Teknion Navigate End Cover-Metal Operating and maintenance instructions

Section:
Date: May 2019
SCREENS & GABLES
height-adjustable bench
Installation Guides
Rev. 01
Page: 1 of 4
HABN_223c
Note: Mid Cover with Power Pole Cut-out is
Shown as Example. For Cable Channel
installation procedures, please refer to guide
HABN_223a/223b
Navigate End Cover - Metal (HNBCCEMN), Navigate Mid Cover - Metal (HNBCCMMN)

Section:
Date: May 2019
SCREENS & GABLES
height-adjustable bench
Installation Guides
Page: 2 of 4
HABN_223c
ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY.
1 END COVER, DOUBLE SIDED, HAB A16-7445-X 1
2 MID COVER, DOUBLE SIDED, HAB A16-7446-X 1
Part & Product Identification

Section:
Date: May 2019
SCREENS & GABLES
height-adjustable bench
Installation Guides
Page: 3 of 4
HABN_223c
1
Note: Support Bracket ships with Cable
Channel. For Cable Channel installation
procedures, please refer to guide
HABN_223a/223b
1
PLACE END COVER & BRACKET ON FRAME BAR
STEP 1: Slide Cable Channel Support Bracket into End Cover, making sure holes align. Bring
End Cover and Support Bracket together, and place them on Frame Stretcher Bar
STEP 2: Secure End Cover in place with Support Bracket Screws
SECURE END COVER IN PLACE

Section:
Date: May 2019
SCREENS & GABLES
height-adjustable bench
Installation Guides
Page: 4 of 4
HABN_223c
2
2
2
Note: For Cable Channel
installation procedures, please refer
to guide HABN_223a/223b
PLACE MID COVER ON STRETCHER BARS
STEP 3: Place Metal Mid Cover on top of Stretcher Bars and Cable Channel Support
Brackets.
STEP 4: Use Screws provided with Support Brackets to secure Metal Mid Cover in place.
SECURE MID COVER IN PLACE
