Tait TB9400 User manual

TB9400 Base Station/Repeater
Specifications Manual
MBC-00002-13 · Issue 13 · July 2017

2TB9400 Specifications Manual
© Tait Limited July 2017
Contact Information
Tait Communications
Corporate Head Office
Tait Limited
P.O. Box 1645
Christchurch
New Zealand
For the address and telephone number of regional
offices, refer to our website:www.taitradio.com
Copyright and Trademarks
All information contained in this document is the
property of Tait Limited. All rights reserved.
This document may not, in whole or in part, be copied,
photocopied, reproduced, translated, stored, or reduced
to any electronic medium or machine-readable form,
without prior written permission from Tait Limited.
The word TAIT and the TAIT logo are trademarks of
Tait Limited.
All trade names referenced are the service mark,
trademark or registered trademark of the respective
manufacturers.
Disclaimer
There are no warranties extended or granted by this
document. Tait Limited accepts no responsibility for
damage arising from use of the information contained
in the document or of the equipment and software it
describes. It is the responsibility of the user to ensure
that use of such information, equipment and software
complies with the laws, rules and regulations of the
applicable jurisdictions.
Enquiries and Comments
If you have any enquiries regarding this document, or
any comments, suggestions and notifications of errors,
please contact your regional Tait office.
Updates of Manual and Equipment
In the interests of improving the performance,
reliability or servicing of the equipment, Tait Limited
reserves the right to update the equipment or this
document or both without prior notice.
Intellectual Property Rights
This product may also be made under license under one
or more of the following patents:
- US7203207, AU2004246135, CA2527142,
GB2418107, HK1082608, MY134526, US8306071
- US7339917, AU2004246136, CA2526926,
GB2418812, MY134217
- US7499441, AU2005262626, CA2570441,
GB2430333, JP4690397, NZ551231, KR100869043,
RU2351080, BRP10512052, MXPA06015241
- US 7200129, AU2005226531, CA2558551,
CN1930809, GB2429378, JP4351720, BRP10508671,
NZ549124, KR848483, RU2321952
Environmental Responsibilities
Tait Limited is an environmentally
responsible company which supports
waste minimization, material recovery and
restrictions in the use of hazardous
materials.
The European Union’s Waste Electrical and Electronic
Equipment (WEEE) Directive requires that this
product be disposed of separately from the general
waste stream when its service life is over. For more
information about how to dispose of your unwanted
Tait product, visit the Tait WEEE website at
www.taitradio.com/weee. Please be environmentally
responsible and dispose through the original supplier,
or contact Tait Limited.
Tait Limited also complies with the Restriction of the
Use of Certain Hazardous Substances in Electrical and
Electronic Equipment (RoHS) Directive in the
European Union.
In China, we comply with the Measures for
Administration of the Pollution Control of Electronic
Information Products. We will comply with
environmental requirements in other markets as they
are introduced.

TB9400 Specifications Manual Contents 3
© Tait Limited July 2017
Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Scope of Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Associated Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Publication Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1 Base Station Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.2 Frequency Bands and Sub-bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
1.3 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
AC Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
DC Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Auxiliary Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.4 Power and Current Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.4.1 120VAC Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Transmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.4.2 230VAC Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Transmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.4.3 12VDC Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Transmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.4.4 24VDC Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Transmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
1.4.5 48VDC Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Transmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
1.5 Receiver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Digital RF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Analog RF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Analog Audio - General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Analog Audio - CTCSS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Analog Audio - Gating Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
1.6 Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Simulcast. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Analog Audio - General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Analog Audio - Modulation Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . 29

4 Contents TB9400 Specifications Manual
© Tait Limited July 2017
Analog Audio - CTCSS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
1.7 Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
1.7.1 Requirements for Delay, Jitter, Loss and Duplication. . . . . . . . . . . . . . . . . . . 31
1.7.2 Channel Group Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
1.8 System Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
1.8.1 External Frequency Reference Input (BNC). . . . . . . . . . . . . . . . . . . . . . . . . . 33
1.8.2 Ethernet Interface (RJ45) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
1.8.3 System Interface 25-Way D-range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
External General Purpose Digital Inputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
1.8.4 1PPS Timing Reference Input (BNC). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
1.9 Miscellaneous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
1.9.1 Channel Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
1.9.2 Duplexer Attenuation Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
1.9.3 Operating Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
1.9.4 Heat Load Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
1.9.5 Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
1.9.6 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
2 Module Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.1 Reciter and Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
2.1.1 Identifying the Reciter and Receiver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
2.1.2 Physical Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2.2 PA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
2.2.1 Identifying the PA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
2.2.2 Physical Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
2.3 PMU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
2.3.1 Identifying the PMU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
2.3.2 Physical Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
2.3.3 Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3 Compliance Standards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Appendix A – Frequency Response Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

TB9400 Specifications Manual Preface 5
© Tait Limited July 2017
Preface
Scope of Manual
Welcome to the Specifications Manual for the TB9400 base station/
repeater. This manual provides general, performance and physical
specifications for the TB9400 50W and 100W base stations/repeaters.
In the following, unless mentioned specifically, this manual will use the
term “base station” to mean both base station and repeater.
Document Conventions
Within this manual, four types of alerts may be given to the reader. The
following paragraphs illustrate each type of alert and its associated symbol.
Warning This alert is used when there is a hazardous situation
which, if not avoided, could result in death or serious injury.
Caution This alert is used when there is a hazardous situation which,
if not avoided, could result in minor or moderate injury.
Notice This alert is used to highlight information that is required to
ensure procedures are performed correctly. Incorrectly performed pro-
cedures could result in equipment damage or malfunction.
This icon is used to draw your attention to information that may
improve your understanding of the equipment or procedure.

6 Preface TB9400 Specifications Manual
© Tait Limited July 2017
Associated Documentation
The following associated documentation for this product is available on the
Tait support website.
■TB9400 Installation and Operation Manual (MBC-00001-xx)
■TN9400 P25 Trunked Network Maintenance Manual (MNC-00001-xx)
■TaitNet P25 Trunked Networks with TB9400 Base Stations System
Manual (MBA-00064-xx)
■TaitNet Analog Conventional Networks with TB9400 Base Stations
System Manual (MND-00001-xx)
■Safety and Compliance Information (MBA-00012-xx)
The characters xx represent the issue number of the documentation.
Technical notes are published from time to time to describe applications for
Tait products, to provide technical details not included in manuals, and to
offer solutions for any problems that arise. Technical notes are available in
PDF format from the Tait support website. For more information contact
your regional Tait office.
Publication Record
Issue Publication Date Description
1 May 2012 First release
2 November 2012 Changes for version 1.15 release.
Additions
■operating temperature range
■Btu load values
Updates
■power and current consumption
■compliance standards
3 June 2013 Changes for version 1.20 release.
Additions
■B3-band base station specifications
Updates
■compliance standards
4 November 2013 Changes for version 1.30 release.
Additions
■H-band base station specifications
■Dual 50W and receive-only base station specifications
Updates
■compliance standards

TB9400 Specifications Manual Preface 7
© Tait Limited July 2017
5 December 2014 Changes for version 1.45 release.
Additions
■K4 band receive-only base station specifications
■P25 Phase 2 specifications
Updates
■P25 Phase 2 emission designators
■compliance standards
6 April 2015 Changes for version 2.00 release.
Additions
■K4 band 50W base station specifications
■peak-to-average power level specifications
Updates
■base station MTBF
■compliance standards
7 July 2015 Changes for version 2.05 release.
Additions
■information on receive-only base stations and receiver modules
■1PPS jitter specification
Updates
■external frequency reference stability specification
■compliance standards
8 November 2015 Changes for version 2.10 release.
Additions
■information on analog base stations
Updates
■compliance standards
9 April 2016 Changes for version 2.15 release.
Additions
■Clarification of repeater vs. base station for K and L bands in Brazil
10 June 2016 Changes for version 2.20 release.
Additions
■table added to section 1.5 Analog RF specifying that the TB9400 only
supports Narrow Bandwidth
■inclusion of B band alongside G and F
11 November 2016 Changes for version 2.25 release.
Additions
■General updates.
■Information added in regards to the QoS requirements (delay, jitter,
loss, duplication).
■Fix Anatel approvals
Issue Publication Date Description

8 Preface TB9400 Specifications Manual
© Tait Limited July 2017
12 March 2017 Changes for version 2.30 release.
General updates
Updated “Requirements for Delay, Jitter, Loss and Duplication” on
page 31
13 July 2017 Changes for version 2.35 release.
General updates
Addition of the new H3 band throughout
Added some missing K4 band info
Removed some erroneous K8 information
Updated receive voter limitations
Updated “RF and EMC Compliances” on page 45
Updated information in “Requirements for Delay, Jitter, Loss and
Duplication” on page 31
Issue Publication Date Description

TB9400 Specifications Manual Base Station Specifications 9
© Tait Limited July 2017
1 Base Station Specifications
The performance figures given in these specifications are applicable only
to equipment operating as an integral part of a TB9400 base station. These
performance figures are minimum figures, unless otherwise indicated, for
equipment operating at standard room temperature (+22°C to +28°C
[+71.6°F to +82.4°F]) and standard test voltages as follows:
■AC power management unit (PMU) - 120VAC and 230VAC
■12V DC PMU - 12VDC
■24V DC PMU - 24VDC
■48V DC PMU - 48VDC.
The TB9400 is available in the following configurations:
■50W single or dual base station with PMU
■100W single base station with PMU
■receive-only base station - up to four receivers (receive-only reciters)
with PMU.
Notice The software release notes list known issues or limitations of
the base station that may vary from the specifications published in this
document. Please refer to the current software release notes for any vari-
ations to the specifications in this document.

10 Base Station Specifications TB9400 Specifications Manual
© Tait Limited July 2017
1.1 Regulatory Information
Test Methods Where applicable, the test methods used to obtain these specifications are
those described in the following standards:
■TIA-102.CAAA-D
■TIA-102.CCAA-A
■EN 300 086
■EN 300 113
■EN 300 219
■EN 301 489
■CFR Title 47 Part 15
■TIA/EIA-603/603-D
■AS/NZS 4295
Emission
Designators
This equipment is compatible with the emissions listed in the following
table.
You can obtain further details of test methods and the conditions which
apply for compliance testing in all countries from Tait.
Emission
Designator Common Name
Modulation
Scheme Operating Modes
11K0F3E FM analog FM analog voice
8K10F1E P25 Phase 1 C4FM digital voice
8K10F1D P25 Phase 1 C4FM data/control channel
8K10F7W P25 Phase 1 C4FM digital voice/data/
control channel
8K70D1W P25 Phase 1
linear simulcast
modulation
CQPSK digital voice
8K70D7W P25 Phase 1
linear simulcast
modulation
CQPSK digital voice/data/
control channel
9K80D7W P25 Phase 2
linear simulcast and
non-simulcast
modulation
H-DQPSK digital voice/data
6K80D7W test mode only H-D8PSK digital voice/data

TB9400 Specifications Manual Base Station Specifications 11
© Tait Limited July 2017
1.2 Frequency Bands and Sub-bands
Many of the performance figures in this manual are applicable to all
frequency bands. In some cases the figures refer to specific bands or sub-
bands, and these are identified with the letters listed in the following table.
The table also indicates which base station configurations are currently
available in each frequency band.
Refer to “Compliance Standards” on page 44 for details about which bands
or sub-bands have been tested and approved to appropriate national and
international compliance standards.
In Brazil, for K band, the TB9400 is considered to be configured as a base
station with retransmission of receive frequencies.
Frequency
Identification Frequency Band and Sub-band 50W 100W Receive-only
B band B3 = 148MHz to 174MHz ✓✓ ✓
H band H1 = 400MHz to 440MHz
H2 = 440MHz to 480MHz
H3 = 470MHz to 520MHz
✓✓ ✓
K band K4 = 762MHz to 870MHza✓✓ ✓
a. The actual frequency coverage in this band is:
Transmit: 762MHz to 776MHz, and 850MHz to 870MHz
Receive: 792MHz to 824MHz

12 Base Station Specifications TB9400 Specifications Manual
© Tait Limited July 2017
1.3 Power Supply
The specifications in this section refer to the TB9400 base station fitted
with a PMU.
AC Input
Input
Voltage
Frequency
Power factor
Total harmonic distortion (THD)
Inrush current
230VAC
115VAC
Leakage current
88VAC to 264VAC
50Hz to 60Hz
> 0.95
< 8%
< 30A @ < 4ms
< 15A @ < 4ms
< 3.5mA/240VAC
Protection
Fault current (input)
Transient suppression
Overvoltage inhibit (self recovering)
Undervoltage signal
10A fuse
275V MOV (line-to-line)
275VAC ±10V
83VAC ±5V
General
Efficiency at rated outputa
Input-to-chassis isolation
Output-to-chassis isolation
86%
1500VAC, 50Hz, 1 minute
500VAC, 50Hz, 1 minute
a. At 230VAC.

TB9400 Specifications Manual Base Station Specifications 13
© Tait Limited July 2017
DC Input
Input voltage
User-programmable alarmsa
Low battery voltage
High battery voltage
User-programmable limitsb
Startup voltage
(after shutdown)
Shutdown voltage
Battery protection (fail-safe) limitsc
Startup voltage
Undervoltage shutdown
Overvoltage shutdown
Overvoltage shutdown reset
12V PMU
10V to 14V
14V to 17.5V
10.9V to 15V ±0.3V
10V to 13.5V ±0.3V
10.8V ±0.2V
9.5V ±0.3V
18.1V ±0.3V
17.1V ±0.3V
24V PMU
20V to 28V
28V to 35V
21.8V to 30V ±0.5V
20V to 27V ±0.5V
21.6V ±0.5V
19V ±0.5V
36.2V ±0.5V
34.2V ±0.5V
48V PMU
40V to 56V
56V to 70V
43.6V to 60V ±1V
40V to 54V ±1V
43.2V ±1V
38V ±1V
72.4V ±1V
68.4V ±1V
a. User-programmable alarms can be set for low or high battery voltage, using the web interface. The alarms will be triggered
when the set voltage levels are reached. These limits are subject to the tolerances of the battery protection circuitry, as
stated in “Battery Protection (Fail-safe) Limits” above.
b. The user-programmable startup and shutdown limits allow for adjustable startup and shutdown voltages. Using the web
interface, these limits can be adjusted for different numbers of battery cells, or for the particular requirements of the base
station operation. Once the limits are reached, the PMU will shutdown. These limits are subject to the tolerances of the
battery protection circuitry.
c. The battery protection limits are set in hardware at the factory and cannot be adjusted by the user. These limits will not be
reached under normal operation conditions, but are provided as “fail-safe” measures to protect the battery from deep
discharge.
Input current
0V to battery protection startup
voltaged
Battery protection startup voltage to
user-programmed startup voltagee
12V
2mA maximum
40mA typical
at 10.8V
24V
2mA maximum
30.1mA typical
at 21.6V
48V
1.2mA maximum
13.2mA typical
at 43.2V
Operating current refer to “Power and Current Consumption” on page 15
d. When the input voltage drops below the battery protection undervoltage shutdown limit, and until the voltage rises above the
battery protection startup voltage.
e. At initial power-up; or, after battery protection has occurred, when the input voltage rises above the battery protection startup
voltage (PMU now under control of its microcontroller), but is still below the user-programmed startup voltage
Protection
Fault current (input)
Wrong input voltage
Wrong input voltage polarity
circuit breaker or fuse in external wiringf
electronic lock-out
shunt diode
f. Provided by user.
General
Efficiency at rated output
12VDC
24VDC
48VDC
82%
85%
90%

14 Base Station Specifications TB9400 Specifications Manual
© Tait Limited July 2017
Outputs
28VDC output
Voltage
Current
Regulation
Ripple and noisea
Ripple and noise rms
Transient response on 28V loadstepb
28V
14A maximum
±0.5%
50mV pp
10mV rms
2% overshoot and recover within 0.6ms
a. 100MHz bandwidth.
b. 10% to 100% loadstep.
Protection
Overload
Short circuit
Overvoltage
AC module
DC module
electronic current limit above 16A
hiccup mode, self-resetting
electronic shutdown latch (33.5V)
electronic hysteric control (33.5V)
Auxiliary Power Supply
DC input voltage 28V ±15%
DC output
Voltage
Current
Regulation
Ripple and noisea
Ripple and noise rms
Zero load ripple
12V
13.65V
3A maximum
±2%
50mV pp
10mV rms
100mVpp
24V
27.3V
1.5A maximum
±2%
50mV pp
10mV rms
100mVpp
48V
54.6V
750mA maximum
±2%
50mV pp
10mV rms
100mVpp
a. 100MHz bandwidth.
Protection
Overload/short circuit
Overvoltage
12V
electronic
current limit
16V Zener diode
24V
electronic
current limit
32V Zener diode
48V
electronic
current limit
62V Zener diode
General
Efficiency at rated output
Input-to-output isolation
Output-to-chassis isolation
88%
1000VAC, 50Hz, 1 minute
500VAC, 50Hz, 1 minute

TB9400 Specifications Manual Base Station Specifications 15
© Tait Limited July 2017
1.4 Power and Current Consumption
The specifications in this section refer to the TB9400 base station fitted
with a PMU. The performance figures are typical figures.
The transmit measurements were carried out with the base station
transmitting at the stated RF output power with all front panel fans running.
The standby measurements were carried out with the base station not
receiving or transmitting and no front panel fans running. All
measurements were carried out with no load on the auxiliary power supply.

16 Base Station Specifications TB9400 Specifications Manual
© Tait Limited July 2017
1.4.1 120VAC Input
Transmit
AVAW
Single 50W base station
Minimum RF output power (5W)
Maximum RF output power (50W)
1A
1.9A
120VA
238VA
117 W
235W
Dual 50W base stationa
Minimum RF output power (5W)
Maximum RF output power (50W)
1.7A
2A
207VA
450VA
204W
440W
a. Both base stations transmitting.
100W base station
Minimum RF output power (10W)
50% RF output power (50W)
Maximum RF output power (100W)
1.6A
2.4A
3.3A
192VA
295VA
400VA
189W
290W
395W
Standby
AVAW
Single 50W and 100W base station 370mA 44VA 30W
Dual 50W base station 490mA 59VA 50W

TB9400 Specifications Manual Base Station Specifications 17
© Tait Limited July 2017
1.4.2 230VAC Input
Transmit
AVAW
Single 50W base station
Minimum RF output power (5W)
Maximum RF output power (50W)
700mA
1.1A
159VA
250VA
108W
220W
Dual 50W base stationa
Minimum RF output power (5W)
Maximum RF output power (50W)
1A
2A
230VA
460VA
196W
440W
a. Both base stations transmitting.
100W base station
Minimum RF output power (10W)
50% RF output power (50W)
Maximum RF output power (100W)
970mA
1.3A
1.7A
223VA
310VA
395VA
183W
285W
375W
Standby
AVAW
Single 50W and 100W base station 510mA 117VA 31W
Dual 50W base station 510mA 117VA 45W

18 Base Station Specifications TB9400 Specifications Manual
© Tait Limited July 2017
1.4.3 12VDC Input
Transmit
AW
Single 50W base station
Minimum RF output power (5W)
Maximum RF output power (50W)
8.8A
18A
106W
216W
Dual 50W base stationa
Minimum RF output power (5W)
Maximum RF output power (50W)
16A
36A
192W
432W
a. Both base stations transmitting.
100W base station
Minimum RF output power (10W)
50% RF output power (50W)
Maximum RF output power (100W)
14.6A
23.6A
32A
176W
285W
385W
Standby
AW
Single 50W and 100W base station 2.0A 24W
Dual 50W base station 3.3A 39W

TB9400 Specifications Manual Base Station Specifications 19
© Tait Limited July 2017
1.4.4 24VDC Input
Transmit
AW
Single 50W base station
Minimum RF output power (5W)
Maximum RF output power (50W)
4.4A
9A
106W
216W
Dual 50W base stationa
Minimum RF output power (5W)
Maximum RF output power (50W)
7.9A
17A
190W
408W
a. Both base stations transmitting.
100W base station
Minimum RF output power (10W)
50% RF output power (50W)
Maximum RF output power (100W)
7.1A
11.8 A
15.5A
171W
285W
370W
Standby
AW
Single 50W and 100W base station 975mA 23W
Dual 50W base station 1.6A 39W

20 Base Station Specifications TB9400 Specifications Manual
© Tait Limited July 2017
1.4.5 48VDC Input
Transmit
AW
Single 50W base station
Minimum RF output power (5W)
Maximum RF output power (50W)
2.1A
4.2A
101W
202W
Dual 50W base stationa
Minimum RF output power (5W)
Maximum RF output power (50W)
3.7A
7.8A
178W
374W
a. Both base stations transmitting.
100W base station
Minimum RF output power (10W)
50% RF output power (50W)
Maximum RF output power (100W)
3.2A
5.5A
7.4A
155W
265W
355W
Standby
AW
Single 50W and 100W base station 480mA 23W
Dual 50W base station 780mA 38W
