superbrightleds MWPE Series User manual

LED Teardrop Mini Wall Pack with Emergency Backup
Important: Read all instructions prior to installation. MWPE Series
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V2 07/14/2022
5yr
User Manual
Specications
Safety and Notes
Wiring Diagram
CCT Selection
Line
Neutral
Ground
Black
L L
Line Blue
L L
N N
GND GND
White
Dim (+)
Dim (-)
Purple
+ +
- -
Gray/Pink
Yellow / Green
• Product should be installed and serviced by in accordance with applicable
national, state, and local building and electrical codes.
• To reduce the risk of electric shock, ensure that the main power source and
circuit breakers are switched o󰀨 before performing any installation or wiring
procedures.
• Avoid looking directly into lamp when illuminated.
• Ensure all mounts are securely attached and will support the weight of the
xture. Failure to properly support xture may result in damage or injury, for
which the manufacturer does not assume responsibility.
• Photocell sensor can be disabled by unplugging it and capping the connector
that was attached to the sensor.
• Do not connect emergency battery until all other possible mounting and wiring
are complete. Make certain supply power is o󰀨 when initially connecting the
emergency battery.
• Emergency battery requires at least 24 hours of charge time between uses
or before initial testing.
To select CCT, open the wall pack and use internal switch
to set the desired color temperature. This process should
be done prior during installation. If adjustment is needed
after installation, make certain to remove supply power
before opening the wall pack or making any changes.
Model MWPE-SW15WD-BRP
Ambient Operating Temperature 32°–113° F (0°–45° C)
Environmental Rating IP65
Dimming 0–10 V
Photocell Operation Light will turn on when the ambient light level falls below 30 lx
and will turn o󰀨 when the ambient light level exceeds 130 lx.
Check product label for specific electrical
specifications related to installation.
Improper installation will void warranty.
120–277 VAC Input
0–10 V Dimming
3500K 4000K 5000K

LED Teardrop Mini Wall Pack with Emergency Backup
Important: Read all instructions prior to installation. MWPE Series
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V2 07/14/2022
5yr
User Manual
Installation
1. Remove screw covers and screws and
separate front and rear housings.
Note: There will be two electrical connectors
that connect the front and rear, which will
need to be disconnected once the xture
is open as well.
2.Select desired CCT value on internal switch.
3.Drill holes in rear housing for mounting, and
remove plug for wiring.
4.Mount rear housing to junction box/wall,
making certain to use the included gasket.
5. With supply power o󰀨, connect supply wiring.
6.Connect the plugs for the emergency battery.
7. Reconnect electrical plug running from front
to rear housing and reattach front housing
to rear housing.
8.Once secure, apply power and check for
proper operation.
Note: Emergency operation test button is at
the bottom of the xture. Fixture will need to
charge for 24 hours before initial test.
