System air BOR-S Series User manual

BOR-S
Installation, maintenance and operation instructions

BOR-S | Installation, maintenance and operation instructions
1.

BOR-S | Installation, maintenance and operation instructions Installation, maintenance and operation instructions | BOR-S
2.
ø 4 mm

BOR-S | Installation, maintenance and operation instructions
3.

BOR-S | Installation, maintenance and operation instructions Installation, maintenance and operation instructions | BOR-S
4.
1
2
3
...
9

BOR-S | Installation, maintenance and operation instructions
Pa

BOR-S | Installation, maintenance and operation instructions Installation, maintenance and operation instructions | BOR-S
k-factor (l/s) BOR-S-100 BOR-S-125
Position 1 2,48 3,32
Position 2 2,31 3,06
Position 3 2,12 2,82
Position 4 1,97 2,63
Position 5 1,83 2,44
Position 6 1,69 2,25
Position 7 1,54 2,06
Position 8 1,41 1,87
k-factor (m3/h) BOR-S-100 BOR-S-125
Position 1 8,94 11,96
Position 2 8,30 11,03
Position 3 7,64 10,14
Position 4 7,08 9,45
Position 5 6,58 8,78
Position 6 6,07 8,10
Position 7 5,56 7,41
Position 8 5,07 6,72
Q(l/s) = k· √pd(Pa)Q(m3/h) = k· √pd(Pa)
