superbrightleds ALKW5-RGB45 User manual

Instructional Sheet
Part Number:
4400 Earth City Expy, St. Louis MO 63045 866-590-3533 [email protected]
ALKW5-RGB45
Important: Read all instructions prior to installation.
Diagram 1
Remote Battery Replacement
1. Remove three philips head screws and remove the button panel.
2. Carefully remove battery and replace with new.
3. Reposition button panel then insert and tighten screws
1. Connect strips to the connection box then connect to the Adapter Cable with
the “To Splitter” arrow towards the Splitter Cable. Connect the other end of the
Adaptor Cable with the “To Controller” arrow towards the Controller. Temporarily
apply power to the controller and test strip locations for proper lighting effect.
2. Mark the desired location of the strips. Mount strips using double sided tape
or silicone in desired location and away from heat sources and moving parts.
3. Mount controller in a dry location away from heat sources and moving parts
and route power wires to power source then connect. Route white antenna wire
away from metal objects for maximum operating range.
Multi Color 5 Piece Accent Light Kit
5 - 5” Weatherproof Accent Light Strips
1 - RF RGB Accent Light Controller (RCW-RFRGB)
1 - RF Wireless Keychain Remote (RCW-RFR)
1 - Adapter Cable (LC4 to LC4)
1 - Splitter Cable
1 - 12V 27A Battery
Parts Included
Installation
Specications
RGB LED Flexible Light Strip
5-way
Splitter
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
RGB LED Flexible Light Strip
5-way
Splitter
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
Battery
OR
CPS connector
(CPS-F2ST)
Fuse 3A
1/4” Snap Spades
Power Supply
(CPS-12VDC-50W)
White
Antenna
Black Ground
Blue
Brake
Override
To Brake
Switch
To Splitter To Controller
Adapter Cable
RF Controller
RCW-RFRGB
To Splitter
To Controller
Adapter Cable
RCW-RFRGB
Black
Ground
Red
Power In
Blue
Wire
RF Controller
Running Light Cicuit (+)
Ground
White
Antenna
PSC-164
Brake Light
Circuit (+)
Input Voltage 9~14.5 VDC
Controller Output Current 3 x 1A Maximum
Fuse Size 3A
Operating Temperature -4 ~149° F (-20~65° C)
Strip IP Rating Weatherproof IP65
Static Color Dynamic Modes 2
Seven Color Dynamic Modes 2
Static Colors 18
Override Mode 1
Brightness Levels 5
Remote Battery 12V 27A x 1
Remote Range 33 Feet (10m) Maximum
Remote Frequency 315 MHz
FCC ID 2AFXS-JX-R001
Warranty 2 Years
Button Functions
Cycles up through 18 single color modes and two 7 color modes.
Press and hold for dimming 80%, 60%, 40%, 20% and back to
100% during single color modes.
Activates Flash Modes during single color modes. Switches
between Flash/Flash/Long Pause and Flash/Flash/Short Pause
during ash modes. Increases cycle speed during 7 color modes
Activates Fading Mode during single color modes. Decreases
cycle speed during 7 color modes.
On/Off
Hold for 6 seconds to return to Mode 1 (Static Red)
RCW-RFR
Remote comes paired to the controller. Use the following procedure if additional
remotes are required.On power up, LEDs will be green indicating pairing mode
for three seconds. During green pairing mode, press button “A” then “B” to pair a
new remote.
Remote Pairing
Remote Buttons
Wiring
Output Connector Polarity Purpose
Black Positive (+) Common Anode
Red Negative (-) Red LED Cathode
Green Negative (-) Green LED Cathode
Blue Negative (-) Blue LED Cathode
Input Wires Polarity Purpose
Black Negative (-) Ground In (-)
Red Positive (+) 9~14.5 VDC Power In (+)
Blue (see below) Positive (+) 9~14.5 VDC Red Override Signal In (+)
Blue wire activates red single color mode at full brightness while voltage is applied.
Use for brake override if required. Works as brake override even when controller is
in standby mode.
Slide Cover

Instructional Sheet
Part Number:
4400 Earth City Expy, St. Louis MO 63045 866-590-3533 [email protected]
ALKW5-RGB45
Important: Read all instructions prior to installation.
Multi Color 5 Piece Accent Light Kit
Mode Sequence & Functions
Mode Button A Button B Button C Button D
1 Red Flash Modes Fade Mode On/Off
2 Blue Flash Modes Fade Mode On/Off
3 Light Pink Flash Modes Fade Mode On/Off
4 Green Flash Modes Fade Mode On/Off
5 Gold Flash Modes Fade Mode On/Off
6 Light Blue Flash Modes Fade Mode On/Off
7 Orange Flash Modes Fade Mode On/Off
8 Hot Pink Flash Modes Fade Mode On/Off
9 Light Green Flash Modes Fade Mode On/Off
10 Cool White Flash Modes Fade Mode On/Off
11 Aqua Flash Modes Fade Mode On/Off
12 Pale Rose Flash Modes Fade Mode On/Off
13 Purple Flash Modes Fade Mode On/Off
14 White Flash Modes Fade Mode On/Off
15 Warm White Flash Modes Fade Mode On/Off
16 Sky Blue Flash Modes Fade Mode On/Off
17 Sea Green Flash Modes Fade Mode On/Off
18 Lemon Flash Modes Fade Mode On/Off
19 7 Color Flash Speed Up Speed Down On/Off
20 7 Color Fade Speed Up Speed Down On/Off
FCC Statement
Auxilary Running/Brake Light Example
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation. Any changes or
modifications in construction of this device which are not expressly approved
by the party responsible for compliance could void the user’s authority to
operate the equipment.
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between equipment and receiver.
–Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
–Consult the dealer or an experienced radio/TV technician for help.
RGB LED Flexible Light Strip
5-way
Splitter
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
RGB LED Flexible Light Strip
5-way
Splitter
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
V+
G
R B
Battery
OR
CPS connector
(CPS-F2ST)
Fuse 3A
1/4” Snap Spades
Power Supply
(CPS-12VDC-50W)
White
Antenna
Black Ground
Blue
Brake
Override
To Brake
Switch
To Splitter To Controller
Adapter Cable
RF Controller
RCW-RFRGB
To Splitter
To Controller
Adapter Cable
RCW-RFRGB
Black
Ground
Red
Power In
Blue
Wire
RF Controller
Running Light Cicuit (+)
Ground
White
Antenna
PSC-164
Brake Light
Circuit (+)
Diagram 2
Tip: To use RGB LED light strips for auxilary
running lights/brake lights, set controller for red
color and dim to 40% or 20% to simulate parking
lights. Attach Blue wire from controller to the
positive brake light wire on the motorcycle. After
pairing mode the LED light strips will be dim red
when controller is on and the LED light strips
will be full brightness red when brake is applied.
Controller will activate full brightness red mode
anytime the controller is powered and a positive
signal is applied to the blue wire. Strips will now
function as auxiliary Tail/Brake lights to enhance
visibility and safety.
