superbrightleds RSL Series User manual

Recessed LED Step Lights
User Manual
Part Number:
Important: Read all instructions prior to installation. RSL-Series
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V1 09/26/2018
Included Parts
Optional Accessories
Specications
Safety and Notes
1 - step light (stainless steel or black nish)
1 - wire pigtail
RSL-6S - six light wire harness for single color light
RSL-S2M - 6.6 ft (2 m) extension harness for single color light
RSL-6RGB - six light wire harness for RGB lights
RSL-RGB3M - 9.8 ft (3 m) extension harness for single RGB light
• This product should be installed and serviced in accordance with
applicable national, state, and local building and electrical codes.
• To reduce the risk of electric shock, ensure that the main power source
and circuit breakers are switched o󰀨 before performing any installation
or wiring procedures.
• While the light is IP68 water-resistant, the connectors built into the
harness are not.
• When interconnected, each six light accessory harness will support
ve lights each instead of six.
Installation
1. Mark and drill 5/8” hole in mounting surface.
2. Make electrical connection
3. Test t light. If needed, apply silicone adhesive
to assist in securing light.
Model RSL-xK1-x RSL-RGB1-x
Total Power Consumption 1 Watts
Operating Voltage Range 12 VDC
Operating Temperature -4–122° F (-20–50° C)
Beam Angle 150°
Control/Dimming PWM 12 VDC RGB controller
Warranty 3 Years
Dimensional Drawings RSL-40K1-S (Dimensions represent all models)

Recessed LED Step Lights
User Manual
Part Number:
Important: Read all instructions prior to installation. RSL-Series
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V0.1 09/06/2018
Dimensional Drawings RSL-6RGB (Dimensions also represent RSL-6S)
RSL-S2MRSL-RGB3M
TOTAL LENGTH
17.50in
444.50mm
1.70in
43.18mm
10ft
3048mm
17.50in
444.50mm
1.42in
36.07mm
1.39in
35.39mm
PIG TAIL
(5 total per harness)
1.39in
35.39mm
117.19in
2976.62mm
76.19in
1935.22mm
10ft
3048mm
79in
2006.6mm
1.42in
36.07mm
1.39in
35.39mm
1.42in
36.07mm
