superbrightleds ALKW9-RGB93 User manual

Instructional Sheet
Part Number:
4400 Earth City Expy, St. Louis MO 63045 866-590-3533 [email protected]
ALKW9-RGB93
Important: Read all instructions prior to installation.
Diagram 1
Remote Battery Replacement
Remote Functions
1. Remove three philips head screws and remove the button panel.
2. Carefully remove battery and replace with new.
3. Reposition button panel then insert and tighten screws
1. Connect strips to the connection box then connect to the Adapter Cable
with the “To Splitter” arrow towards the Connection Box. Connect the other
end of the Adapter Cable with the “To Controller” arrow towards the Controller.
Temporarily apply power to the controller and test strip locations for proper
lighting effect.
2. Mark the desired location of the strips. Mount strips using double sided tape
or silicone in desired location and away from heat sources and moving parts.
3. Mount controller and connection box in dry locations away from heat sources
and moving parts and route power wires to power source then connect. Route
white antenna wire away from metal objects for maximum operating range.
Multi Color 9 Piece Accent Light Kit
3 - 10.7” Waterproof Accent Light Strips
2 - 8.8” Waterproof Accent Light Strips
4 - 4.8” Waterproof Accent Light Strips
1 - RF RGB Accent Light Controller
1 - RF Wireless Key Chain Remote
Parts Included
Installation
Specications
RGB LED Flexible Light Strip
Battery
1/4” Snap Spades
Connection Box
Adapter Cables
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
Power Supply
OR
CPS connector
(CPS-F2ST)
(CPS-12VDC-50W)
Fuse 3A
RGB LED Flexible Light Strip
Connection Box
Adapter Cables
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
White
Antenna
Blue
Brake
Override
To Brake
Switch
To Splitter To Controller
Adapter Cable
RF Controller
RCW-RFRGB
To Splitter
To Controller
Adapter Cable
RCW-RFRGB
Black
Ground
Red
Power In
Blue
Wire
RF Controller
Running Light Cicuit (+)
Ground
White
Antenna
PSC-164
Brake Light
Circuit (+)
1 - Connection Box
1 - Adapter Cable (LC4 to LC4)
9 - Adapter Cables (LC4 to 4pin)
1 -12V 27A Battery
Input Voltage 9~14.5 VDC
Controller Output Current 3 x 1A Maximum
Fuse Size 3A
Operating Temperature -4 ~149° F (-20~65° C)
Strip IP Rating Waterproof IP68
Static Color Dynamic Modes 2
Seven Color Dynamic Modes 2
Static Colors 18
Override Mode 1
Brightness Levels 5
Remote Battery 12V 27A x 1
Remote Range 33 Feet (10m) Maximum
Remote Frequency 315 MHz
FCC ID 2AFXS-JX-R001
Warranty 2 Years
Remote comes paired to the controller. Use the following procedure if additional
remotes are required.On power up, LEDs will be green indicating pairing mode
for three seconds. During green pairing mode, press button “A” then “B” to pair a
new remote.
Remote Pairing
Wiring
Output Connector Polarity Purpose
Black Positive (+) Common Anode
Red Negative (-) Red LED Cathode
Green Negative (-) Green LED Cathode
Blue Negative (-) Blue LED Cathode
Input Wires Polarity Purpose
Black Negative (-) Ground In (-)
Red Positive (+) 9~14.5 VDC Power In (+)
Blue (see below) Positive (+) 9~14.5 VDC Red Override Signal In (+)
Blue wire activates red single color mode at full brightness while voltage is applied.
Use for brake override if required. Works as brake override even when controller is
in standby mode.
Button Functions
Cycles up through 18 single color modes and two 7 color modes.
Press and hold for dimming 80%, 60%, 40%, 20% and back to
100% during single color modes.
Activates Flash Modes during single color modes. Switches
between Flash/Flash/Long Pause and Flash/Flash/Short Pause
during ash modes. Increases cycle speed during 7 color modes
Activates Fading Mode during single color modes. Decreases
cycle speed during 7 color modes.
On/Off
Hold for 6 seconds to return to Mode 1 (Static Red)
RCW-RFR
Slide Cover

Instructional Sheet
Part Number:
4400 Earth City Expy, St. Louis MO 63045 866-590-3533 [email protected]
ALKW9-RGB93
Important: Read all instructions prior to installation.
Multi Color 9 Piece Accent Light Kit
Mode Sequence & Functions
Mode Button A Button B Button C Button D
1 Red Flash Modes Fade Mode On/Off
2 Blue Flash Modes Fade Mode On/Off
3 Light Pink Flash Modes Fade Mode On/Off
4 Green Flash Modes Fade Mode On/Off
5 Gold Flash Modes Fade Mode On/Off
6 Light Blue Flash Modes Fade Mode On/Off
7 Orange Flash Modes Fade Mode On/Off
8 Hot Pink Flash Modes Fade Mode On/Off
9 Light Green Flash Modes Fade Mode On/Off
10 Cool White Flash Modes Fade Mode On/Off
11 Aqua Flash Modes Fade Mode On/Off
12 Pale Rose Flash Modes Fade Mode On/Off
13 Purple Flash Modes Fade Mode On/Off
14 White Flash Modes Fade Mode On/Off
15 Warm White Flash Modes Fade Mode On/Off
16 Sky Blue Flash Modes Fade Mode On/Off
17 Sea Green Flash Modes Fade Mode On/Off
18 Lemon Flash Modes Fade Mode On/Off
19 7 Color Flash Speed Up Speed Down On/Off
20 7 Color Fade Speed Up Speed Down On/Off
