T&S EasyInstall B-2300 Series User manual

20
19
13
12
10
1
92
22
3
11
14
16
7
5
6
4
8
21
15
18
23
25
12
23
24
17
8
20
19
P/N:
DATE:
DRAWN:
CHECKED:
APPROVED:
098-016898-45 Rev.3
11-08-2010
TED
JRM 08-04-2020
JHB 08-11-2020
8” FIXED CENTER
CONCEALED
WIDESPREAD
B-2300, B-2800,
B-2900 SERIES
Installation and
Maintenance
Instructions
Patent # 7,472,434
Parts List
Option B
Option B:Contains low-profile escutcheons to
accommodate push button metering, pivot action metering,
fast self-close and wrist action metering.
Base Faucet Assembly
1 Base Faucet Assembly N/A
2 Side Flange Nut N/A
3 C-Washer 016749-45
4 Center Flange Nut 016742-45
5Compression & Nut Fitting 016745-45
6 Compression Nut N/A
7 Compression Fitting N/A
8 Center Shank, Swivel 016754-40NS
9 Coupling Nut 000958-20
12 Escutcheons:
11 Escutcheons, Bell 001257-40NS
12 Escutcheons, Metering 017292-45 Opt.B
19 Swivel Goosenecks Inquire w/ T&S
20 Aerators:
55/64-27 Female Threads B-0199-01
3/8” NPSM Male Threads B-0199-02
13/16-27 Male Threads B-0199-03
Stream Regulator, Plain B-LT
Stream Regulator w/ Screen B-PT
Rosespray B-0103-01
20 Sidespray & Hose Assembly 001495-45
21 Star Washer, Anti-Rotation 014200-45
22 Hanger 016777-45
Cartridge Assemblies
10 Cartridge Only, Eterna w/ Spring Checks RTC 016753-40NS
20 Cartridge Only, Cerama w/ Check Valves RTC 016767-25NS
11 Cartridge Only, Eterna w/ Spring Checks LTC 016752-40NS
22 Cartridge Only, Cerama w/ Check Valves LTC 016768-25NS
23 Push Button Metering Cartridge (shown) 238A Opt.B
23 Wrist Action Metering Cartridge 012449-40 Opt.B
24 Pivot Action Metering - Hot (shown) 238AH-PA Opt.B
Push Button Metering - Hot 238AH Opt.B
25 Pivot Action Metering - Cold (shown) 238AC-PA Opt.B
Push Button Metering - Cold 238AC Opt.B
Handle Assemblies
13 Handle, 4”Wrist Action (shown) B-WH4-NS
6Handle, Lever 001638-45NS
6Handle, 4-Arm 002521-45NS
14 Screw, Handle 000925-45
15 Index, Button Snap-In Hot (Red) 001193-19NS
16 Index, Button Snap-In Cold (Blue) 018506-19NS
17 Pivot Action Handle - Hot PA-H Opt.B
18 Pivot Action Handle - Cold PA-C Opt.B
Hot Cap Assembly 014194-40 Opt.B
Cold Cap Assembly 014195-40 Opt.B
Fast Self-Closing Asm - Cold 014A-NS Opt.B
Fast Self-Closing Asm - Hot 015A-NS Opt.B
Limited One Year Warranty
(Commercial Applications)
T&S warrants to the original purchaser (other than for purposes of resale) that such product is
free from defects in material and workmanship for a period of one (1) year from the date of purchase.
During this one-year warranty period, if the product is found to be defective, T&S shall, at its options,
repair and/or replace it. To obtain warranty service, products must be returned to...
T&S Brass and Bronze Works, Inc.
Attn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other transportation charges of the product to T&S and the return
of repaired or replaced product to the purchaser are the responsibility of the purchaser. Repair and/
or replacement shall be made within a reasonable time after receipt by T&S of the returned product.
This warranty does not cover Items which have received secondary nishing or have been altered
or modied after purchase, or for defects caused by physical abuse to or misuse of the product, or
shipment of the products.
Any express warranty not provided herein, and any remedy for Breach of Contract which might
arise, is hereby excluded and disclaimed. Any implied warranties of merchantability or tness for a
particular purpose are limited to one year in duration. Under no circumstances shall T&S be liable for
loss of use or any special consequential costs, expenses or damages.
Some states do not allow limitations on how long and implied warranty lasts or the exclusion or
limitation of incidental or consequential damages, so the above limitations or exclusions may not apply
to you. Specic rights under this warranty and other rights vary from state to state.
Attention California Residents:
WARNING This product can expose you to chemicals including Lead, Chromium (hexavalent
compounds) and Phthalates (DEHP) which are known to the State of California to cause cancer
and birth defects or other reproductive harm.
For more information go to
www.P65Warnings.ca.gov.

Before starting the installation, be sure to flush supply lines and shut off water supply.
Faucets with side spray or Pedal Valve connection: you must remove diverter from center shank, using a flat head screwdriver, before separating center shank from body for install.
Step 1:
Take center shank out of body.
Step 3:
Insert body into deck holes until hanger snaps to top of deck.
Place c-washers under bonnet nuts on side bodies.
Step 5:
Squeeze hanger loops and allow hanger to drop through center
hole.
Step 4:
Option B: Screw metering escutcheons over c-washers. Tighten
cartridges.
Step 6:
Remove nuts as shown. Option B: Remove retaining rings from cartridges.
Place center body through center hole into main body. Tighten 3 flange
nuts. Tighten compression nut to seal center body.
1. Tighten diverter to center body using
flat head screwdriver.
2. Remove locknuts from hose guide,
place it through existing hole in sink.
Reinstall locknut on the hose guide.
Tighten by hand.
3. Apply Teflon tape to threaded end of
sidespray, insert through hose guide and
attach threaded end of side spray to base
of center body. Tighten with wrench.
4. Turn on water and check for leaks.
Step 2:
Place hanger on body. Add center flange nut to top of
compression nut. Option B: Remove cartridges.
Step 7:
Add escutcheons, packing nuts, handles, spout and tighten. Option B: Add
handles, retaining rings, spout and tighten. Turn on water supply and check for
leaks.
For models with sidespray:
Option B Option B
Option B
Option B
Option B
Option B
Swivel to Rigid GooseneckSwivel to Rigid Gooseneck
OptionOption: Uninstall and lift
out gooseneck. Place star
washer into swivel body.
Reinstall gooseneck.
