Teknion Leverage User manual

Worksurface Supporting Pedestal Kit (HWP) Part and Product Identification
A - Lyft Filler Panel
(CMFILER) x1
Section:
Description: Page No:
Date:
Rev. No: 0
WORKSURFACE SUPPORTING PEDESTAL KIT
WORKSURFACE SUPPORTS AND ACCESSORIES
May 2020 1 of 4
TLE_357
leverage Installation Guides
B - Lyft Worksurface Support
Bracket
(CMSUPT) x1
C - Lyft Tether
(CMTETHER12) x1
D - #10 x 1
2" Self Tapping Screw
(PHSCRW1021) x13
E - Worksurface Support Bumper
(D06-4027) x2
F - #10 x 1" Quadrex, Pan Washer
Head, Wood Screw
(PHSCRW1020) x2

STEP 2: Fasten the panel to the back of the Pedestal.
STEP 1:Remove the Drawer.
Section:
Description: Page No:
Date:
REMOVE THE DRAWERS ATTACH THE PEDESTAL
TLE_357
2 of 5
May 2020
WORKSURFACE SUPPORT PEDESTAL KIT
WORKSURFACE SUPPORTS AND ACCESSORIES
leverage Installation Guides

Section:
Description: Page No:
Date:
INSTALL THE PEDESTAL FIX THE SUPPORT BRACKET
TLE_357
3 of 5
May 2020
WORKSURFACE SUPPORT PEDESTAL KIT
WORKSURFACE SUPPORTS AND ACCESSORIES
STEP 4: Secure the worksurface support bracket at the top of the Pedestal.STEP 3: Attach the Pedestal to the panel.
leverage Installation Guides
Align holes of
Filler
Panel and
worksurface
Support
Bracket
Use Rail pilot
hole
to drill a
0.188"d
hole through
Ped top
Use Rail pilot
hole to drill a

Section:
Description: Page No:
Date:
LEVEL PEDESTAL
INSTALL RED HOOK
SECURE THE BUMPERS
TLE_357
0 of 4
May 2020
WORKSURFACE SUPPORTING PEDESTAL KIT
WORKSURFACE SUPPORTS AND ACCESSORIES
STEP 6: Engage Rail Hook into horizontal Panel Rail.
STEP 5: Level the Pedestal by turning the leveler screw.
STEP 7: Fix Bumpers on top of the Pedestal using Machine Screws.
leverage Installation Guides

STEP 9: Secure the worksurface using Machine Screws provided.
STEP 8: Fix Lyft Tether at the onto the panel to mount the worksurface.
Section:
Description: Page No:
Date:
INSERT LYFT TETHER ASSEMBLE THE WORKSURFACE
TLE_357
4 of 4
May 2020
WORKSURFACE SUPPORTING PEDESTAL KIT
WORKSURFACE SUPPORTS AND ACCESSORIES
leverage Installation Guides
