T&S B-1171 User manual

Installation and
Maintenance
Instructions
WORKBOARD FAUCET
B-1171 and B-1172
(with diverter valve)
Deutsch: InstallaƟons- und
Wartungsanleitun-
gen
Español: la Instalación y las
Instrucciones de
Mantenimiento
Français: les InstrucƟons d’In-
stallaƟon et d’Entre-
Ɵen
P/N: 098-009717-45 Rev.4
Date: 10-22-14
Drawn: TEH 10-22-14
Checked: JRM 11-04-14
Approved: JHB 11-10-14
Limited One Year Warranty
T&S warrants to the original purchaser
(other than for purposes of resale) that such
product is free from defects in material and
workmanship for a period of one (1) year
from the date of purchase. During this one-
year warranty period, if the product is found
to be defecve, T&S shall, at its opons,
repair and/or replace it. To obtain warranty
service, products must be returned to...
T&S Brass and Bronze Works, Inc.
AƩn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other
transportation charges of the product
to T&S and the return of repaired or
replaced product to the purchaser are the
responsibility of the purchaser. Repair
and/or replacement shall be made within a
reasonable me aer receipt by T&S of the
returned product. This warranty does not
cover Items which have received secondary
finishing or have been altered or modified
aer purchase, or for defects caused by
physical abuse to or misuse of the product,
or shipment of the products.
Any express warranty not provided
herein, and any remedy for Breach of
Contract which might arise, is hereby
excluded and disclaimed. Any implied
warranes of merchantability or fitness for
a parcular purpose are limited to one year
in duraon. Under no circumstances shall
T&S be liable for loss of use or any special
consequenal costs, expenses or damages.
Some states do not allow limitations
on how long and implied warranty lasts
or the exclusion or limitaon of incidental
or consequenal damages, so the above
limitaons or exclusions may not apply to
you. Specific rights under this warranty and
other rights vary from state to state.

Exploded View
2
3
2
18
1
21
22
10
11
12
13
19 20
4
5
6
7
8
9
14
15
16
17
23

3
Part Number Guide
Base Faucet Assemblies
1 Base Faucet N/A
2 Washer, Shank 000999-45
3 Locknut 002954-45
4 Washer 001043-45
5 Seat 000763-20
6 Valve, Diverter Piston 002338-45
7 Escutcheon Body (3-1/2” - 4” centers) 001258-40
Escutcheon Body (8” centers) 001259-40
8 Locknut, Cover Plate 000712-25
9 Asm, Spindle - LTC, Includes Screw, Index & Handle 002709-40
Asm, Spindle - RTC, Includes Screw, Index & Handle 002710-40
10 Spindle - LTC 009754-25
Spindle - RTC 009753-25
11 Handle 001638-45
12 Index, Buon - Blue 001660-45
Index, Buon - Red 001661-45
13 Screw, Lever Handle 000922-45
14 Adapter, Diverter 001484-20
15 O-Ring, Center Body 001069-45
16 Screw, Diverter Cover 001486-45
17 Cover, Diverter 001485-40
Nozzle Assemblies
18 Nozzle Tip 000863-25
19 Washer 001048-45
20 Screen 001323-45
21 Swing Nozzle N/A
22 Hose Guide 001496-45
23 Hose Spray 001495-45

4
5. Reinstall no.2and no.3back onto
no.1shank under boom of sink.
Connect water supply to no.1.
6. Tighten no.3with a wrench.
Spray Hose/Diverter InstallaƟon
7. Disassemble no.22, place shank
of no.22 thru hole for no.23. Tighten
locknut of no.22.
8. Apply teflon tape to threaded end
of no.23. Insert no.23 through no.22
and aach to no.1.
9. Turn on water supply and check for
leaks.
Nozzle InstallaƟon:
Note: Nozzle should be installed first.
See diagram below:
1. Place no.17 over no.14. Insert
no.16 into each side of no.17.
2. Apply teflon tape or pipe joint
compound to threaded end of no.21.
Screw no.21 into no.17, rotate no.17
so that no 21 is facing front, ghten
no.16.
Faucet InstallaƟon:
3. Shut offwater supply and drain
lines. Drill (4) four holes, into
countertop where you are installing
no.1.
21
17
16
14
sink
2
3
1
water
supply
water
supply
4. Place no.1into the (3) three
pre-drilled mounng holes.
1
22
23
22
sink
General Instructions
Ø 1”
Ø 1”
8” (for B-1172)
2” (for B-1171)
4” Min.
for no.23
4” (for B-1171)
4” (for B-1172)

5
5. Instale de nuevo las partes No.2
y No.3en el tronco de la parte No.1
debajo del fondo del lavatorio.
Conecte el surdo de agua a la parte
No.1.
6. Apriete No.3con una llave.
Instalación Del Desviador para La
Manguera Roceadora
7. Desarme la parte No.22, coloque el
tronco de la parte No.22 a través del
hueco para la parte No.23. Aprete la
contra tuerca de la parte No.22.
8. Aplique cinta para rosca de tubería
al extremo con rosca de la parte
No.23. Insarte la parte No.23 a través
de la parte No.22 y júntelo a la parte
No.1.
9. Abra la fuente de agua e
inspeccione por filtraciones.
Instalación De La Boquilla:
Nota: La boquilla debe de ser
instalada primero. Mire el dibujo de
abajo:
1. Coloque la parte No.17 sobre la
parte No.14. Coloque las partes
No.16 dentro de ambos lados de la
parte No.17.
2. Aplique cinta para rosca de
tubería o compuesto de coyuntura al
extremo con roscas de la parte No.21.
Atornille la parte No.21 entre la parte
No.17, gire la parte No.17 debido a
que la parte No.21 esté oscilada hacia
el frente, aprete la parte No.16.
Instalación De La Canilla:
3. Cierre la fuente principal de agua y
desagüe las tuberias. Perfore (4) cu-
atro huecos, en el mostrador donde
será instalada la parte No.1.
21
17
16
14
Lavatorio
SurƟdo De Agua
4. Coloque la parte No.1entre los (3)
tres huecos hechos anteriormente.
1
22
23
22
Lavatorio
2
3
1
Instrucciones Generales
Ø 2.5cm
Ø 2.5cm
20cm (por B-1172)
5cm (por B-1171)
10cm Min.
por No.23
10cm (por B-1171)
10cm (por B-1172)

6
5. Réinstaller Nº.2et Nº.3sur la
jambe au-dessous l’évier. Brancher le
tuyau qui fournir l’eau à Nº.1.
6. Resserrer Nº.3avec une clef.
Le Tuyau De Jet/ L’InstallaƟon
D’Aiguillage:
7. Désassembler Nº.22, mere la
jambe de Nº.22 à travers le trou de
Nº.23. Resserrer l’écrou de Nº.22.
8. Appliquer le ruban en Téflon à
l’extrémité avec les filets de Nº.23.
Inserer Nº.23 à travers Nº.22 et
aacher à Nº.1.
9. Recommencer l’eau et vérifier s’il y
a des fuites.
L’InstallaƟon De L’Ajutage:
Noter: Les ajutages devoir être in-
staller au début. Voir le diagramme
ci-dessous:
1. Mee Nº.17 sur Nº.14. Insérer
Nº.16 dans chaque côté de Nº.17.
2. Appliquer le ruban en Téflon ou le
composé pour les tuyaux à l’ex-
trémité avec les filets de Nº.21. Visser
Nº.21 dans Nº.17, tourner Nº.17
jusqu’à Nº.21 être en face, resserrer
Nº.16.
L’InstallaƟon Du Robinet:
3. Fermer la réserve de l’eau et
égouer la tuyauterie. Percer (4)
quatre trous (3 trous pour B-1172)
dans le comptoir où vous aller in-
staller Nº.1.
l’évier
le tuyau qui
fournir l’eau
4. Mere Nº.1dans les trois trous
déjà préparés.
1
23
21
17
16
14
22
22
l’évier
2
3
1
Instructions Générales
Ø 2.5cm
Ø 2.5cm
20cm (pour B-1172)
5cm (pour B-1171)
10cm Min.
pour Nº.23
10cm (pour B-1171)
10cm (pour B-1172)

7
SpülƟsch
5. Nr.2und 3auf der Unterseite
des Spülsches wieder auf den
Schavon 1aufsetzen. Nr.1mit der
Wasserleitung verbinden.
6. Nr.3mit einem Schraubenschlüssel
anziehen.
Brausenschlauch/InstallaƟon des
Umstellers
7. Nr.22 auseinandernehmen, Scha
von Nr.22 durch das Loch für Nr.23
stecken. Gegenmuer von Nr.22
anziehen.
8. Das Gewinde von Nr.23 mit
Teflonband umwickeln. Nr.23
durch Nr.22 hindurchstecken, Nr.22
anziehen.
9. Wasserzufuhr andrehen und auf
Lecks prüfen.
SchwenkhahninstallaƟon:
Anmerkung: Der Schwenkhahn ist als
ertes zu installieren. Siehe Zeichnung
unten:
1. Nr.17 auf Nr.14 aufsetzen. Nr.16 in
beide Seiten von Nr.17 einfügen.
2. Teflonband oder Rohrdichtmasse
auf das Gewinde von Nr.21 auragen.
Nr.21 in Nr.17 einschrauben, Nr.17
so drehen, daß Nr.21 nach vorn
ausgerichtet ist, Nr.16 anziehen.
ArmatureninstallaƟon:
3. Wasserzufuhr abstellen und
Leitungen entleeren. Vier (4)
Löcher (3 Löcher für B-1172) in
die Abdeckpae bohren, wo Nr.1
installiert wird.
21
17
16
14
Wasserzufuhr
4. Nr.1in die drei vorgebohrten
Löcher einsetzen.
1
22
23
22
SpulƟsch
2
3
1
Allgemeine Anleitungen
2,5cm Durchmesser
2,5cm Durchmesser
20cm (für B-1172)
5cm (für B-1171)
10cm Min.
für Nr.23
10cm (für B-1171)
10cm (für B-1172)
