T&S B-2177 User manual

Installationand
Maintenance
Instructions
B-2177
Commercial Faucet
(shown without nozzle)
Deutsch: Installations- und
Wartungsanleitungen
Español: la Instalación y las
Instruccionesde
Mantenimiento
Français: lesInstructions
d’Installation et
d’Entretien
Limited One Year Warranty
T&Swarrantstotheoriginalpurchaser(otherthan
forpurposesofresale)thatsuchproductisfreefrom
defectsinmaterialandworkmanshipforaperiodof
one(1)yearfromthedateofpurchase. Duringthis
one-yearwarrantyperiod, iftheproductis foundto
bedefective,T&S shall,at itsoptions, repairand/
orreplaceit. Toobtainwarrantyservice,products
mustbereturnedto...
T&SBrassandBronzeWorks,Inc.
Attn: WarrantyRepairDepartment
2SaddlebackCove
TravelersRest,SC 29690
Shipping,freight,insurance,andothertranspor-
tationchargesoftheproducttoT&Sandthereturn
ofrepairedorreplacedproducttothepurchaserare
theresponsibilityofthepurchaser. Repairand/or
replacementshallbemadewithinareasonabletime
afterreceiptbyT&Softhereturned product. This
warrantydoesnotcoverItemswhichhavereceived
secondaryfinishingorhavebeenalteredormodi-
fiedafterpurchase, orfordefectscausedbyphysi-
calabuseto ormisuseoftheproduct,orshipment
oftheproducts.
Anyexpresswarrantynotprovidedherein,and
anyremedyforBreachofContractwhichmightarise,
is hereby excluded and disclaimed. Any implied
warrantiesofmerchantabilityorfitnessforaparticu-
larpurposearelimitedtooneyearinduration. Under
no circumstances shall T&S be liable for loss of
useor anyspecialconsequentialcosts,expenses
ordamages.
Somestatesdonotallowlimitationsonhowlong
andimpliedwarrantylastsortheexclusionorlimi-
tationof incidentalorconsequentialdamages,so
theabovelimitationsorexclusionsmay not apply
toyou. Specificrightsunderthiswarrantyandother
rightsvaryfromstatetostate.
P/N: 098-012431-45 Rev.0
Date: 990614
Drawn: CW
Checked: MAB11-12-99
Approved: MVW11-13-99

Exploded View
*Some items are listed for instructional purposes
and may not be sold as separate parts.
4
2
3
8
6
9
13
12
7
11
10 10
1
5
SIDE VIEW
11
2

Part Number Guide
Faucet Assemblies
1Base Faucet *
2Shank, Faucet *
3Washer, Rosette 001000-45
4Locknut 002954-45
5Spout *
6Aerator B-0199-01
7Cube *
8Asm, Spindle - Eterna RH - Cold 006009-40
9Asm, Spindle - Eterna LH - Hot 006010-40
10 Handle - Wrist Action 4" B-WH4
11 Screw, Handle 000925-45
12 Index, Button, Snap-In - Red (Hot) 001194-45
13 Index, Button, Snap-In - Blue (Cold) 001686-45
3

General Instructions
Installation: (Faucet)
1. Turn off water supply and drain lines. Drill (2) two 1” diameter holes, 4”
center-to-center in sink or countertop where you will be installing no.1.
2.After unpacking, remove no.4, no.3and no.2from each no.1.
1
2
sink
3
4
3. Place no.1into holes in sink top and replace no.2, no.3and no.4onto
threaded shank. Tighten no.4firmly with a wrench.
4. Connect water supply lines and check for leaks.
5
4

Instrucciones
Generales
Instalación: (Canilla)
1. Cierre la fuente de agua y desagüe las tuberías. Perfore (2) dos huecos de 1”
de diámetro en el lavatorio o el mostrador con centros de 8”, donde la parte
No.1 seráinstalada.
2. Desenpaque y remueva ambas partes No.4, No.3y No.2 del No.1.
1
2
Lavatorio
3
4
3. Coloque la parte No.1dentro de los huecos del lavatorio y coloque de nuevo
las partes No.2, No.3 y No.4en el asta con rosca. Firmemente apriete la parte
No.4con una llave.
4. Conecte las linias de surtido de agua e inspeccione por filtraciones.
5
