LED Bollard Light
Important: Read all instructions prior to installation. BLRB and BLSB Series
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V1.0 01/11/2022
User Manual
Safety and Notes
Installation Kits
Wiring Diagram
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Green
Dim (+)
Dim (-)
Purple
+ +
- -
Grey or Pink
WARNING—RISK OF FIRE, ELECTRIC SHOCK, INJURY, OR PROPERTY DAMAGE.
• To reduce the risk of electric shock, ensure that the main power source and circuit
breakers are switched o󰀨 before performing any installation or wiring procedures.
• Product should be installed and serviced by a certied electrician in accordance
with applicable national, state, and local building and electrical codes.
• Ensure all mounts are securely attached and the foundation will support the weight
of the xture. Failure to properly support xture may result in damage or injury, for
which the manufacturer does not assume responsibility.
• Mount using the appropriate installation kit as o󰀨ered by the manufacturer only.
CAUTION
• Edges may cut—wear gloves while handling or servicing this equipment.
• Inspect equipment for shipping damage before installation.
• Clean using a dry, soft cloth only. If necessary, use a mild detergent and luke warm
water to remove grease. Do not use undiluted detergents or those that contain
abrasives or sealants.
Check product label for specific electrical
specifications related to installation.
Improper installation will void warranty.
12 - Nut
3 - SpringWasher
6 - FlatWasher
1 - Anchor Bolt Carrier
3 - Anchor Bolt 4 - Anchor Bolt
1 - Anchor Bolt Carrier
16 - Nut
4 - SpringWasher
8 - FlatWasher
BLRB-KIT
INSTALLATION
BLSB-KIT
1-1/2~2”
With electrical conduit in place, mount anchor
bolts in concrete using the carrier to maintain
proper spacing. Install so that 1.5–2 in. of the
anchor bolt remains exposed above the surface.
120–277 VAC Input
0–10 V Dimming
LED Bollard Light
Important: Read all instructions prior to installation. BLRB and BLSB Series
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V1.0 01/11/2022
User Manual
1. With installation kit mounted and cement/concrete cured, mount bollard base
using provided installation kit hardware and connect wiring using terminal block.
When making adjustments, switch supply power to the light o󰀨
if it is already installed. To select wattage and CCT, remove the
light section to access the switches located on the bottom. Slide
the selector switch to the desired setting, then reinstall the light
section of the bollard.
CCT and wattage adjustment switches
Bollard Installation
CCT and Wattage Selection (applicable models only)
hheexx wwrreenncchh hheexx wwrreenncchh
2. Rotate bollard and place in position over bollard base.
3. Tighten set screws to secure bollard to base.
12W
16W
22W
3000K
4000K
5000K
