Techni Mobili RTA-3265C User manual

REV.AOF-7372-0623
Techni Mobili Modern Ergonomic Office Chair
MODEL RTA-3265C
ASSEMBLY INSTRUCTIONS
Thank you for purchasing our product

Replacement Parts for International
Customers & AK-HI-PR orders:
RTA Products will replace the part free of
charge, while the customer is responsible
for shipping costs plus any International
local taxes or duties.
Do a quick inventory
of all the parts and
hardware listed below.
For Support, assembly questions
& Replacement Parts within the
48 Contiguous United States:
Please email us at:
[email protected]
P.1 P.1
RTA-3265C
A
x1 B
x1 C
x1 D
x1
Backrest Seat 5-Leg star metal
base Mechanism with
tension knob and
latch
E
x1 F
x5 G-L
x1 G-R
x1
Lift cylinder Caster Left armrest Right armrest
Headrest
H
x1
MAIN PARTS LIST
(Front) (Front)
Sitting on the
chair, not
looking at it
Sitting on the
chair, not
looking at it
PART # SIZE / DESCRIPTION USE IN
QTY
M8x40
3
Mechanism, backrest
7
Backrest to mechanism
K
L
M
HARDWARE LIST
Ø8, Ø15
Metal washer
Ø6, Ø14
Metal washer
6Armrests
M6 Allen wrench
1Use in steps 1, 2, 3 & 6
INCLUDED TOOLS
N
Ø17 Plastic cap
2Headrest
(Scaled
reference)
M6x206
Armrests to seat
M6x30
6
Mechanism to seat;
headrest to backrest
I
J
6

P.2 P.2
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
• Do not discard this manual or any of the packaging
material until the unit is completely assembled.
• Please read the assembly instructions throughly and
follow step by step.
√
√
M6
30mm
M6x30
• Make sure you understand which
hardware will be used on each step. Using
the wrong size of screw, bolt or pin might
strip the threads or cause damage to the
part in which it is being used.
• To avoid misalignments, always leave the screws
loosely and do not tighten them until all the pieces
are positioned correctly.
• Do not overtighten or force the screws as they might
break, strip, damage the threads of the holes, or get
stuck inside the parts.
• If the hole seems too small for the screw, make sure
you are using the correct size of screw and/or that
you are installing it in the correct hole.
• Sometimes the fabric or material might cover partially
or entirely the screw hole, making the hole appear to
be too small or not visible at all.
RTA-3265C

P.3 P.3
Turn over the seat Band assemble the armrests G-L, G-R in their respective
sides with screws J and washers M. Please note that the armrest side (left or
right) goes by you sitting on the chair, not looking at it.
STEP 1
Hardware
JM6x30
6
Pcs
RIGHT
G-R
B
(Front)
(Front)
(Front)
(Back)
(Front)
(Back)
LEFT
G-L
A goes under D
(x6)
A
ASSEMBLY STEPS
IM6x20 4
Pcs
Place the mechanism Dover the seat Bmaking sure the tension knob faces
towards the front, then secure it with screws Iand washers L.
L4
Pcs
STEP 2
Hardware
D
B
Attach the backrest Aunder the latch of the mechanism Dwith screws Kand
washers L. The screws go through Dand into A.
D
Knob towards
the Front
RTA-3265C
J
M
MØ6, Ø14
6
Pcs
(x6)
(x4)
I
L(x4)
6
Ø8, Ø15
(x3)
K
L(x3)
LEFTRIGHT
KM8x40 3
Pcs
L3
Pcs
STEP 3
Hardware
Ø8, Ø15
(Front)
(Back)
6
6

A
H
I
N
STEP 5
P.4 P.4
Join the base parts to the seat making sure the tip of the lift Eenters correctly
into the hole of the mechanism D.
RTA-3265C
Or:
Assemble the headrest Hto the backrest Awith screws I, then cover the holes
with N.
E
D
STEP 4 Insert the casters Finto each leg of the base Cusing pressure, then place the
lift cylinder Ein the middle of the base.
F
C
E
C
IM6x20 2
Pcs
N2
Pcs
STEP 6
Hardware
Cap
6

RTA-3265C
P.5 P.5
To raise or lower the chair’s height, flip DOWN the handle on the lever that is under the seat on
the right side. The chair goes down while sitting on it, or up if you lift your body.
To make the backrest recline freely, pull OUT the same lever.
You can turn the tension knob at the front of the mechanism under the seat to make the
reclining feel either easier or with more resistance according to your preference.
To lock the backrest in one of the preset angles, pull OUT the lever, recline and then push IN
the lever. To return to the normal upright position, UNLOCK the lever, push back a little bit on
the backrest, then pull yourself forward and lock the lever.
To adjust the armrest height, press the button that is on the outside of the armrest and release
it once the desired height is reached.
For comfort, the headrest can be adjusted UP and DOWN or tilted forward/backwards.
You can adjust the height of the lumbar suport by moving it UP or DOWN, and the depth is
adjusted by turning the knob in either direction.
CHAIR'S FUNCTIONS
1
2
3
4
6
5
5
4
2
3
• To clean the chair it is recommended to use a soft cloth lightly damped in a solution of smooth
soap and water, then dry with a clean towel.
• Do not use solvents or abrasive materials to clean any part of the chair.
• Before using a cleaning agent, test on a small hidden area of the chair, like underneath the seat.
• Do not expose the product to direct sunlight or to extreme environmental conditions.
• Inspect the chair completely every 4 months and make sure that all screws are tightened.
CARE AND MAINTENANCE
WARNINGS
• Do not exceed the indicated weight limit.
• Do not use if parts are bent, damaged, or if screws are loose or missing.
• Only one person at a time can sit on the chair.
• Do not sit babies or toddlers alone.
• If children (3 years and older) are sitting on the chair, always keep close
observation on them.
• Do not allow small children to play with the chair.
• Do not stand up on the chair or use it as ladder.
• Do not sit too close to the edge of the seat to avoid going beyond your
balance point and falling off the chair, and always sit properly.
• Not paying attention to these warnings could result in injuries.
WEIGHT LIMIT
250
Lbs
(113.6 Kg)
7
1
6
5
4

P.6 P.6
TECHNI MOBILI WARRANTY
RTA Products, LLC has warranted the Techni Mobili office chairs to the original purchaser who acquired a
new product from RTA Products or its authorized resellers of the product against defects in material or
workmanship.
This warranty is expressly limited to the repair or replacement (at its option) of defective chair components
or materials that fails under normal use as a result of a defect in materials or workmanship. This warranty is
limited to merchandise purchased in the Continental United States, excludes AK, HI and PR. No assembly
labor is included. The word "defects" as used in this warranty, is defined as imperfections that impair the
utility of the product.
This warranty applies under conditions of normal use, but does not apply to defects that result from
intentional damage, negligence, unreasonable use or exposure.
Liability for consequential damages is excluded to the extent exclusion is permitted by law. This warranty
gives you specific legal rights, and you may have other rights that vary from State to State.
RTA Products does not warrant: a) natural variations in character marks b) changes in surface finishes due
to aging or exposure to light c) marks, scars, or wrinkles occurring naturally in leather d) failure resulting
from normal wear and tear e) the matching of colors, grains, or textures of natural materials f) the
colorfastness or the matching of textiles, including an exact match to cuttings or to swatch cards g)
damage, marking, or staining of veneer surfaces due to contact with rubber or similar compounds, damage
from sharp objects or imprinting from writing instruments, or prolonged exposure to direct sunlight h) we do
not warrant products that are exposed to extreme environmental conditions or that have been subject to
improper storage.
RTA Products shall not be liable for loss of time, inconvenience, commercial loss, or incidental or
consequential damages.
Any modification to the original product voids the warranty. We do not warrant the performance of the
product when used in combination with other than original products.
This product has been designed for and is intended for office and home-office use only. This warranty is
Original Purchaser’s sole remedy for product defects, and this warranty does not extend to any product, or
damage to any product, caused by or attributed to abuse or misuse, products used for commercial or rental
purposes, use modifications of, or attachments to the product, and products or parts not used, maintained,
or extended hereunder is in lieu of any and all other warranties, express or implied, including without
limitations any implied warranty or merchantability or of fitness for a particular purpose.
To file a Claim within the 48 contiguous United States: Email us to [email protected] to explain
the defect and provide your name, address, phone number, model number of our product, date and place,
and proof of purchase. Please provide pictures of the damage or defect.
If we determine that a replacement will remedy the situation, and in order to determine the extent or the
cause of the defect, purchaser may be requested to send the part in question at purchaser’s expense.
Once we receive the part, we will examine it and determine whether the claim is valid (or not), and then
proceed to send the replacement. We will ship the replacement at our expense.
Replacement Parts for International Customers & AK-HI-PR orders: RTA Products will replace the part free
of charge, while the customer is responsible for shipping costs plus any International local taxes or duties.
TECHNI MOBILI CHAIR WARRANTY
EXECUTIVE/MANAGER CHAIR: 2-YEAR WARRANTY
RTA-3265C
