Technoline TEMPERATURE STATION User manual

WIRELESS 868 MHz TEMPERATURE STATION
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this compact 868MHz Temperature Station which
simultaneously displays time, indoor temperature and outdoor temperature
readings. With only two keys, being easy to operate, this product is ideal for use in
the home or office.
42

FEATURES:
43
LCD
Displa
y
Function
Keys
Hanging
Hole
Battery
compartment
cover
Removable
stand

44
The Temperature Station
• Quartz clock in 12 or 24-hour time display (hour and minute, manually set)
• Indoor and outdoor temperature reading in or degree Celsius (°C) or
Fahrenheit (°F)
• Can receive up to two outdoor transmitters for 3 outdoor channels
• Can show the outdoor reading of channel 1, 2 and 3 simultaneously
• Wireless transmission at 868 MHz
• Signal reception intervals at 4 seconds
• Minimum and Maximum records of indoor temperature and outdoor
temperature
• Low battery indicator
• Wall mounting or table standing

The Outdoor Temperature Transmitter
• Remote transmission of outdoor temperature to
Temperature Station by 868 MHz
• Shower proof casing
• Wall mounting case (Mounting at a sheltered place.
Avoid direct rain and sunshine)
45

46
SETTING UP:
When one transmitter is used
1. First, insert the batteries into the Temperature transmitter. (see “Install
and replace batteries in the Temperature transmitter“).
2. Immediately after and within 30 seconds, insert the batteries into
Temperature station (see “Install and replace batteries in the
Temperature station”). Once the batteries are in place, all segments of
the LCD will light up briefly. Following the time as 0:00 and the indoor
temperature will be displayed. If these are not displayed after 60 seconds,
remove the batteries and wait for at least 10 seconds before reinserting
them.
3. After inserting the batteries, the Temperature station will start receiving
data from the transmitter. The outdoor temperature and the signal

47
reception icon should then be displayed on the Temperature station. If this
does not happen after 3 minutes, the batteries will need to be removed
from both units and reset from step 1.
4. In order to ensure sufficient 868 MHz transmission however, this should
under good conditions be a distance no more than 100 meters between
the final position of the Temperature station and the transmitter (see notes
on “Mounting” and “868 MHz Reception”).
When more than one transmitter is used
1. User shall remove all the batteries from the temperature station and
transmitters and wait for 60 seconds if setting has been done with one
transmitter before.
2. Insert the batteries to the first transmitter.

48
3. Within 30 seconds of powering up the first transmitter, insert the batteries to
the Temperature station. Once the batteries are in place, all segments of the
LCD will light up briefly. Following time as 0:00 and the indoor temperature
will be displayed. If they are not shown in LCD after 60 seconds, remove the
batteries and wait for at least 60 seconds before reinserting them.
4. The outdoor temperature from the first transmitter (channel 1) should then
be displayed on the Temperature station. Also, the signal reception icon will
be displayed. If this does not happen after 2 minutes, the batteries will need
to be removed from both units and reset from step 1.
5. Insert the batteries to the second transmitter as soon as the outdoor
temperature readings from the first transmitter are displayed on the
Temperature station.

49
Note: User shall insert the batteries into the second transmitter within 10 seconds
of reception of the first transmitter.
6. The outdoor temperature from the second transmitter and the "channel 2"
icon should then be displayed on the Temperature station. If this does not
happen after 2 minute, the batteries will need to be removed from all the
units and reset from step 1.
7. Insert the batteries to the third transmitter as soon as the "channel 2" icon
and outdoor data are displayed on the Temperature station. Then within 2
minutes, the channel 3 outdoor data from the third transmitter will be
displayed and the channel icon will shift back to "1" once the third
transmitter is successfully received. If this is not happen, user shall restart
the setting up from step 1.

50
Note: User shall insert the batteries into the third transmitter within 10 seconds of
reception of the second transmitter.
8. In order to ensure sufficient 868 MHz transmission however, this should
under good conditions be a distance no more than 100 meters between
the final position of the Temperature station and the transmitter (see notes
on “Mounting” and “868 MHz Reception”).
IMPORTANT:
Transmission problems will arise if the setting for additional sensors is not followed
as described above. Should transmission problems occur, it is necessary to
remove the batteries from all units and start again the set-up from step 1.

HOW TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE
STATION The Temperature Station uses 2 x AAA, IEC LR3, 1.5V
batteries. When batteries will need to be replaced, the
low battery icon will appear on the LCD. To install and
replace the batteries, please follow the steps below:
1. Lift up the battery compartment cover.
2. Insert batteries observing the correct polarity (see
marking).
3. Replace compartment cover.
51

INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE
TRANSMITTER
52
The Temperature Transmitter uses 2 x AA, IEC LR6, 1.5V battery. To install and
replace the batteries, please follow the steps below:
1. Remove the battery compartment cover at the
back of the outdoor temperature transmitter.
2. Insert batteries observing the correct polarity (see
marking).
3. Replace compartment cover.

Note:
In the event of changing batteries in any of the units, all units need to be reset by
following the setting up procedures. This is because a random security code is
assigned by the transmitter at start-up and this code must be received and stored
by the temperature station in the first 3 minutes of power being supplied to it
BATTERY CHANGE:
It is recommended to replace the batteries in all units regularly to ensure optimum
accuracy of these units. (Battery life – see Specification)
Please participate in the preservation of the environment. Return
used batteries to an authorized depot.
53

FUNCTION KEYS:
Temperature Station:
54
MIN/MAX/+
key
SET/CH ke
y
The Temperature Station has only two easy to use function keys.

55
SET/CH key (Setting/Channel)
• Press and hold for about 3 seconds to enter the Manual setting mode.
• Press shortly to show all outdoor channel readings
MIN/MAX/+ key (Min/ Max temperature)
• Used to toggle between the minimum and maximum recorded readings of
indoor & outdoor temperature.
• Press and hold to reset minimum and maximum record (when min or max
record is shown).

LCD SCREEN AND SETTINGS:
56
Outdoor Reception
Signal icon
#
Receiver Low battery
indicator
Time OR Indoor
temperature*
Indoor
Temperature OR
Outdoor Temp of
Channel 1*
Channel
No.
Outdoor
Temperature

*Showing Three Outdoor channel simultaneously
When all the three channels are occupied, if the SET/CH key is pressed, user may
view the indoor reading and three channel readings simultaneously, while the time
display is hidden.
57
Channel 1
Outdoor Temp
Channel 2
Outdoor Temp
Channel 3
Outdoor Temp
Channel
No.
Indoor Temp

#When the signal from the transmitter is successfully received by the Temperature
Station, this icon will be switched on. (If not successful, the icon will not be shown
on the LCD). User can therefore easily see whether the last reception was
successful (“ON” icon) or not (“OFF” icon). On the other hand, the short blinking of
the icon shows that signal reception is taken part at that time.
The LCD screen is split into 4 sections:
Section 1 - TIME OR INDOOR TEMPERATURE
• Display of time.
• Display indoor temperature (when the 3 channels are occupied and
SET/CH key is pressed)
58

59
Section 2 - INDOOR TEMPERATURE OR CHANNEL 1 OUTDOOR
TEMPERATURE
• Display of indoor temperature in normal display
• Display Channel 1 outdoor temperature (when the 3 channels are occupied
and SET/CH key is pressed)
Section 3 - OUTDOOR TEMPERATURE
• Display of the Channel 1 outdoor temperature in normal display.
• Display Channel 2 outdoor temperature (when the 3 channels are occupied
and SET/CH key is pressed)
Section 4 - OUTDOOR TEMPERATURE
• Display of the Channel 2 outdoor temperature in normal display.

60
• Display Channel 3 outdoor temperature (when the 3 channels are occupied
and SET/CH key is pressed)
MANUAL SETTING:
12 / 24- HOUR TIME DISPLAY SETTING AND TEMPERATURE UNIT (°C/°F)
SETTING
User may choose to display the time in 12-hour or 24-hour mode:
Note:
When the time display is set as 12-hour mode, the temperature unit will be set to
°F; when the time mode is in 24-hour format, the temperature unit will be set to °C.
1. In normal display mode, press and hold the “SET/ CH” key for about 3
seconds. The "24h" digit will be flashing.
2. Press the “MIN/MAX/+” key to set the desired time display mode.

61
3. Press shortly the “SET/ CH” key to advance to the MANUAL TIME
SETTING.
MANUAL TIME SETTING
User shall manually set the time of the Temperature Station by the following steps:
1. The hour digit of the time display will be flashing.
2. Press the “MIN/MAX/+” key to adjust the hour (press and hold to allow fast
advance). Press “SET/ CH” key to confirm and go to the minute setting.
3. The minute digit will be flashing. Press the “MIN/MAX/+” key to adjust the
minute (press and hold to allow fast advance). Press “SET/ CH” key once
more to return to normal display.
