Swegon DHCe User manual

DHCe
Installation – Commissioning – Maintenance 20151117 Art. No. 1545190
Accessories
Regulator unit:
REG. Combination unit with damper and sound attenuator.
Duct cover:
DHCT 1. For incorporation of the regulator unit and the
connected spiral duct.
Base:
DHCT 2. For mounting the air diffuser on the floor.
Decorative top:
DHPT 3. Removable top board in different materials and
dimensions. Can be used when duct cover is not utili-
zed. Please contact your nearest sales representative for
further information.
Installation
Secure the air diffuser with screws to the wall using angle
brackets supplied with the diffuser. Screw the base into
place on the bottom of the unit. Secure the telescopic
duct cover with screws to the wall using the wall mount-
ing rails. Conceal the screws with aluminium lateral strips.
Press the regulator unit, which has a circular connection
spigot with a rubber seal, into the inlet socket of the air
diffuser. See Figure 1.
Commissioning
The measurement tapping is positioned on the one
side of the air diffuser behind the aluminium strip. The
K-factor (COP) is given on the product identification label
on the diffuser to the side of the measurement tapping.
K-factors can also be found in the relevant commissioning
instructions at www.swegon.com. We recommend that
you use the REG regulator unit for adjusting the airflow.
See Figure 2.
To regulate how the air is supplied to the room, turn the
air diffuser’s Varizon®discs to make the air to flow in the
desired direction. A straight air discharge can be achieved
by taking the disc out of the diffuser, turning it 180° and
reinserting it back into place. See Figure 4.
Maintenance
The air diffuser can be cleaned, if necessary, using luke-
warm water with dishwashing detergent added or by
vacuum cleaning using a brush nozzle. The duct system is
accessed by removing the front panel and the inspection
cover of the air distribution panel. See Figure 2.
Figure 1. Installation.

DHC
2Swegon reserves the right to alter specifications. 20151117
Figure 2. Commissioning, Maintenance.
Disc adjustment – Varizon®
Figure 3. Nozzle adjustment, schematic presentation
q= flow reading l/s
p= current pressure reading (Pa)
k= commissioning factor
q
p
kpq⋅=
k
pq
=
( )2
k
K-FAC TOR
q
p
kpq⋅=
k
pq
=
( )2
k
q
p
kpq⋅=
k
pq
=
( )2
k

3
20151117 Swegon reserves the right to alter specifications.
DHC
Dimensions and weights
DHC
Size Dimensions (mm) Weight (kg)
ABCØD G
125 245 623 250 125 123 7
160 280 623 285 160 140 10
200 320 923 325 200 160 15
250 370 923 375 250 185 18
315 435 1523 435 315 218 23
400 520 2003 525 400 260 29
500 620 2003 620 500 310 36
630 750 2003 750 630 375 45
800 920 2003 920 800 460 56
REG
Size Dimensions (mm)
ØC Ød G H
125 225 124 230 500
160 260 159 230 500
200 300 199 230 500
250 350 249 250 500
315 415 314 260 800
400 500 399 300 800
500 600 499 300 900
630 730 629 300 900
Figure 4. Regulator unit, REG.
Figure 5. DHC.
Figure 6. DHC with duct cover and base.
1. Sizes 125-315: 2400-2750.
Size 400-800: 2850-3200.
If other lengths are required always state the total room height.
d
K-factor (COP)
Size Supply air
125 12.0
160 20.0
200 33.0
250 50.0
315 84.0
400 134.0
500 202.0
630 285.0
800 520.0
Number of measuring tubes: 1
