Swann SW343-DP2 User manual

Product Code SW343-DP2
UPC 814282011735
EAN 9325481010999
2 months
continuous recording+
320
GB
30ft 9m
good night vision
high video quality
1/3” CMOS 400 TV lines
400
BNC cable x 2
50ft 15m
weather resistant cameras
anti-corrosive casing
easily backup video
incidents to flash drive
easily connects
to your TV
add up to 2 cameras
4
Channels
www.swannsecurity.com
™
™
Advanced securit
y
made eas
y
plug&playsecurity
Home & Business
Security Monitoring Kit
DVR4-950™ / PNP-150/2™
Monitor up to 4 cameras for peace of mind at an
affordable price, with no ongoing costs
Easily backup & retain video footage if there’s an
incident
Set & forget by recording continuously from 4 cameras
for over 60 days+
Catch suspicious activity, save time & hard drive space
with motion detection
Protect the people you care about & reduce the cost of
crime
Never lose the
remote control again!
Use as a front control panel
or easily detach to use as a
remote control

www.swannsecurity.com
™
Please note that the information contained within this document is subject to change without notification.
Package Contents
• DVR4-950™
• 320GB Hard Drive (installed)
• PNP-150™ Cameras x 2
• RCA to RCA Cable 3ft / 1m
• BNC Cables 50ft / 15m x 2
• Power Adapters
• Remote Control x 2
• BNC to RCA Adapters
• Mounting Screws & Plugs
• Operating Instructions
• Theft Deterrent Stickers x 4
All trademarks remain properties of their respective owners.
™
™
Advanced securit
y
made eas
y
plug&playsecurity
warranty
MONTHS
12 x4
BONUS
STICKERS
SECURITY
Home & Business
Security Monitoring Kit
DVR4-950™ / PNP-150/2™
Specifications
DVR
Video
Video Format NTSC or PAL
Video Inputs 4CH Composite
Video Outputs 1CH Composite
Display Resolution NTSC: 640 x 448 /
PAL: 640 x 544
Display Frame Rate NTSC: 120fps (4 x 30) /
PAL: 100fps (4 x 25)
Audio
Audio Input 1 RCA Input
Audio Output 1 RCA Output
Recording
Compression Format Advanced MJPEG
Recording Resolution NTSC: 640 x 224 / PAL: 640 x 272
Recording Frame Rate NTSC: 60fps Quad View /
PAL: 50fps Quad View
Recording Modes Manual / Schedule / Motion
Multiplex Operation Triplex
HDD Interface / Memory Type SATA
Hard Drive Support Up to 1TB
General
Operating Power DC 12V
Dimensions 8.9”x 8.2”x 2.1” /
225mm x 208mm x 53mm
Weight 2.8lbs / 1.3kg
Backup Method USB to Flash Drive
Remote Control Yes, 2 in pack
Remote Control Battery Type Lithium battery CR2025 / 3V
Camera
Video
Image Sensor 1/3” CMOS
Video Quality 400 TV Lines
Number of Effective Pixels NTSC: 510 x 492 / PAL: 628 x 582
Minimum Illumination 0 Lux (IR on)
Day/Night Mode Color during day / switches to B&W at night
White Balance Automatic
Signal / Noise Ratio > 50dB
Electronic Shutter 1/60 - 1/15,000 NTSC / 1/50 - 1/15,000 PAL
Gain Control Automatic
Backlight Compensation Yes
Wide Dynamic Range No
Lens 6mm
Viewing Angle 53 degrees
Audio
Microphone No
Night Vision
Night Vision Distance Up to 30ft / 9m
IR Cut Filter No
Number of Infra-Red LEDs 30
Infra-Red Wavelength 850nm
Infra-Red LED Life 10,000 hours
General
Indoor / Outdoor Indoor / Outdoor
Operating Power DC 12V
Operating Temperature 14°F ~ 122°F / -10°C ~ 50°C
Body Construction ABS Plastic
Dimensions - Camera 5.5” x 2.8” x 2.8” /140mm x 70mm x 70mm
Dimensions - Stand 4.5” x 2.3” x 2.3” /120mm x 60mm x 60mm
Weight – Camera 0.4lbs / 180g
Weight – Camera & Stand 0.5lbs / 235g
Cable Length 50ft / 15m
Packaging
Pack Weight 11lbs / 5kg
Pack Dimensions (HxWxD) 15” x 11.2” x 7.1” /
380mm x 285mm x 180mm
Master Pack Quantity 2
Master Pack Dimensions (HxWxD) 14.2” x 17.1” x 25.8” /
360mm x 435mm x 655mm
Channel Select
Operating Controls
Detachable
Remote Control
Power LED
front
320GB Hard Drive
HDD Activity LED
Video Out Power Input
back
Video
In x 4
Audio In
Audio
Out
USB Port
+ based on the lowest recording settings
