 23
9Stemware Rack 1
10 Foot 4
11 M6 x 9/16" Flat Screw 3
12 Rear Panel Clamp 5
13 M6 x 1/2" Screw 16
14 Tipover Restraint Kit 2
Page 1 / 9
 (not included)
Phillips Screwdriver Rubber Mallet Hammer Power Drill with
1/8" Bit & 1/4" Bit
10/2022

INTRODUCTION
Instrucciones
Instructions


Read the manual carefully to ensure you fully understand
all use, care, assembly, and safety information.
Read this manual carefully and
follow the assembly instructions
in the order listed. Pay close
attention to assembly drawings.
Regularly clean with a clean
    
accumulation.
Do not paint the unit.
Do not use abrasive materials or
cleaners to clean the furniture;
only use a slightly moistened cloth.
Indoor use only.
Do not expose the furniture to
heat or humidity.
When cleaning nearby the
furniture, do not allow contact
with water or cleaners as they
can deteriorate the furniture.
Do not allow metal components
to come in contact with water or
cleaners as it may cause rust and
staining.

dry surface.
Use a soft, protective barrier when
assembling the furniture.
TIP: Use the box carton as a
protective layer to separate and
protect the parts from scratches and
other damage during assembly.
Do not push or drag furniture as
doing so may damage the unit.
Only move furniture when it is empty.
Always ask for help when moving
furniture.
Avoid Accidents - Do not climb, sit
or stand on the furniture.
Do not allow children to play on or
inside the furniture.
Keep sharp objects away as they
may scratch or damage the unit.
Do not use the furniture as a writing
surface without a padded barrier.
Lavina
Install wood dowels by gently tapping
them into the designated hole using a
rubber mallet.
    
pressing them into the hole or gently
tapping with a rubber mallet until the

Align the cam lock opening (arrow)
with the pre-drilled hole on the side
of the panel. Use a screwdriver to
adjust alignment as needed.
Wood Dowel Spreading Bolt Cam Lock
IMPORTANT INSTALLATION INFORMATION
For the stability of the unit, it is important that furniture connectors are installed correctly.
See drawings and tips below for proper installation.
Page 2 / 910/2022

Lavina
ASSEMBLY
STEP 1
D: 1
1: 4
2: 5
3: 2
Review all steps carefully and understand assembly before beginning.
STEP 2
2: 3
STEP 3
H: 2
1: 8
3: 8
STEP 4 STEP 5
I: 1
1: 4
3: 3
STEP 6
 
 

Spreading Bolts (2), and two Cam
Locks (3) into Middle Panel (D) as
shown.
Turn the panel over.
Install three Spreading Bolts (2)
into Middle Panel (D) as shown.
Then, turn the panel over.
Install four Wood Dowels (1) and
four Cam Locks (3) into Left End
Panel (H) as shown.
Repeat this step on the remaining
Left End Panel (H).
As indicated in the drawing, align
the dowel in Left End Panels (H)
with Middle Panel (D).
Then, use a screwdriver to turn
the cam lock until it locks onto the
head of the spreading bolt.
Install four Wood Dowels (1) and
three Cam Locks (3) into Right
End Panel (I) as shown.
As indicated in the drawing, align
the dowel in Right End Panel (I)
with Middle Panel (D).
Use a screwdriver to turn the cam
lock until it locks onto the head of
the spreading bolt.

Page 3 / 910/2022

STEP 7
J: 1
1: 4
2: 1
3: 2
STEP 8
2: 1
STEP 9
K: 2
1: 8
3: 4
STEP 10 STEP 11
G: 1
1: 4
2: 1
3: 2
STEP 12
 
 
Install four Wood Dowels (1), one
Spreading Bolt (2), and two Cam
Locks (3) into Right Side Middle
Panel (J) as shown.
Turn the panel over.
Install one Spreading Bolt (2) into
Right Side Middle Panel (J) as
shown.
Turn the panel over.
Install four Wood Dowels (1) and
two Cam Locks (3) into Right Side
Small Shelf (K) as shown.
Repeat this step on the remaining
Right Side Small Shelf (K).
   
are on the bottom, align two
Small Shelves (K) with Right Side
Middle Panel (J) and secure the
cam locks.
Install four Wood Dowels (1), one
Spreading Bolt (2), and two Cam
Locks (3) into Right Shelf (G) as
shown.

facing down, align Right Shelf (G)
with Right Side Middle Panel (J)
and secure the cam lock.
Lavina

Page 4 / 910/2022

Lavina
STEP 13 STEP 14
F: 3
1: 12
3: 6
STEP 15
STEP 17
  
 
STEP 16
B: 1
1: 4
2: 5
3: 2
7: 2
STEP 18
C: 1
1: 4
2: 3
3: 2

on the bottom, align Right Shelf
(G) and Right Side Small Shelf (K)
with Middle Panel (D) and secure
the cam locks.
Install four Wood Dowels (1) and
two Cam Locks (3) into Left Shelf
(F) as shown.
Repeat this step on the two
remaining Left Shelves (F).
   
are on the bottom, align three Left
Shelves (F) with Middle Panel (D)
and secure the cam locks.

Spreading Bolts (2), and two Cam
Locks (3) into Left Panel (B) as
shown.
Loosely secure two Hinges (7).
Do not fully tighten the hinge screws.
Save the remaining screws for Step 27.
Ensuring the hinges are installed
on the front of the unit, fasten Left
Panel (B) to Left Shelves (F) and
Left End Panels (H) by aligning
the dowels and securing the cam
locks.
Install four Wood Dowels (1), three
Spreading Bolts (2), and two Cam
Locks (3) into Right Panel (C) as
shown.
Page 5 / 910/2022

Lavina
STEP 19 STEP 20
E: 1
2: 6
6: 1
9: 1
11: 3
STEP 21
  
 
STEP 22
A: 1
10: 4
13: 16
STEP 24STEP 23
2: 6
6: 1
As shown, align Right Panel (C)
with the right side of the unit and
secure the cam locks.
Install six Spreading Bolts (2) and
one Door Stop (6) into Top Panel
(E) as shown.
Next, align Stemware Rack (9)
 
x 9/16" Flat Screws (11).
Ensuring the glass rack is on the
right, align Top Panel (E) with the
top of the unit and secure the cam
locks.
Secure one Foot (10) to the bottom
of Bottom Panel (A) using four M6
x 1/2" Screws (13).
Repeat to connect the remaining
three Feet (10).
Turn the panel over.
Install six Spreading Bolts (2) and
one Door Stop (6) into Bottom
Panel (A) as shown.
Align Bottom Panel (A) with the
dowels and cam locks on the
bottom of the unit. Secure the cam
locks.
With assistance, carefully and

Assistance is required for turning unit.

Page 6 / 910/2022

Assistance is recommended for this step.
Lavina
STEP 26
M: 1
5: 1


STEP 27
L: 4
4: 31
STEP 25
N: 1
O: 1
8: 23
12: 5

Place Left Backing Board (N) and Right Backing Board (O)
on the back of the cabinet, ensuring they are evenly aligned.
Fasten the outer edges using eighteen Nails (8), and the

Firmly fasten Handle (5) to Door (M) using the
3/4" Screws that are packaged with the handle.
Assistance recommended to hold panels
steady while the back panels are fastened.
Door Adjustment Procedure:
Please note, care must be taken during hinge adjustment to avoid damage.
Only a slight adjustment is required. Rotate the Door Adjustment screw 1/8 to
1/4 turns at a time, then check the door position. Rotate adjustment screws as
necessary until doors are properly aligned.
With assistance, align Door (M)
with Left Panel (B) and secure
the hinges to the door using the
remaining 1/2" Screws.
Before beginning this step, refer to the
Door Adjustment Procedure
With the angled edges facing inward, slide four
Diagonal Panels (L) into the spaces on the
bottom right of the unit, as shown.
Cover all cam locks using Cover Caps (4).
Page 7 / 910/2022

Top
Lavina
STEP 28
14: 2

IMPORTANT:
Carefully measure the location of pilot hole before
drilling and installing the wall anchor.
WARNING:
Check for pipes and electrical wiring before drilling.
 
Assistance required for moving the furniture.
IMPORTANT: The included wall anchor is suitable for drywall. Use a drill bit suited for your wall material; if the drill bit is too
large, the tipover restraint system will be faulty.

Carefully measure and mark the location of screw installation and pilot holes before drilling. Measure twice, drill once!
Tipover Restraint Installation
• Use a 1/8" drill bit to drill two small pilot holes on the back of the furniture top.
• Securely fasten one end of the tipover restraint strap using the M8 x 1/2" Screw. Repeat to connect the
second strap.
• Place the unit against the wall and mark the position for drilling the wall anchor pilot hole.
• Use a power drill with a 1/4" drill bit to drill pilot holes to the depth of the wall anchor, approximately
30mm deep. For walls made from softer materials, we recommend using a smaller drill bit to ensure the
wall anchor remains snug inside the pilot hole.
• Insert the wall anchor until the wall anchor opening is flush with the wall.
• Align the unit with the wall anchor and secure the unit to the wall using the included M8 x 1" Screw.
NOTICE: Manufacturer and seller expressly disclaim any and all liability from personal injury, property damage
or loss, whether direct or indirect, or incidental, resulting from the incorrect attachment, improper use, inadequate

Page 8 / 910/2022

NOTICE:
Manufacturer and seller expressly disclaim any and all liability from personal injury, property damage
or loss, whether direct or indirect, or incidental, resulting from the incorrect attachment, improper use,


SAFETY STATEMENTS & WARNINGS
• For indoor use only.
• This product is for residential use only; institutional or commercial use will automatically void the warranty.
• Ensure all fittings are tight before use. Periodically check fittings to ensure they remain tight.
• Only use this unit on a flat, level surface.
• Never sit, stand or climb on the unit.
• Never allow children to stand, climb, or hang on doors or shelves.
• Do not place hot items or liquids directly on the furniture.
• Never use chemical cleaning products or polishes as doing so may damage the finish.
• Do not exceed the weight capacity of the furniture.
• Do not overload shelves as doing so may cause them to sag.
• Always place the heaviest items on the lowest shelves.
• Avoid long-term exposure to sunlight.
• Avoid placing the unit near heating or cooling vents as forced air is very drying and can damage the unit.
• Do not write on furniture without a padded barrier to protect the surface.
Lavina 10/2022 Page 9 / 9
If you experience issues with assembly or the product was damaged during shipping,
please contact our customer service team directly through one of the methods mentioned at the top of page 1.
Please have the item number and order information ready to expedite response time.
