DXV Keefe D35104900 User manual

- 1 -
INSTALLATION INSTRUCTIONS
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2017
SAVE FOR FUTURE USE
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
M965481 Rev. 1.6 (5/17)
Model D35104900
Keefe®
Deck Mount Tub Filler
with Hand Shower
ROUGHING-IN DIMENSIONS:
• For reference
Adjustable Wrench Phillips ScrewdriverChannel Locks
Flat Blade Screwdriver
Basin Wrench
1-1/4" D.
(32 mm)
2-3/8" D.
(60 mm)
8-1/4"
(210 mm)
12" MAX. (305 mm)
1-3/8" D.
(35 mm)
NOTE: MOUNTING HOLES
ARE 1-3/8" D. (35 mm) for handles
1-1/4" D. (32 mm) for spout
3/4"NPT
INLETS
8" TO 12" MAX.
(203 to 305 mm)
3/4" D.
(19 mm)
2-3/5"
(65.3 mm)
2-1/8"
(53.7 mm)
3-7/8"
(98.4 mm)
1-1/2" MAX.
(38 mm) 1-1/2" MAX.
(38 mm)
4-9/10"
(124.8 mm)
8-1/2"
(216.2 mm)
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: [phone]
www.DXV.com
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: [phone]
www.DXV.ca
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
Thank you for selecting DXV. To ensure that your
installation proceeds smoothly, please read these
instructions carefully before you begin.

- 2 - M965481 Rev. 1.6 (5/17)
1
2
2a
HOSE ASSEMBLY
HAND SHOWER ASSEMBLY
• Insert FIBER WASHERS (1) into COUPLING NUTS (2)
of SUPPLY HOSES (3) and tighten.
NOTE: Back flow prevention and 2.5 GPM flow restrictions are included with all
Roman tub sets with hand shower.
• T-PIECE (8) and COUPLING NUT (9) are factory pre-installed on SPOUT
SHANK (1) and must be removed to install spout. Unthread COUPLING NUT
(9) and pull off T-PIECE (8).
• Insert SPOUT SHANK (1) through center hole of sink or mounting surface.
Install WASHER (2).
• Assemble RUBBER WASHER (3), FIBER WASHER (4) and LOCKNUT (5)
onto threads of SPOUT SHANK (1). Tighten rmly.
• Grease O-RING (6 & 7). Assemble T-PIECE (8) onto the SPOUT SHANK (1)
and tighten with COUPLING NUT (9).
• Slide the T-PIECE (8) onto SPOUT SHANK (1) until it makes contact
with the O-RING (6). Thread COUPLING NUT (9) onto SPOUT
SHANK (1). Rotate T-PIECE (8) about 10 degrees from center and
tighten securely. Make sure both O-Rings (6 & 7) are seated into
grooves of T-PIECE (9).
SPOUT AND T-PIECE ASSEMBLY
CAUTION Turn off hot and cold water
supplies before beginning.
IMPORTANT NOTICE TO THE INSTALLER
Please check with your local Code Authority for acceptable installation requirements forthis
Roman Tub set with hand shower. Some local codes may require a vacuum breaker and/or
a pressure balanced mixing valve to be installed in conjunction with this product.
• Drop SPRAY HOLDER (4) into the fourth hole of the
tub ledge or deck (12" max from SPOUT center)
directed towards tub center. Be sure O-RING (5)
is properly seated in ESCUTCHEON (6). Install
RUBBER WASHER (7), FIBER WASHER (8) and
LOCKNUT (9) from underside of mounting
ledge. Secure SPRAY HOLDER (4)
by tightening LOCKNUT (9).
• Add SEAL WASHER (10) and connect
COUPLING NUT (11) of BRAIDED HOSE (12)
to outlet nipple. Tighten rmly. Tighten SPRAY
REST (19).
• Slip SHOWER HOSE (13) with
COUPLING NUT (14) through SPRAY
HOLDER (4) and ESCUTCHEON (6).
• Install SEAL (15) into COUPLING NUT (14).
Connect COUPLING NUT (15) to
HOSE NIPPLE (16) and tighten.
• INSTALL second SEAL (15) and
connect HANDS HOWER (17)
to SPRAY HOSE END (18). Hand tighten.
GROOVE
IN TEE
GROOVE IN TEE
10°
3
4
5
8
9
7
12
6
TRANSFER
KNOB
14
2
2
1
1
11
12
13
3
3
10
15
8
BRAIDED
HOSE
16
15
5
6
4
OUTLET
NIPPLE
9
18
7
3
19
17

- 3 - M965481 Rev. 1.6 (5/17)
3
4MAKE WATER SUPPLY CONNECTIONS
• Connect HOT water supply to LEFT INLET UNION (1)
and COLD water supply to RIGHT INLET UNION (2).
Pipe connections are 3/4" (19 mm) NPT. Use sealant
or Teon tape on pipe connections.
Do not solder directly to valve body.
TEST INSTALLED FAUCET
• Remove AERATOR from FAUCET.
• With HANDLES in OFF position, turn
on WATER SUPPLIES and check all
connections for leaks.
• Operate both HANDLES to ush water
lines thoroughly.
• Replace AERATOR.
• Lift HAND SHOWER from HOLDER,
direct spray into tub. Lift TRANSFER KNOB
to check HAND SHOWER and HOSES
for leaks.
• Turn handles “off” and replace HAND SHOWER.
INSTALL VALVE BODIES
• HANDLE ASSEMBLIES (1, 1A) are installed on VALVE BODIES (2)
and must be removed to install VALVE BODIES (2) from under
tub deck or mounting surface.
• To remove HANDLE ASSEMBLY (1), unthread HANDLE BASE (3)
with LEVER (4) from VALVE BODY (2). Pull HANDLE ASSEMBLY (1)
off VALVE STEM (5).
• Unthread and remove MOUNTING RING (6) and SPACER (7).
• Thread LOCKNUT (8) to bottom of VALVE BODY (2). Make sure
FIBER WASHER (9) and RUBBER WASHER (10) are installed.
Insert VALVE BODY (2) through mounting hole from underside
of tub deck or mounting surface.
NOTE: VALVE BODY marked Hot is installed in the left Mtg. hole,
VALVE BODY marked Cold in the right when facing front
of fitting Maximum mounting surface thickness is 1-1/2".
• From top install SPACER (7) onto VALVE BODY (2). Thread
MOUNTING RING (6) on VALVE BODY (2) until seated tightly
against SPACER (7). Set VALVE BODIES (2) so that their outlets
are facing toward SPOUT TEE (11) and then tighten LOCKNUT (8)
using 35 mm or adjustable wrench.
• Insert RUBBER WASHERS (12) into COUPLING NUTS (13) of
SUPPLY HOSES (14) and tighten making water tight connection.
Important: Loop SUPPLY HOSES (14) as illustrated so they do not kink.
INSTALL HANDLES
• Turn VALVE BODIES (2) to off position. Align HANDLES as shown or as desired and install HANDLE ASSEMBLY (1, 1A)
onto VALVE STEM (5). Thread HANDLE BASE (3) onto VALVE BODY (2) until seated tightly against mounting surface.
1-1/2'' MAX.
"O" RING
6
1
3
4
8
12
HOT
13
14
911
10
7
5
2
"O" RING
TUB DECK OR
MOUNTING SURFACE
HOT COLD
3/4" D.
IMPORTANT: It is strongly recommended that
access be provided for all enclosed mechanical
parts to this system.
3/4" X 3/4" NPT UNION
(NOT SUPPLIED)
HOT
COLD
3/4" NPT
TRANSFER KNOB
3/4" NPT
2
1
HAND
SHOWER

- 4 -
H960001.191
3/4 HOT
CARTRIDGE
H961267.191
SPOUT TEE WITH DIVERTER
H960170.191
3/4 COLD
CARTRIDGE
(CLOCKWISE ON)
H960893.191
3/4 SIDE VALVE
(CLOCKWISE ON)
H960194.191
HOSE ASSEMBLY
M964549-0070A
STREAM STRAIGHTENER
H960294.191
VALVE
MOUNTING KIT
M964591-0070A
TRANSFER
ROD ASSEMBLY
M964542-YYY0A
POP-UP KNOB KIT
M970043-XXX0A
SPOUT SET SCREW KIT
M964534-YYY0A
HANDLE KIT
H960185C.191
SPOUT HOSE
ASSEMBLY
M964557-YYY0A
HAND SHOWER
HOLDER KIT
D35104781.XXX
HAND SHOWER
H960440.XXX
HAND SHOWER
HOSE KIT WITH SEALS
012668-0070A
SHANK KIT
H960743.191
3/4" SIDE VALVE
(COUNTER-
CLOCKWISE ON)
M965481 Rev. 1.6 (5/17)
Replace the “YYY” with
appropriate finish code
POLISHED CHROME 100
BRUSHED NICKEL 144
MODEL NUMBERS
D35104900
Keefe®
Deck Mount Tub Filler
with Hand Shower
