VAV Kit
Installation Manual
Item# : 420300
2017-11-01
This Kit includes:
Pressure transducer (2 pcs)
Pressure tap (2 pcs)
Screw (6 pcs)
Tubing of 1m (2 pcs)
Topvex Series VAV installation Kit
Systemair Inc.
2
1. Locate where the pressure tap is going to be installed. The pressure tap should be 5 duct diameters
from the applicable opening of the unit or midpoint between applicable opening and rst down-stream
obstruction (bends, splits, dampers, coils, di󰀨users, etc). Use the mounting location that allows for the
furthest distance from the unit, drill a 5/16” hole and install pressure tap.
To unit
*** If there is another AHU (i.e. DOAS, furnace, etc) in series downstream of the unit then the pressure
tap should be located downstream of the AHU as described above.
A
B
1
4
2
3
1Outdoor Air (OA)
2Supply Air (SA)
3Return Air (RA)
4Exhaust Air (EA)
ADi󰀨erential pressure transmitter & pressure tap for supply air fan
BDi󰀨erential pressure transmitter & pressure tap for exhaust air fan
Systemair Unit
DOAS, furnace, etc
READ AND SAVE THESE INSTRUCTIONS!
Danger
• Make sure that the Main power supply to the unit is disconnected before performing any
maintenance or electrical work!
• All electrical connections must be carried out by an authorized installer and in accordance with local
rules and regulations.
Topvex Series VAV installation Kit
Systemair Inc.
3
2. Mount di󰀨erential pressure transducer as close as possible to the pressure tap while still permitting
accessibility. Connect one end of tube to duct mounted pressure tap and one end to the di󰀨erential
pressure transducer. For the supply, connect it to the high side (+). For the exhaust, connect it to the
low side (-). Insure that no kinks, twists, cuts, or punctures can occur in tube.
3. Install low voltage signal / power wire connecting di󰀨erential pressure transmitter to unit. See gure
below
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
ON
1 2 3
SupplyExhaust
TB3-40
TB3-42
TB3-10
TB3-40
TB3-41
TB3-10
Connect to pressure tap
Leave open to atmosphere
Signal wire to unit
4. Once the di󰀨erential pressure transducers have been mounted and wire back to their respective inputs on
the unit, the unit software needs to be setup for a VAV application by using the control panel and following
the procedure on page 4.
Connect to pressure tap
Leave open to atmosphere
Signal wire to unit
Supply Exhaust
1 - OFF
2 - ON
3 - OFF
Topvex Series VAV installation Kit
Systemair Inc.
4
1 Access rights
Go to Access Rights by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
Temperature
Air Control
Time settings
→Access Rights
2 Log on
Choose Log on. Select by pressing the RIGHT
arrow button.
→Log on
Log o
Change password
3 Password
Enter password 1111 by pressing OK followed by
the UP/DOWN arrow buttons. Select next digit by
pressing the RIGHT arrow button. Press OK when
all 4 digits have been entered.
Go back 2 steps using the LEFT arrow button.
Log on
Enter password xxxx
Actual level: None
4 Conguration menu
Go to Conguration by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
Man/auto
Settings
→Conguration
Access Rights
5 Inputs/Outputs
Go to Inputs/Outputs by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
→Inputs/Outputs
Control function
Fan control
Extra Sequence Y4
6 Analog input exp3
Go to AI exp3 by using the UP/DOWN arrow
buttons. Select by pressing the RIGHT arrow
button.
*If AI exp3 does not appear in this menu, go
back 1 step using the LEFT arrow button and
proceed to step 8.
Topvex ####
YYYY-MM-DD HH:MM
SYSTEMI: STOPPED
SP: ACT: °F ↓
Topvex Series VAV installation Kit
Systemair Inc.
5
7 Pressure A exp3
Conrm by pressing OK button. Set Sign to
Not used by using the UP/DOWN arrow buttons.
Conrm by pressing OK twice.
Go back 1 step using the LEFT arrow button.
Pressure A exp3
Sign: Not used
Raw value: 0.0
Compensation: 0.0Pa↓
8 Analog input exp4
Go to AI exp4 by using the UP/DOWN arrow
buttons. Select by pressing the RIGHT arrow
button.
*If AI exp4 does not appear in this menu, go
back 1 step using the LEFT arrow button and
proceed to step 10.
AI
AI exp4
→AI exp4
DI
9 Pressure A exp4
Conrm by pressing OK button. Set Sign to
Not used by using the UP/DOWN arrow buttons.
Conrm by pressing OK twice.
Go back 1 step using the LEFT arrow button.
Pressure A exp4
Sign: Not used
Raw value: 0.0
Compensation: 0.0Pa↓
10 Analog input
Go to UI by using the UP/DOWN arrow buttons.
Select by pressing the RIGHT arrow button.
→UI
UI exp3
UI exp4
AO
11 EAF Pressure
Go to UI1 by using the UP/DOWN arrow buttons.
Conrm by pressing OK. Set AI Sign to EAF
pressure by using the UP/DOWN arrow buttons.
Conrm by pressing OK.twice.
UI1
Choose AI or DI sign
AI sign: EAF Pressure
DI sign: Not used
12 SAF Pressure
Go to UI2 by using the UP/DOWN arrow buttons.
Conrm by pressing OK. Set AI Sign to SAF
pressure by using the UP/DOWN arrow buttons.
Conrm by pressing OK twice.
Go back 2 steps to the main menu using the
LEFT arrow button.
UI2
Choose AI or DI sign
AI sign: SAF Pressure
DI sign: Not used
Topvex Series VAV installation Kit
Systemair Inc.
6
13 Fan Control
Go to Fan Control using the DOWN arrow
buttons. Select by pressing RIGHT arrow button.
Inputs/Outputs
Sensor settings
Control function
→Fan control
14 Pressure control
Press the OK button to select Pressure
control. Press OK to conrm.
Go back 2 steps using the LEFT arrow button
Fan control
Pressure control
15 Air Control
Go to Air control by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button
Temperature
→Air Control
Time settings
Access Rights
16 Pressure Control SAF
From this submenu, the actual supply duct
pressure measured is displayed along with the set
point for the current unit operation mode. Press the
RIGHT arrow button to access the next submenu.
Pressure control SAF
Actual: Pa
Setp: Pa
17 Pressure Control SAF
From this submenu, the set points for normal
speed (1/1) and reduced speed (1/2) for the supply
air fan can be entered. Press the OK button to
access the eld, use the arrow buttons to set a
value and press OK again to save the value. Press
the LEFT arrow to return to the previous submenu.
Pressure control SAF
Step 1/1: Pa
Setp 1/2: Pa
18 Pressure Control EAF
From this submenu, press the DOWN arrow.
The actual exhaust duct pressure measured is
displayed along with the set point for the current
unit operation mode. Press the RIGHT arrow
button to access the next submenu.
Pressure control EAF
Actual: Pa
Setp: Pa
Topvex Series VAV installation Kit
Systemair Inc.
7
Pressure control EAF
Step 1/1: Pa
Setp 1/2: Pa
3 Pressure Control EAF
From this submenu, the set points for normal
speed (1/1) and reduced speed (1/2) for the
exhaust air fan can be entered. Press the OK
button to access the eld, use the arrow buttons to
set a value and press OK again to save the value.
Press the LEFT arrow twice to return to the main
menu and press the UP arrow 3 times to display
the system status screen.
Systemair Inc. reserves the right to make changes and improvements to the contents
of this manual without prior notice.
Systemair Inc.
50 Kanalakt Way
Bouctouche, NB
E4S3M5, Canada
Phone + 1 800 263 7081
10048 Industrial Blvd
KS, 66215
United States
Phone +1 800 263 7081
www.systemair.net
