Teknion Complements Operating and maintenance instructions

Section:
Date: Sept 2018
INFINTIY SCREENS
complements
Installation Guides
Rev. 0
Page: 1 of 7
COM_554
2.1
2.3
1
2.2
2.4
NOTE: Configuration GXCH422035L
is used as an example.
INFINITY CURVED DESK EDGE SCREEN (GXCH), INFINITY SCREEN ALIGNMENT CLIP (GXCC)

Section:
Date: Sept 2018
INFINTIY SCREENS
complements
Installation Guides
Page: 2 of 7
COM_554
ITEM
NO.
PREVIEW DESCRIPTION
PART
NUMBER
QTY.
1
INFINITY
CURVED DESK
EDGE SCREEN
ASSY.
N03-
2554SL\42\20
\36
1
2. INFINTIY CURVED DESK EDGE SCREEN WIRE BRACKET KIT
2.1
INFINITY
CURVED DESK
EDGE SCREEN
END BRKT,
A16-6023 1
2.2
INFINITY
CURVED DESK
EDGE SCREEN
WIRE BRKT
ASSY.
N03-2592L 1
2.3
FABRIC
SCREEN
MOUNTING
BRKT.
A16-6026L 2
ITEM
NO.
PREVIEW DESCRIPTION
PART
NUMBER
QTY
.
2. INFINTY CURVED DESK EDGE SCREEN WIRE BRACKET KIT
2.4
INFINITY
SCREEN END
COVER
A16-6210 1
2.5
1/4-20 UNC.
NUT HEX
KEPS ZINC
E03-0059 10
2.6
#10 x 0.875" LG.
SCREW,
QUAD.PAN
WASHER
E07-0077 8
3
PLASTIC
SPACER
B10-0521 2
ITEM
NO.
PREVIEW DESCRIPTION
PART
NUMBER
QTY.
2.4
INFINITY
SCREEN END
COVER
A16-6210 1
2.5
1/4-20 UNC.
NUT HEX
KEPS ZINC
E03-0059 10
2.6
#10 x 0.875" LG.
SCREW,
QUAD.PAN
WASHER
E07-0077 8
3
PLASTIC
SPACER
B10-0521 2
4
fromparent+INF
INITY CURVED
DESK EDGE
SCREEN,
W/WIRE
MANAGER,
DISTRICT
MirrorGXCD
_WL
1
4.1
fromparent+INF
INITY CURVED
DESK EDGE
SCREEN ASSY.
MirrorN03-
2554L-X
1
4.1.1
fromparent+INF
INITY CURVED
DESK EDGE
SCREEN
INNER
ELEMENT
MirrorN03-
2552L-X
1
4.1.1.
1
MirrorF03-056
5L-X
1
4.1.1.
2
SCHAETTI
SF1303 EVA
GLUE
TJ02-0092 1
4.1.1.
3
REXTAC
RT6723 HOT
MELT
TJ02-0099 1
4.1.2
MirrorC07-
2563L-X
1
4.1.3
MirrorC07-
3735L-X
1
4.1.4
fromparent+FAB
RIC SCREEN
MOUNTING
PLATE SUB
ASSY. ZONES
MirrorN03-
2470 1
4.1.4.
1
MirrorA16-56
00
1
4.1.4.
2
MirrorE03-03
45
2
4.1.5
fromparent+FAB
RIC SCREEN
MOUNTING
PLATE SUB
ASSY. ZONES
MirrorN03-
24701 1
4.1.5.
1
MirrorA16-56
00
1
4.1.5.
2
MirrorE03-03
45
2
4.1.6
fromparent+FAB
RIC SCREEN
MOUNTING
PLATE SUB
ASSY. ZONES
MirrorN03-
24702 1
4.1.6.
1
MirrorA16-56
00
1
4.1.6.
2
MirrorE03-03
45
2
4.1.7
fromparent+FAB
RIC SCREEN
MOUNTING
PLATE SUB
ASSY. ZONES
MirrorN03-
24703 1
4.1.7.
1
MirrorA16-56
00
1
4.1.7.
2
MirrorE03-03
45
2
4.1.8
fromparent+INF
INITY CURVED
DESK EDGE
SCREEN
OUTER
ELEMENT
MirrorN03-
2553X-X
1
4.1.8.
1
MirrorF03-056
6X-X
1
4.1.8.
2
SCHAETTI
SF1303 EVA
GLUE
TJ02-0092 1
4.1.8.
3
REXTAC
RT6723 HOT
MELT
TJ02-0099 1
4.1.9
3M DP-604NS
DUOPAK
ADHESIVE
TJ02-0111 1
4.1.10
3M FASTBOND
2000 BLUE
(WATER
BASED)
ADHESIVE
TJ02-0080 1
4.1.11
3M FASTBOND
2000 BLUE
(WATER
BASED)
ADHESIVE
APPLICATOR
TJ02-0081 1
4.1.12
MirrorE03-
0930 8
4.2
fromparent+INF
INITY CURVED
DESK EDGE
SCREEN WIRE
BRKT. KIT
MirrorX06-
0498L-X
1
4.2.1
MirrorA16-
6023L
1
4.2.2
fromparent+INF
INITY CURVED
DESK EDGE
SCREEN WIRE
BRKT ASSY.
MirrorN03-
2592L-X
1
4.2.2.
1
MirrorA16-60
24L-X
1
4.2.2.
2
MirrorE03-20
39
2
4.2.3
MirrorA16-
6026L
2
4.2.4
MirrorA16-
6210 1
4.2.5
MirrorE03-
0059 10
4.2.6
MirrorE07-
0077 8
4.3
MirrorB10-
0521 2
5
INFINITY
SCREEN
ALIGNMENT
CLIP
GXCC 1
5.1
INFINITY
ALIGNMENT
CLIP
A25-0641 2
5.2
8-32 X 3/4 SOC
SET SCREW
CUP POINT
BARE
E03-0923 1
Part & Product Identification (GXCH)

Section:
Date: Sept 2018
INFINTIY SCREENS
complements
Installation Guides
Page: 3 of 7
COM_554
ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY.
1
INFINITY
ALIGNMENT CLIP
A25-0641 2
2
8-32 X 3/4 SOC SET
SCREW CUP
POINT BARE
E03-0923 1
Part & Product Identification (GXCC)

Section:
Date: Sept 2018
INFINTIY SCREENS
complements
Installation Guides
Page: 4 of 7
COM_554
2.1 2.2
2.3
2.4
NOTE: When installing the Brackets to the screens,
the Torque applied to the Fasteners should be
controlled between 14 to 18 Lb.In.
2.5
INSTALL BRACKET
STEP 1: Install the End Bracket and Fabric Screen Mounting Bracket onto to the studs in the
Screen assembly.
STEP 2: Secure the Brackets onto the Fabric Screen Screen Assembly by rotating the hex nut
clockwise.
When installing the Brackets to the Screen, the Torque applied to the Fastener
should be controlled between 14 to 18 Lb.In.
SECURE BRACKET

Section:
Date: Sept 2018
INFINTIY SCREENS
complements
Installation Guides
Page: 5 of 7
COM_554
PILOT HOLES
NOTE: For illustration Purpose the
Lefthand Side Leg Support is Hidden.
STEP 3: Align and Mount the Whole Assembly onto the designated Pilot Holes on the Worksurface using the Wood Screws as indicated. Ensure the Brackets are Parallel to the Worsurface.
MOUNT SCREEN ASSEMBLY

Section:
Date: Sept 2018
INFINTIY SCREENS
complements
Installation Guides
Page: 6 of 7
COM_554
TILTING INWARDS
BACK WOOD SCREW
3
3
NOTE: For illustration Purpose the
Lefthand Side Leg Support is Hidden.
TILTING OUTWARDS
3
3
FRONT WOOD SCREW
NOTE: For illustration Purpose the
Lefthand Side Leg Support is Hidden.
3
BACK WOOD SCREW
3
FRONT WOOD SCREW
INSTALL PLASTIC SPACER (OPTIONAL)
STEP 4: If the Screen is Tilting Inwards Loosen the Back Wood Screw a little and place the
Plastic Spacer under the Worksurface around the Back Wood Screw on the Bracket at the
back to Level the Screen.
STEP 5: If the Screen is Tilting Outwards Loosen the Front Wood Screw a little and place
the Plastic Spacer under the Worksurface around the Front Wood Screw on the Bracket at
the back to Level the Screen.
INSTALL PLASTIC SPACER (OPTIONAL)

Section:
Date: Sept 2018
INFINTIY SCREENS
complements
Installation Guides
Page: 7 of 7
COM_554
1
2
ASSEMBLE AND MOUNT CLIP
STEP 1: Assemble the Set Screw to the Alignment Clip by rotating Clockwise. Tighten the
part loosely and push it between the screens.
STEP 2: Tighten the alignment clip onto the set screw by rotating it Clockwise.
TIGHTEN CLIP
