Teknion Dossier ZJSF Operating and maintenance instructions

Section:
Description: Page No:
Date:
Rev. No: 1
MODESTY PANEL - END POSITION
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
Feb 2023 1 of 4
DOS_003b
dossier Installation Guides
ZJSF, ZJPF, ZJDF, ZJRP, ZJRF, ZJUP, ZJUF, ZJBF, ZJBG, ZJBH, ZJBJ,
ZJNF, ZJNJ, ZJNP, ZJNR, ZJEF, ZJEJ, ZJEP, ZJER
Part and Product Identification
A1 - Modesty Panel
For Customer Support please contact
[email protected]
B - Pedestal x 2
A2 - Modzee Clip (AS111) x 4
C - 1
2" Modular Screw (AS121) x 6
A1
B
B
PEDESTAL DESK WITH
FULL MODESTY END
POSITION (ZJDF)
SHOWN AS EXAMPLE
D - L Bracket (AS079) x Varies
E - #8 Pan Head Wood Screw
(AS031) x 12
D

Section:
Description: Page No:
Date:
SCREWS TO PEDESTAL L-BRACKET INSTALL TO MODESTY
DOS_003b
2 of 4
Feb 2023
MODESTY PANEL - END POSITION
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
dossier Installation Guides
STEP 2: Fasten L Bracket to Modesty Panel using pilot holes for proper location. UseWood
Screws provided
STEP 1: Fasten Modular Screws to pilot holes located on the Pedestal.
C
E
B
D
A1

Section:
Description: Page No:
Date:
ALIGN MODESTY TO GABLE MODESTY PANEL LOCATION
DOS_003b
3 of 4
Feb 2023
MODESTY PANEL - END POSITION
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
dossier Installation Guides
STEP 4: Make sure all Modular Screws are inside of cavity.STEP 3: Line-up screws to bottom end of cavity
A1
A2
C
A1
A2
B
C

Section:
Description: Page No:
Date:
ELEVATE MODESTY PANEL MODESTY PANEL INSTALL
DOS_003b
4 of 4
Feb 2023
MODESTY PANEL - END POSITION
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
dossier Installation Guides
STEP 6: Lower Modesty Panel so that the screws slide to the top of Modzee Clips. Make sure
Top of Modesty Panel is leveled to the top of Gable.
STEP 5: Keep Modesty Panel elevated and insert Pedestal by lining up Modular Screw to
bottom cavities of Modesty Panel.
A1
Align
Keep Elevated
