YCanvas Office Landscape®Support Panel Installation
and Disassembly for Recycling Instructions
Safety Glass
Parts Included:
Tools Required:
Mounting Plate
Hanger Clip Plug (2)
Tapping Screw(5)
Pan Head Tapping
Screw(6)
Flat Head Tapping
Screw(3)
Safety Clip
Support Panel
AF
B
DE
HJK
CG
Machine Screw (2)
Shared Support Panel
Power Driver #2 Phillips Bit 1/8” Drill Bit
Hardware Pack
Hardware Pack
Note: Determine whether right or left hand Support Panel
is needed for installation. Right hand Support Panel is
shown throughout these instructions. For left hand
installation, ip Hanger and Safety Clip 180 degrees
before installing onto Panel support.

Z
2
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b6wbj rev B.
1. Install Hanger Clip(C) onto Support
Panel(A) with 5 Tapping Screws(D). Be
sure to start screws with smallest hole
in Bracket rst. This will ensure Panel
will t correctly on frame.
2. Attach Safety Clip(E) onto panel with
one Machine Screw(F) using slotted
hole in Clip. Do not tighten!
3. Push Plugs(G) into holes on oppo-
site side of Panel.
End Support:
A
F
C
C
D
EG
Smallest Hole

Z
3
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b6wbj rev B.
4. Insert Teeth on Hanger Clip into Slots in frame. Push down on Support to fully
engage Teeth.
5. Lift up on Safety Clip to align hole in Clip with hole in Support.
6. Install Machine Screw(F). Tighten both Screws.
7. If Shared Support is to be used between Work
Surfaces, do the following: Install Mounting
Plate(H) onto Shared Support(B) with 3 Flat
Head Tapping Screws(J). Important! Make sure
heads of screws are ush with top of plate.
Continue installing Shared Support onto wall as
described in steps 1 - 6.
D
J
H
B
Hanger Clip
Slot
Teeth
Safety Clip
Safety Clip
Machine Screw
Shared Support:

Z
4
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b6wbj rev B.
8. Relocate Spacer Screw and Shoulder Screw into proper Pilot Holes in Work
Surface if necessary.
9. Install Work Surface by inserting Shoulder Screw into Keyhole Slot in Support
Panel.
10. Push Work Surface back until Spacer engages into hole in Support Panel.
Work Surface
Work Surface
Keyhole Slot
Hole
Spacer
Shoulder Screw
End Support:

Z
5
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b6wbj rev B.
Shared Support:
11. Align front and back holes in Shared Support Mounting Plate with Pilot Holes
in Work Surfaces.
12. Install 4 front and back Pan Head Tapping Screws(K).
13. Using Mounting Plate as template, drill 2 pilot holes for middle screws.
14. Install 2 Pan Head Tapping Screws(K).
K
K
Pilot Hole
Pilot Hole

Z
6
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b6wbj rev B.
Disassembly and Recycling:
Materials Identication and Segregation:
Where possible, plastic components are marked with ASTM recycling codes. Use
these codes to identify material type for recycling. Non marked components should
be treated as mixed plastic. Ferrous metals can be identied using a small magnet
for recycling. Non-ferrous metals should be separated and recycled separately.
To disassemble product, reverse steps 14 through 1 and also do the following:
