superbrightleds RWLA Series User manual

LED Street Light
Important: Read all instructions prior to installation. RWLA Series
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V1.0 02/24/2019
5yr
User Manual
Optional Mounts Photocell/Shorting Cap Installation
Safety and Notes
Environmental Specications
Operating Temperature -40°–122° F(-40°–50° C)
IP Rating IP65
Pole/Post Mount (RWLA-PM)
• Product should be installed and serviced by a certied electrician
in accordance with applicable national, state, and local building
and electrical codes.
• To reduce the risk of electric shock, ensure that the main power
source and circuit breakers are switched o󰀨 before performing
any installation or wiring procedures.
• Avoid looking directly into lamp when illuminated.
• Ensure all mounts are securely attached and will support the
weight of the xture. Failure to properly support xture may
result in damage or injury, for which the manufacturer does not
assume responsibility.
Specications
RWLA-xK120AT2-GRSF
Check product label for specific electrical
specifications related to installation.
Improper installation will void warranty.
Photocell or
Socket
Shorting Cap
Wiring Diagram
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Dim (+)
Dim (-)
Purple
+ +
- -
Gray
Green
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Dim (+)
Dim (-)
Purple
+ +
- -
Gray
Green

LED Street Light
Important: Read all instructions prior to installation. RWLA Series
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V1.0 02/24/2019
5yr
User Manual
Pole/Post Knuckle Mount (RWLA-PM) Installation
Round Adjustable Fitter Mount Installation
Photocell or
Socket
Shorting Cap
Photocell or
Socket
Shorting Cap
1. Remove the center bolt to separate mount from light xture.
2. Run wiring through mount and reattach mount to light.
3. With supply power o󰀨, make all wiring connections.
4. Install photocell or shorting cap.
5. Attach mount to pole and tighten bolts to secure. Adjust angle by loosening center
bolt, tighten once at desired angle.
1. Remove the center bolt to separate the slip-tter mount from the
light and set the mount aside.
2. Remove access panel from side of pole/post mount.
3. Run wiring through the pole/post mount and connect mount to light.
4. Make appropriate mounting and wiring holes in pole/post and attach
mount to pole/post.
5. With supply power o󰀨, use the side access panel to connect wiring,
then close access panel.
6. Install photocell or shorting cap.
7. Adjust angle of light by loosening center bolt, then tighten once
at desired angle.
.70in
17.78mm
0.31in
8mm
5.5in
139.7mm
RWLA-PM
2.51in
63.75mm
