Telstra MF821 User manual

TelstraMF821UserManualv1.1Page1of22
TELSTRA MF821
4G USB DATA MODEM
USER MANUAL
Copyright © 2012. All rights reserved.
No part of this publication may be excerpted, reproduced,
translated or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to
make modifications on print errors or update specifications without
prior notice.
Version 1.1February 2012

TelstraMF821UserManualv1.0 Page2of22
CHECK YOUR SYSTEM REQUIREMENTS
Check you have a spare USB port (USB 1.0 or 2.0)
You need to be running Windows 7 / XP / Vista for a PC or OS X
10.5.11 and above for a Mac
The recommended minimum system requirements are:
CPU 1GHz Pentium or above
Hard Disk At least 50MB free space
RAM 512M or above
Display 800 x 600 minimum
You need to have Administrator rights to install and run the software
We suggest you switch off your anti-virus software before installing
the USB modem. In some cases protection software can prevent
automatic installation. It is possible to start the installation process
manually by clicking the Autorun icon when it appears.

TelstraMF821UserManualv1.0 Page3of22
GET TO KNOW YOUR USB MODEM

TelstraMF821UserManualv1.0 Page4of22
INSERT YOUR SIM CARD
1. Slide the top cover to access the SIM and memory slots.
2. Insert your USIM card carefully as shown.
3.If you want to add a memory card you can do it now. Your
USB modem supports up to 32GB microSD™ memory.
4. Close the back cover.
Handy hint
Remember to keep your plastic SIM card holder. It has a
record of your phone number and a PIN number which you
may need later.

TelstraMF821UserManualv1.0 Page5of22
INSERT THE MODEM INTO YOUR COMPUTER
The installation and management software is pre-loaded
onto your USB modem. Simply insert your modem into
your computer and follow the instructions on-screen.
You’ll be up and connected in about 5 minutes.
The USB modem is a Plug and Play device. Once inserted
your system will automatically detect the new hardware
and start to install the software. Be patient as it may take
some time for your computer to recognise the modem.
If nothing happens your system configuration may be
preventing Autorun.
Handy Hint
Double click the Telstra icon to start the software
installation.

TelstraMF821UserManualv1.0 Page6of22
Windows users: Select Open folder to view files, then
double click the Telstra icon to start the software
installation:
MAC Users: Double click the Telstra icon from your
desktop:

TelstraMF821UserManualv1.0 Page7of22
The installation method shown below is for Windows 7.
Other systems will follow a similar but not necessarily
identical installation process:

TelstraMF821UserManualv1.0 Page8of22
Choose ‘I confirm….’, and then click Next to continue

TelstraMF821UserManualv1.0 Page9of22
Press Next to accept the default folder location, or press
Browse to define your own path.

TelstraMF821UserManualv1.0 Page10of22
Click next then wait a few seconds for the installation to
proceed…Press Finish when complete:

TelstraMF821UserManualv1.0 Page11of22
CONNECT TO THE INTERNET
After installation the software interface will launch
automatically. Your modem will continue installing for a
couple of minutes…
You’ll be ready to go when you see the Connect Now
button.
Press Connect Now to get on line

TelstraMF821UserManualv1.0 Page12of22
LED indicators Modem Status
Red Offline. Not registered on the network
Green solid Registered on the LTE network
Green blinking
Active data transfer on the LTE network
Bluesolid Registered on the 2G / 3G network
Blue blinking
Active data transfer on 2G / 3G network
The installation will create a new shortcut on your desktop
and a new program listing under Start-Programs
You may have to reboot your PC or MAC after installation is
complete
If you have problems with the installation please contact
your supplier or see our website, www.zte.com.au/ for
more assistance and FAQ’s
If you can’t connect to the internet check your SIM card is
inserted correctly, contact your service provider and check
your account is active.

TelstraMF821UserManualv1.0 Page13of22
USING YOUR USB MODEM
Press Connect Now to connect to the internet
Launch your browser or other software
When you have finished your internet or email connection
remember to return to the software interface and press
Disconnect to end your session
If the software has been minimized then double click the
small icon on the task bar to re-open the application
window
The modem is locked to Telstra. If you use a SIM card from
another provider you may not be able to connect to the
network. Consult Telstra for more details or to unlock your
device.
Handy Hint
After the computer wakes from hibernation or standby
mode you may need to remove and insert the modem

TelstraMF821UserManualv1.0 Page14of22
microSD™ MEMORY CARD
If you use a microSD™ memory card in your modem your
computer will display a removable disk drive. You can use
the modem as an external drive to store and transfer files.
microSD™ cards supported to 2GB are FAT 16 format.
microSDHC™ cards supported to 32GB are FAT 32 format.
If you want to remove the modem please use the Safe
Removal of Hardware to stop the removable disk first.
EXTERNAL ANTENNA PORT
Only use the correct antenna as recommended by the
manufacturer. The antenna port type is TS9. Insert and
remove the connection carefully. Do not pull on the cable
to remove the connection.
HELP
Click Help to access the system help and FAQ’s.

TelstraMF821UserManualv1.0 Page15of22
TROUBLESHOOTING
If you have any problems with your connection or modem
please consult the manual and check this section. If the
problem still exists contact your service provider or check
our website for more details at www.zte.com.au
Problem Possible Causes Suggested Solution
The user
interface doesn’t
start after the
modem is
plugged in.
PC
configuration is
not correct.
(No autorun)
Start the program
manually by going
Start > Program Files
or use the shortcut
on the desktop.
The antenna is
at the wrong
angle or
position.
Adjust the angle and
position of the USB
modem.
You have no
network
coverage.
Try moving location
until you get good
reception.
The modem has
no signal.
SIM card
requires a PIN
number
Remove your SIM.
Insert into a mobile
handset and unlock
the PIN function.

TelstraMF821UserManualv1.0 Page16of22
Problem Possible Causes Suggested Solution
Data
connection
failed.
You have no
network
coverage.
Try moving location
until you get good
reception.
The modem
cannot connect
to the internet
when overseas
You don’t have
international
roaming
enabled on your
plan.
Consult your service
provider before you
go overseas to
enable roaming.
No warning
tone
The PC
soundcard is
disabled or on
low volume
Check the audio card
and adjust the
volume.
The microSD™
card cannot be
read or is not
found.
Re-insert the
microSD™ card.
The maximum
capacity is
32GB SDHC
card
Try another
microSD™ card and
make sure the
capacity and format
is correct.

TelstraMF821UserManualv1.0 Page17of22
SOFTWARE REMOVAL
If you wish to uninstall the application please follow the
procedures below:
PC
Start > Control Panel > Add or Remove Programs (or
equivalent) > Select Telstra Mobile Broadband Manager >
Click Remove or Uninstall
Follow the prompts and press Yes to continue.
MAC
With the Telstra Pre-Paid Broadband application running
select:
Telstra Pre-Paid Broadband > Uninstall
Follow the prompts to continue.

TelstraMF821UserManualv1.0 Page18of22
PRECAUTIONS AND SAFETY INFORMATION
Some electronic devices are susceptible to
electromagnetic interference. The modem is a
transmitting device and may cause interference to
sensitive electronic equipment such as audio systems,
vehicle systems and medical equipment. Please consult
the manufacturer of the other device before using the
modem.
Operating of laptop or desktop PCs with the modem may
interfere with medical devices like hearing aids and
pacemakers. Please keep the modem more than 20
centimetres away from such medical devices. Turn the
modem off if necessary. Consult a physician or the
manufacturer of the medical device before using the
modem near such devices.
Be aware of the regulations when using the modem at
places such as oil warehouses or chemical factories,
where there are explosive gases or explosive products
being processed. Turn off your modem as instructed.
Don’t touch the antenna area unnecessarily whilst
connected. This can affect your modem performance and
reduce the signal quality.
Store the modem out of the reach of children. The modem
may cause injury or get damaged.

TelstraMF821UserManualv1.0 Page19of22
The modem contains sensitive electronic circuitry. Do not
expose the modem to any liquids, high temperatures or
shock.
Only use original accessories or accessories that are
authorized by the manufacturer. Using unauthorized
accessories may affect your modem’s performance,
damage your modem and violate related national
regulations.
Avoid using the modem in areas that emit electromagnetic
waves or in enclosed metallic structures eg lifts.
The modem is not waterproof. Please keep it dry and store
it in a cool, dry place.
Don’t use the modem immediately after a sudden
temperature change eg from an air conditioned
environment to high temperature and humidity outside. In
such cases there could be condensing moisture inside the
modem which can cause internal damage. Unplug the
modem and leave it for 30 minutes before use.
Always handle the modem with care. Be careful not to
drop or bend the modem.
There are no user serviceable parts inside the modem.
Unauthorised dismantling or repair will void the warranty.

TelstraMF821UserManualv1.0 Page20of22
RF SAFETY INFORMATION
The USB modem has an internal antenna. For optimum
performance with minimum power consumption do not
shield the device or cover with any object. Covering the
antenna affects signal quality and may cause the modem
to operate at a higher power level than needed.
RADIO FREQUENCY ENERGY
The USB modem is a low-power radio transmitter and
receiver. When switched on it intermittently transmits
radio frequency (RF) energy (radio waves). The transmit
power level is optimized for best performance and
automatically reduces when there is good quality
reception. Maximum power is only used at the edge of
network coverage so under most circumstances the power
output is very low. Under poor network conditions the
modem transmits at a higher power level and may get hot.
