Teknion Projek Owner's manual

SEAT HEIGHT ADJUSTMENT SEAT DEPTH ADJUSTMENT
3D ARM PIVOT ADJUSTMENT ARM HEIGHT ADJUSTMENT
BACK TILT ADJUSTMENT TILT TENSION ADJUSTMENT
Seat height can be adjusted by
pulling outward on the button
below the seat on the right hand
side. When this button pulled, the
weight of the body will cause the
seat to lower, and releasing it stops
the seat at the desired height.
Pulling outward on the button
with no weight on the seat allows
it to rise.
o adjust the seat depth, pull
outward on the button below the
seat on the left-hand side and
simultaneously lift your weight
from the seat while sliding the seat
forward or backward. Release
button to lock the seat in place.
o pivot the arm cap, depress the
auto safety lock button on the
outside of the armrest and pivot
180˚ degrees to desired position.
Release the button to lock in place.
o adjust the arm height, press the
button below either arm rest to
raise or lower it to the desired
position. Release the button to lock
in place.
urning the grip found under the
left side of the seat limits the back
tilt travel and locks the back. ravel
is limited on 3 positions with back
lock in the upright position.
Fine tune the weight balanced
tension by rotating the dial located
below the seat centre to suit
personal preference.
projek adjustment features & instruction

W rning
ipping or collapsing can result in serious injury. o prevent product failure and possible injury:
• his chair has been designed and tested for users weighing up to 300 lbs
• Frequently inspect the chair for visible cracks and damages, tighten all screws, bolts, adjustable knobs and parts
• Do not use the chair if damaged or unstable – immediately remove it from service
• his chair is equipped with casters intended for use on carpeted surfaces. Use of these casters on hard surfaces could result in unexpected rolling
and tipping. Casters designed for use on hard surfaces are available. If in doubt, see your dealer for appropriate selection
• Do not stand on or use the chair as a step ladder
• Failure to follow these warnings could result in serious injury
LUMBAR HEIGHT-ADJUSTMENT ARM WIDTH ADJUSTMENT
STOOL FOOT RING HEIGHT
he lumbar height-adjustment
knobs can be found on the back
where the Inner Frame connects to
the Lumbar Element.
he height of the lumbar support
can be adjusted by sliding them up
and down.
o adjust the width of each arm,
turn the dial clockwise to release
the arm lock. Slide the arm inward
or outward to the desired position.
ighten the knob to lock the arm
in place.
o raise or lower the stool’s foot
ring, turn the foot ring’s knob
counter clockwise to release the foot
ring and adjust the ring until you
reach the desired level. urn the
knob clockwise to lock in place.
projek adjustment features & instruction
