superbrightleds WPR Series User manual

Rotatable LED Wall Pack
Important: Read all instructions prior to installation. WPR2 / WPRCCT
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V1 10/19/2020
5yr
User Manual
120–277 VAC Input
0–10 V Dimming
Safety and Notes
SpecicationsWiring Diagram
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Dim (+)
Dim (-)
Purple
+ +
- -
Gray
Yellow / Green
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Dim (+)
Dim (-)
Purple
+ +
- -
Gray
Yellow / Green
• Product should be installed and serviced by a certied electrician in accordance
with applicable national, state, and local building and electrical codes.
• To reduce the risk of electric shock, ensure that the main power source and circuit
breakers are switched o󰀨 before performing any installation or wiring procedures.
• Avoid looking directly into lamp when illuminated.
• Ensure all mounts are securely attached and will support the weight of the xture.
Failure to properly support xture may result in damage or injury, for which the
manufacturer does not assume responsibility.
• Photocell sensor on 25 W and 40 W models can be disabled by unplugging it and
capping the connector that was attached to the sensor. 60 W, 80 W, and 120 W
models will require rewiring to bypass the sensor in order to disable it.
Model WPRx-x-xST1-BRP
Operating Temperature -4°–113° F (-20°–45° C)
IP Rating IP65
Dimming 0–10 V
Check product label for specific electrical
specifications related to installation.
Improper installation will void warranty.
Opening Fixture
1/8” Drill Bit
Gasket
4.64 in
[118 mm]
4.64 in
[118 mm]
3.66 in
[93 mm]
3.66 in
[93 mm]
WPR2-50K120-FST1-BRP

Rotatable LED Wall Pack
Important: Read all instructions prior to installation. WPR2 / WPRCCT
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V1 10/19/2020
5yr
User Manual
Installation
CCT Adjustment
1. Remove screws and swing front housing to separate it from the rear housing.
2. Drill holes in rear housing for mounting. For junction box wiring, remove rear pipe
plug and for conduit mounting remove one of the side pipe plugs.
3. Measure and create mounting holes on wall if needed.
4. Apply gasket and mount rear housing.
5. On eld-selectable CCT models, select desired CCT using switch.
6. With supply power o󰀨, connect wiring.
7. Mount front housing to rear.
Field-selectable CCT can be set using the internal switch as shown.
Make certain supply power is o󰀨 when performing this procedure.
1/8” Drill Bit
Gasket
4.64 in
[118 mm]
4.64 in
[118 mm]
3.66 in
[93 mm]
3.66 in
[93 mm]
1/8” Drill Bit
Gasket
4.64 in
[118 mm]
4.64 in
[118 mm]
3.66 in
[93 mm]
3.66 in
[93 mm]
1/8” Drill Bit
Gasket
4.64 in
[118 mm]
4.64 in
[118 mm]
3.66 in
[93 mm]
3.66 in
[93 mm]
1/8” Drill Bit
Gasket
4.64 in
[118 mm]
4.64 in
[118 mm]
3.66 in
[93 mm]
3.66 in
[93 mm]
