Teknion ZNTLCS Operating and maintenance instructions

Start Curved Ledge Table (ZNTLCS), Mid Curved Ledge Table (ZNTLCM), End Curved Ledge Table (ZNTLCE)
Section:
Description: Page No:
Date:
Rev. No: 1
SECTIONAL CURVED LEDGE TABLE
TABLES
May 2019 1 of 33
ZNS_216b
zones Installation Guides
Note: Start, Mid, End Assembly pg 4-20
Start, End Assembly pg 4-5, 21-34
B
A
I
S
F
D
N
Q
H
G
E
F
C
RL

Section:
Description: Page No:
Date:
REFERNCE FOR 60 DEGREE OR 90 DEGREE FRAME ASSEMBLY
May 2019 2 of 33
ZNS_216b
SECTIONAL CURVED LEDGE TABLE
TABLES
START
MIDDLE
END
Note: Reference Frame Assembly for 60 degree or 90 degree frames.
START END
Note: Reference Frame Assembly for 60 degree or 90 degree frames.
zones Installation Guides

Part and Product Identification
Section:
Description: Page No:
Date:
Rev. No:
SECTIONAL CURVED LEDGE TABLE
TABLES
May 2019 3 of 33
ZNS_216b
30 degree
(N02-3961)
60 degree
(N02-3945)
90 degree
(N02-3943)
30 degree
(N02-3960)
60 degree
(N02-3946)
90 degree
(N02-3942)
E- Lower Beam Weldment x qty varies
D - Upper Beam Weldment x qty varies
A - End Worksurface x 1 B - Mid Worksurface x 1 C - Start Worksurface x 1
30 deg End W/S
(C07-2126E) x1
60 deg End W/S
(C07-2123E) x1
90 deg End W/S
(C07-2122E) x1
30 deg Mid W/S
(C07-2126M) x1
30 deg Start W/S
(C07-2126S) x1
60 deg Mid W/S
(C07-2123M) x1
90 deg Mid W/S
(C07-2122M) x1
60 deg Start W/S
(C07-2123S) x1
90 deg Start W/S
(C07-2122S) x1
F - Mid Gable Assembly
(N09-7407) xqty varies
G - End Gable Assembly
(N09-7408) xqty varies
H - End Gable Top Plate
(A16-5423) x2
I - Mid Gable Top Plate
(A16-5400) xqty varies
M - 5/16-18 SHCS
(E01-0911) x2 per
Gable
K - #10 x 0.875
(E07-0077) xqty varies
L - Hook
(A16-5831) xqty varies
O - 1/4-20 x 3/4 Mach Screw
(E01-0484) x9 or 14
T - 1/4-20 x 5/8 Mach Screw
(E01-0098) xvaries
N - Cable Manager Extrusion
(B03-2389\36) x qty varies
P - #8 x 3/4 Wood Screw
(E04-0073) x qty varies
R - Compact Power Bar
x qty varies
S - Power Bar Bracket
xqty varies
J - Split Washer
(E01-1191) x2 per
Gable
Q - Cable Manager Kit
(X09-0049) xqty varies
zones Installation Guides

Section:
Description: Page No:
Date:
ASSEMBLE START FRAME GABLES INVERT AND ASSEMBLE START FRAME
ZNS_216b
4 of 33
May 2019
SECTIONAL CURVED LEDGE TABLE
TABLES
Torque
60 ± 10 lb-in
STEP 1: Fasten End Gable Top Plate to End Gable Assembly with Machine Screws, Fasten
Mid Gable Top Plate to Mid Gable Assembly using Machine Screws
STEP 2: Place End Gable Assemblies upside down and slide Upper and Lower Beam Assembly
onto Gable Assemblies
F
G
O
H
I
H
O
E
D
zones Installation Guides

Section:
Description: Page No:
Date:
SECURE START GABLE ASSEMBLY ASSEMBLE MID GABLE
ZNS_216b
5 of 33
May 2019
SECTIONAL CURVED LEDGE TABLE
TABLES
STEP 3: Fasten Upper and Lower Beam Elements using Socket Headed Cap Screws and Crush
Washers
STEP 4a: Fasten Mid Gable Top Plate to Mid Gable Assembly using Machine Screws
Torque
60 ± 10 lb-in
zones Installation Guides
M
J
M
J
I
O
F

Section:
Description: Page No:
Date:
ASSEMBLE MIDDLE FRAME SECURE MID GABLE
ZNS_216b
6 of 33
May 2019
SECTIONAL CURVED LEDGE TABLE
TABLES
zones Installation Guides
STEP 6a: Fasten Upper and Lower Beam Assemblies to Mid Gable Frame using Crush
Washers and Socket Headed Cap Screws
STEP 5a: Place Mid Gable Assembly upside down and slide Upper and Lower Beam Assembly
onto Mid Gable Assembly
D
E
M
J
M
J

Section:
Description: Page No:
Date:
ASSEMBLE END GABLE ASSEMBLE END FRAME
ZNS_216b
7 of 33
May 2019
SECTIONAL CURVED LEDGE TABLE
TABLES
STEP 8a: Turn End Gable upside down and Slide Upper and Lower Beam Elements onto End
Gable Assembly
STEP 7a: Fasten End Top Plate to End Gable using Machine Screws
Torque
60 ± 10 lb-in
H
O
G
H
O
E
D
zones Installation Guides

Section:
Description: Page No:
Date:
SECURE END FRAME ASSEMBLY ASSEMBLE MIDDLE AND END FRAME
ZNS_216b
8 of 33
May 2019
SECTIONAL CURVED LEDGE TABLE
TABLES
STEP 10a: Slide Middle and End Frames togetherSTEP 9a: Fasten Upper and Lower Beam Assemblies to End Gable Assembly using Crush
Washers and Socket Headed Cap Screws
M
J
J
M
Middle
End
zones Installation Guides

Section:
Description: Page No:
Date:
FASTEN END AND MID GABLE ASSEMBLE START AND MID-END GABLES
ZNS_216b
9 of 33
May 2019
SECTIONAL CURVED LEDGE TABLE
TABLES
zones Installation Guides
STEP 12a: Place Beginning, Middle and End Frames right side up and slide frame assemblies
together
STEP 11a: Fasten Middle and End Gable together using Crush Washers and Socket Headed
Cap Screws
M
J
M
J
Start
Middle-End

Section:
Description: Page No:
Date:
SECURE FULL FRAME ASSEMBLY
May 2019 10 of 33
ZNS_216b
SECTIONAL CURVED LEDGE TABLE
TABLES
zones Installation Guides
STEP 13a: Fasten Gable Assemblies together using Crush Washers and Socket Headed Cap Screws
M
J
M
J
Torque
10 ± 2 lb-ft

Section:
Description: Page No:
Date:
INSTALL HOOKS
May 2019 11 of 33
ZNS_216b
SECTIONAL CURVED LEDGE TABLE
TABLES
zones Installation Guides
STEP 14a: Install Hooks on Top Beam Assembly using Machine Screws and Fasten Mid and End Top Plates to Upper Beam Assemblies using Machine Screws
L
O
T
T
L
O

Section:
Description: Page No:
Date:
ASSEMBLE WORKSURFACES
May 2019 12 of 33
ZNS_216b
SECTIONAL CURVED LEDGE TABLE
TABLES
STEP 15a: Drape Power Bar Cord over Upper Beam Assembly, Place Beginning, Middle and End Worksurfaces on Frame Assembly and fasten using Wood Screws
C
B
A
KR
zones Installation Guides

Section:
Description: Page No:
Date:
TIGHTEN FRAME SCREWS POWER BAR CABLE CLEARANCE
ZNS_216b
13 of 33
May 2019
SECTIONAL CURVED LEDGE TABLE
TABLES
zones Installation Guides
Note: After installing the Worksurface, Tighten the Machine Screws with Torque gun until snug
with a torque setting of 10±2 lb-ft.
Torque
10±2 lb-ft
Note: Sideview
STEP 16a: Ensure Power Bar Cord Clears the Worksurface via the cut out beneath

Section:
Description: Page No:
Date:
INSTALL POWER BAR BRACKET
May 2019 14 of 33
ZNS_216b
SECTIONAL CURVED LEDGE TABLE
TABLES
STEP 17a: Fasten Power bracket using Wood Screws.
S
P
S
P
zones Installation Guides

Section:
Description: Page No:
Date:
INSTALL POWER BAR
May 2019 15 of 33
ZNS_216b
SECTIONAL CURVED LEDGE TABLE
TABLES
zones Installation Guides
STEP 18a: Insert Power Bar into Power Bar Bracket
R

Section:
Description: Page No:
Date:
SECURE POWER BAR REMOVE WIRE CLIPS
ZNS_216b
16 of 33
May 2019
SECTIONAL CURVED LEDGE TABLE
TABLES
STEP 19a: Tighten the Thumb Screws to hold Power Bar into Power Bracket. STEP 20a: Remove Wire Clips from Wire Manager Kit.
Q
zones Installation Guides

Section:
Description: Page No:
Date:
INSTALL WIRE MANAGER
May 2019 17 of 33
ZNS_216b
SECTIONAL CURVED LEDGE TABLE
TABLES
STEP 21a: Fasten Wire Manager Kit beneath Worksurface using wood screws
QP
P
Q
zones Installation Guides

Section:
Description: Page No:
Date:
INSTALL WIRE CLIPS
May 2019 18 of 33
ZNS_216b
SECTIONAL CURVED LEDGE TABLE
TABLES
STEP 22a: Install Wire Clips where required. No Pilot Holes Exist for this step.
P- Clips
Note: Install Wire Clips where required
P-Clips
P
P
zones Installation Guides

Section:
Description: Page No:
Date:
REMOVE TAPE FROM WIRE MANAGER APPLY WIRE MANAGER TO LEG
ZNS_216b
19 of 33
May 2019
SECTIONAL CURVED LEDGE TABLE
TABLES
STEP 24a: Apply Wire Manger to Legs where requiredSTEP 23a: Remove Tap from Wire Manager Extrusion
N
N
zones Installation Guides

Section:
Description: Page No:
Date:
DETAILED WIRE MANGER VIEW RUN POWER CORD
ZNS_216b
20 of 33
May 2019
SECTIONAL CURVED LEDGE TABLE
TABLES
STEP 26a: Run Power Bar Cable Down Gable Assembly Leg using Wire Manager Extrusion
looping any additional cord around Wire Manager Kit
STEP 25a: Install Wire Manager Extrusion as shown above
Flush to Aluminum Leg
.537 ± .125
Press Power Cable into Leg
zones Installation Guides
