Pro
Uninterruptible
Power Supply

ENG
1
Operation Manual Pro
CONTENTS
1. PRECAUTIONS .......................................................................................
2. SPECIAL FEATURES ................................................................................
3. PACKAGE CONTENTS ............................................................................
4. OPERATING PRINCIPLE ..........................................................................
5. DESCRIPTION .....................................................................................
6. MAIN FUNCTIONS ............................................................................
7. CONNECTION AND OPERATION ................................................................
8. BATTERY MAINTENANCE ........................................................................
9. TROUBLESHOOTING .............................................................................
10. TECHNICAL SPECIFICATIONS ..................................................................
Technical support is on www.sven.fi.
Congratulations on your purchase of the Sven uninterruptible power supply!
Please read this Оperation Мanual before using the unit and retain this Оperation Мanual in a safe
place for future reference.
COPYRIGHT
© 2016. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Мanual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Мanual more exact, some discrepancies may occur. The
information of this Мanual is given on «as is» terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damages which have arisen from the information,
contained in the given Мanual.
UNPACKING
Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damages; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
2
3
3
3
4
5
5
7
7
8

ENG
2
1. PRECAUTIONS
Before operating this device, please carefully read the following safety instructions:
• Before switching on the Uninterruptible Power Supply (UPS) in the electric mains for the first time,
it is necessary to charge the storage battery for at least 12 hours. For this purpose the UPS should
be switched on without load in the electric mains.
• If the storage battery has fully run down or the UPS has not been operated for three months, it is
also necessary to charge the storage battery for at least 12 hours. Otherwise, its durability will be
considerably reduced.
• The battery warranty (included into the UPS) is 6 months from the sale date (but not more than
18 months from the UPS manufacture date).
• The UPS is designed solely for operation with PCs equipped with switching power supply units*.
• Do not installed the stabilizer in a place with insufficient ventilation. The minimum air gap is of 25 cm.
• During operation, the case of the device can be heated up to 50°C, which is absolutely normal.
• It is strongly forbidden to open case of the device, as there is high voltage inside. If some prob-
lems occur, please address an authorized service centre. For the list of authorized service centres
please go to www.sven.fi.
• Do not let liquid and foreign objects get inside the device, it can cause short circuit, get out
down the device or electric shock.
• In case there are signs of improper operation of the device (sparkling, unusual smells, etc.), it is
necessary to turn off the device immediately and disconnect it from the mains, and address your
nearest authorized service centre.
• It is forbidden to connect the UPS to equipment with power consumption higher than
its maximum output power. It can cause overload and breakdown of the device.
It is strongly forbidden to operate the device in following conditions:
• in dusty environment or environment containing highly inflammable gas;
• at temperature higher than 40°C or lower than 0°C;
• at relative humidity level higher than 90%;
• in direct sunlight or next to heating elements;
• in vibration places;
• outdoors.
• In case of fire use only powder fire extinguisher, as using water can cause electric shock.
• Try to install the UPS in proximity to power supply, in such way it will be easier to unplug the device
if necessary.
*The device operation is not guaranteed when connecting UPS to equipment with APFC (active
power factor correction).
Uninterruptible
Power Supply

ENG
3
Operation Manual Pro
2. SPECIAL FEATURES
• Automatic voltage regulation within 175-280V
± 3% (built-in voltage regulator)
• Cold Start feature at battery power supply
• Type of load: PC, monitor
• Short circuit
• Transformer thermal protection
• Multifunctional LCD display (in Pro 650 (LCD, USB)/ 1500 (LCD, USB) models)
• Connection to PC via USB port (in Pro 650 (LCD, USB)/ 1000 (USB)/ 1500 (LCD, USB) models)
• Fire-proof ABS plastic case
3. PACKAGE CONTENTS
• Uninterruptible power supply — 1 pc
• Software CD disk (for Pro 650 (LCD, USB)/ 1000 (USB)/ 1500 (LCD, USB) models) — 1 pc
• Interface cable (for Pro 650 (LCD, USB)/ 1000 (USB)/ 1500 (LCD, USB) models) — 1 pc
• Operation manual — 1 pc
• Warranty card — 1 pc
4. OPERATING PRINCIPLE
• Line-interactive UPS’s provide perfect protection of PCs and peripherals. If there are drops of
power supply in the mains, the device connected to the UPS is powered by battery via inverter
converting +12/24V DC voltage into 220V AC voltage, which allows to save data and shut down the
operation of the system properly.
• Voltage mains supply goes through a filter to AVR module (Automatic Voltage Regulator).
Voltage is increased or reduced if necessary to correspond to standard 220V voltage, then voltage
is supplied to the connected equipment. At the same time the charging unit charges the battery.

ENG
4
5. DESCRIPTION
a : Mains operation indicator (green). Lights when the UPS
is turned on and the mains voltage is within the normal limits
b : Battery status indicator (yellow). Intermittent illumina-
tion – when the battery is charging, continuous light – the
battery is charged
c : Inverter indicator (red). Lights when the UPS switches
to inverter mode (battery operation)
d : UPS switch-on button
e Network operation mode
f Battery operation mode
g Output voltage
h Load indicator
i LCD display
j Battery capacity indicator
k Graphic input voltage level indicator:
HIGH, NORMAL, LOW
l Output plug
m Power cable
Pro 400/ 600/ 800
UPS Front Panel
c
d
b
a
Pro 650 (LCD, USB) UPS Front Panel
with LCD display
g
d
f
e
j
i
h
Pro 400/ 600/ 800/
650 (LCD, USB)
UPS Rear Panel
l
m
k
Uninterruptible
Power Supply

ENG
5
Operation Manual Pro
Important! Before the first start-up of the UPS
it is necessary to charge the battery for at least
12 hours without load.
6. MAIN FUNCTIONS
• If there is no electric power supply in the mains,
the UPS is powered with a battery, while the device
connected to the PC produces an audio alarm every
few seconds.
• When the battery is running down, the UPS starts
to produce an audio alarm every 2 seconds.
• When the battery has fully run down, there is a
long audio alarm after which the UPS automatically
switches off.
• When electric power supply restores in the mains,
the UPS automatically switches on. Then the battery
should be charged for at least 12 hours.
7. CONNECTION AND OPERATION
• Place the UPS in an appropriate position with proper
ventilation (free space around the UPS must be not
less than 25 cm).
• Connect the devices to the UPS.
Pro1500 (LCD, USB)
UPS Front Panel with LCD display
g
d
f
e
j
i
h
Pro 1000 (USB)/
Pro1500 (LCD, USB)
UPS Rear Panel
l
m
Pro 1000 (USB)
UPS Front Panel
c
d
b
a
k

ENG
6
Turn on / off the UPS
• Connect the UPS. LED/LCD-display turns on. No need to turn on the UPS with the button (in
models with LCD-display), – «autostart» function will launch it automatically. Turn on the UPS with
the button d (in models with LED-display), in confirmation a short beep will sound.
• Turn off the connected equipment (the first turn on the most powerful, the latest, most low-
power).
• Disconnect the UPS to the network. Turn off the connected equipment, and then turn off the UPS
with button d*.
Notes:
• If the UPS is left unused for a long period of time, please mind to switch it off and pull out
its plug from the socket.
• If the UPS is not used for a long time, the battery is to be charged once every three
months.
• Since the UPS has an «autostart» function, it will restart automatically if a network power
failure happened.
* There is a button without fixing in models with LCD display. UPS is controlled by pressing a button
to activation the command.
Connecting to a PC with a USB port models:
In models with USB port, using the software, you can control the UPS parameters. The software also
allows you to shut down your PC, and etc.
• Turn off and turn on the PC and the connected equipments, UPS from the mains.
• Connect the UPS to a PC via the USB cable (included).
• Connect to the mains and turn on the UPS and PC.
• Install the software from the disc (included).
• Start еру monitoring program.
• Select the “Mega USB” in the type settings of the communication port . Press “Ок” button to confirm.
If power supply in the mains drops, the UPS can properly shut down the system by means of the
software, then the UPS turns off.
Software allows to set the PC switch-off time, and also to keep record of the state of mains power
supply.
Important!
UPS is designed for powering only PCs and monitors, therefore refrain from connecting
other peripherals such as laser printers, scanners, speaker systems, etc.
Note that battery operation time depends on the power consumption of the connected
equipment and the condition of the battery. During this time it is necessary to save all open
documents and switch off the PC, then the UPS should also be switched off.
Uninterruptible
Power Supply

ENG
7
Operation Manual Pro
8. BATTERY MAINTENANCE
UPS series contains one or two maintenance-free sealed lead-acid batteries (depends on UPS
model). High humidity, too high or low temperature, frequent battery discharge reduce its
durability. If battery has not been operated for a long period of time, it also has negative impact on
its durability. Therefore, it is recommended to carry out the whole cycle of battery charging/
discharging at least once per three months.
Storage conditions
• The UPS should be stored closed in vertical position in a dry and cool place with fully charged
storage battery.
• Before placing the UPS in storage, charge it for 12 hours.
Warning! Do not operate the UPS in environment with operating temperature not corres-
ponding to value given in Technical Specifications.
9. TROUBLESHOOTING
Problem
The UPS is connected to the mains with
voltage nominal, though the device
shows no voltage in the mains and enters
off-line mode.
The UPS does not start.
When power supply drops, the UPS
immediately switches off.
Solution
There is over- or undervoltage in the mains. Switch off
the PC and the UPS. Switch them on again after
voltage becomes normal.
The fuse has tripped, battery is discharged. Switch
the fuse, charge the battery.
1. The battery is discharged. It is necessary to carry
out the whole cycle of battery charging.
2. The battery is out of order. It is necessary to
replace the battery.
3. Power requirements exceed the UPS capacity.
If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.

ENG
8
Моdels
Parameters
10. TECHNICAL SPECIFICATIONS
Apparent power, VA Active power, W Battery capacity, A•h Battery voltage, V USB LCD Type of load Input voltage, V Input frequency, Hz Output voltage, V Output frequency, Hz Backup time, min Transfer time, ms Short circuit protection Efficiency, % Operating temperature, °C Operating humidity, %
PC, monitor 175 – 280
± 3%
50 220 ± 10% 50 ± 1 (backup mode) 3-20 (dependent on connected load) ≤ 10 overcurrent (restorable fuse) > 70 0 - 40 10 ~ 90
Notes. Technical specifications given in this table are supplemental information and cannot give occasion to claims. Technical specifications are subject to change without notice due to improvement of SVEN production.
+-+
7 9 2 × 7
Pro 650
(LCD, USB) Pro 800 Pro 1000
(USB)
390 480 720 650 800 1000
12 12 2 × 12
––
74,5
240
Pro
400
Pro
600
360
400 600
12 12
– – +- -
+
2 × 9
Pro1500
(LCD, USB)
900
1500
2 × 12
+
Uninterruptible
Power Supply

2.0 Multimedia Speaker System
Automatic Voltage Regulator
Стабилизатор напряженияСтабилизатор напряжения
Automatic Voltage Regulator
2.0 Multimedia Speaker System 2.0 Multimedia Speaker System
SPS-619
Модели: Pro 400/ 600/ 650 (LCD, USB)/
800/ 1000 (USB)/ 1500 (LCD, USB)
Импортер в России: OOO «РЕГАРД», 109052,
РФ, г. Москва, ул. Нижегородская, д. 86, корп. Б
Уполномоченная организация в России: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 24 мес.
Срок службы: 5 лет.
Производитель: «СВЕН ПТЕ. Лимитед», 176 Джу Чиат Роуд,
№ 02-02, Сингапур, 427447. Произведено под контролем
«Свен Скандинавия Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№ 02-02, Singapore, 427447. Produced under the control
of Oy Sven Scandinavia Ltd. 15, Kotolahdentie, Kotka,
Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland. Pro
Uninterruptible
Power Supply
