Texas Instruments DAC1220EVM User manual


 
August 2004
User’s Guide
SBAU102
Data Acquisition Products

IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications,
enhancements, improvements, and other changes to its products and services at any time and to discontinue
any product or service without notice. Customers should obtain the latest relevant information before placing
orders and should verify that such information is current and complete. All products are sold subject to TI’s terms
and conditions of sale supplied at the time of order acknowledgment.
TI warrants performance of its hardware products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI
deems necessary to support this warranty. Except where mandated by government requirements, testing of all
parameters of each product is not necessarily performed.
TI assumes no liability for applications assistance or customer product design. Customers are responsible for
their products and applications using TI components. To minimize the risks associated with customer products
and applications, customers should provide adequate design and operating safeguards.
TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right,
copyright, mask work right, or other TI intellectual property right relating to any combination, machine, or process
in which TI products or services are used. Information published by TI regarding third-party products or services
does not constitute a license from TI to use such products or services or a warranty or endorsement thereof.
Use of such information may require a license from a third party under the patents or other intellectual property
of the third party, or a license from TI under the patents or other intellectual property of TI.
Reproduction of information in TI data books or data sheets is permissible only if reproduction is without
alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction
of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for
such altered documentation.
Resale of TI products or services with statements different from or beyond the parameters stated by TI for that
product or service voids all express and any implied warranties for the associated TI product or service and
is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.
Following are URLs where you can obtain information on other Texas Instruments products and application
solutions:
Products Applications
Amplifiers amplifier.ti.com Audio www.ti.com/audio
Data Converters dataconverter.ti.com Automotive www.ti.com/automotive
DSP dsp.ti.com Broadband www.ti.com/broadband
Interface interface.ti.com Digital Control www.ti.com/digitalcontrol
Logic logic.ti.com Military www.ti.com/military
Power Mgmt power.ti.com Optical Networking www.ti.com/opticalnetwork
Microcontrollers microcontroller.ti.com Security www.ti.com/security
Telephony www.ti.com/telephony
Video & Imaging www.ti.com/video
Wireless www.ti.com/wireless
Mailing Address: Texas Instruments
Post Office Box 655303 Dallas, Texas 75265
Copyright 2004, Texas Instruments Incorporated

EVM IMPORTANT NOTICE
Texas Instruments (TI) provides the enclosed product(s) under the following conditions:
This evaluation kit being sold by TI is intended for use for ENGINEERING DEVELOPMENT OR EVALUATION
PURPOSES ONLY and is not considered by TI to be fit for commercial use. As such, the goods being provided
may not be complete in terms of required design-, marketing-, and/or manufacturing-related protective
considerations, including product safety measures typically found in the end product incorporating the goods.
As a prototype, this product does not fall within the scope of the European Union directive on electromagnetic
compatibility and therefore may not meet the technical requirements of the directive.
Should this evaluation kit not meet the specifications indicated in the EVM User’s Guide, the kit may be returned
within 30 days from the date of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE
WARRANTY MADE BY SELLER TO BUYER AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED,
IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE.
The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user
indemnifies TI from all claims arising from the handling or use of the goods. Please be aware that the products
received may not be regulatory compliant or agency certified (FCC, UL, CE, etc.). Due to the open construction
of the product, it is the user’s responsibility to take any and all appropriate precautions with regard to electrostatic
discharge.
EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL BE LIABLE
TO THE OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
TI currently deals with a variety of customers for products, and therefore our arrangement with the user is not
exclusive.
TI assumes no liability for applications assistance, customer product design, software performance, or
infringement of patents or services described herein.
Please read the EVM User’s Guide and, specifically, the EVM Warnings and Restrictions notice in the EVM
User’s Guide prior to handling the product. This notice contains important safety information about temperatures
and voltages. For further safety concerns, please contact the TI application engineer.
Persons handling the product must have electronics training and observe good laboratory practice standards.
No license is granted under any patent right or other intellectual property right of TI covering or relating to any
machine, process, or combination in which such TI products or services might be or are used.
Mailing Address:
Texas Instruments
Post Office Box 655303
Dallas, Texas 75265
Copyright 2004, Texas Instruments Incorporated

EVM WARNINGS AND RESTRICTIONS
It is important to operate this EVM within the specified input and output ranges of 0V to 5V that
are described in the EVM User’s Guide.
Exceeding the specified input range may cause unexpected operation and/or irreversible
damage to the EVM. If there are questions concerning the input range, please contact a TI
field representative prior to connecting the input power.
Applying loads outside of the specified output range may result in unintended operation and/or
possible permanent damage to the EVM. Please consult the EVM User’s Guide prior to
connecting any load to the EVM output. If there is uncertainty as to the load specification,
please contact a TI field representative.
Mailing Address:
Texas Instruments
Post Office Box 655303
Dallas, Texas 75265
Copyright 2004, Texas Instruments Incorporated

Contents
iii
Contents
Preface

About This Manual
This manual describes the DAC1220EVM evaluation fixture and how to use
it. Throughout this document, the abbreviation EVM and the term evaluation
module are synonymous with the DAC1220EVM.
Related Documentation From Texas Instruments
The following documents provide information regarding Texas Instruments
integrated circuits used in the assembly of the DAC1220EVM. These docu-
ments are available from the TI web site, and are current at the time of the
writing of this User’s Guide. To obtain a copy of the following TI documents,
visit our website at http://www.ti.com/ or call the Texas Instruments Litera-
ture Response Center at (800) 477−8924 or the Product Information Center
at (972) 644−5580. When ordering, identify the document by both title and
literature number.
Data sheet Literature number
DAC1220 Data Sheet SBAS273
REF1004 Data Sheet SBVS002
OPA335 Data Sheet SBOS245
OPA350 Data Sheet SBOS099
SN74LVC1G80 Data Sheet SCES221
Additional Documentation
The following document provides information regarding selected non-TI
components, which may be used in the testing of the DAC1220EVM. This
document is available from the corresponding manufacturer.
Document Manufacturer
HPA449 User’s Guide SoftBaugh, http://www.softbaugh.com

Contents
iv
If You Need Assistance
If you have questions regarding either the use of this evaluation module or
the information contained in the accompanying documentation, please con-
tact the Texas Instruments Product Information Center at (972) 644−5580
or visit the TI web site at www.ti.com.
FCC Warning
This equipment is intended for use in a laboratory test environment only. It
generates, uses, and can radiate radio frequency energy and has not been
tested for compliance with the limits of computing devices pursuant to sub-
part J of part 15 of FCC rules, which are designed to provide reasonable
protection against radio frequency interference. Operation of this equip-
ment in other environments may cause interference with radio communica-
tions, in which case the user at his own expense will be required to take
whatever measures may be required to correct this interference.
Trademarks
SPI is a registered trademark of Motorola, Inc.
I2C is a registered trademark of Royal Philips Electronics B.V., The Nether-
lands.
All other trademarks are the property of their respective owners.

Contents
v

1 Overview 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Introduction 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Built-In Accessories 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Connectors 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Controls 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5 Setting Up 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Circuit Description 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 DAC1220 and Ancillary Components 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.1 Filter Capacitors 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.2 Power 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Clock Oscillator 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Voltage Reference 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Output Buffer Amplifier 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.5 Layout 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Usage 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 I/O Connectors and Testpoints 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.1 J1: Analog Connector 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.2 J2: Serial Connector 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.3 J4: Power Connector 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.4 Testpoints 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Jumpers 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.1 J3: DAC1220 Supply Current Measurement Jumpers 3-6. . . . . . . . . . . . . . . . . . . . . . .
3.2.2 J5: DAC1220 Analog-Digital Ground Shorting Jumpers 3-6. . . . . . . . . . . . . . . . . . . . .
3.3 Switches 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.1 S1: Reference Input Select 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.2 S2: System Clock Select 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Schematic and Layout 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Board Layout 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 Bill of Materials 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
vi

3−1. DAC1220EVM Connectors and Testpoints 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3−2. Analog Connector Pinout for the DAC1220EVM 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3−3. Serial Connector Pinout for the DAC1220EVM 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3−4. Power Connector Pinout for the DAC1220EVM 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3−5. DAC1220EVM Jumpers 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3−6. Jumper Block J3 on the DAC1220EVM 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3−7. DAC1220EVM Switches 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−1. DAC1220EVM Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−2. DAC1220EVM—Layer 1 (Top) 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−3. DAC1220EVM—Layer 2 (Bottom) 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−1. Analog Connector Pin Descriptions for the DAC1220EVM 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3−2. Serial Connector Pin Descriptions for the DAC1220EVM 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3−3. Power Connector Pin Descriptions for the DAC1220EVM 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−1. Bill of Materials 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1
Overview

The DAC1220EVM is an evaluation fixture designed for the DAC1220 20-bit
delta-sigma (∆Σ) digital-to-analog data converter. The EVM is designed for
prototyping and evaluation, and includes a reference circuit, an oscillator circuit,
and an output buffer amplifier. Use of the output buffer amplifier is optional.
Topic Page
1.1 Introduction 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Built-In Accessories 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Connectors 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Controls 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5 Setting Up 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1

Introduction
1-2
1.1 Introduction
Many data converter evaluation fixtures contain a computer interface or a
microcontroller, but the DAC1220EVM contains only the DAC1220 device and
a few supporting components. All DAC1220 pins are accessible through
various pins on the analog and digital connectors of the DAC1220EVM.
The DAC1220EVM is designed using a simple card format developed by TI.
This simple, consistent design makes the DAC1220EVM very easy to connect
to your own prototype system. One can even think of the DAC1220EVM as an
alternate package for the DAC1220—one much larger than the device itself,
but also much easier to wire up by hand on a test bench.
The DAC1220EVM can be plugged directly into suitable motherboards, such
as the HPA449 MSP430 microcontroller development system from Soft-
Baugh, Inc. (http://www.softbaugh.com). See also TI’s web site for example
code using the DAC1220EVM with the HPA449.
The DAC1220EVM, together with the HPA449 and the appropriate software,
also forms a complete evaluation system for verifying the DAC1220 perfor-
mance. See the Texas Instruments web site for additional information and soft-
ware.
1.2 Built-In Accessories
The DAC1220EVM includes a system clock generator and a low-noise voltage
reference. Using either of these components is optional; you can select an ex-
ternal system clock and/or an external reference, using the slide switches on
the EVM.
The +2.5V reference circuit is based on a REF1004-2.5 voltage reference. Its
noise performance is sufficient to allow the DAC1220 to perform at its lowest
noise level.
The on-board clock circuit uses a 2.4576MHz crystal. A switch selects be-
tween the crystal and an external clock signal applied to the TOUT pin of the
serial connector, J2.

Connectors
1-3
Overview
1.3 Connectors
The DAC1220 device on the DAC1220EVM is connected through three head-
ers: the analog connector, the serial connector, and the power connector. Pin-
outs and locations of each connector are given in Chapter 3 of this user’s
guide.
The analog connector (J1) carries analog I/O. The DAC1220 output appears
in buffered and unbuffered versions on this connector. An external voltage
reference can be applied to the VREF pins.
The serial connector, J2, carries the DAC1220 serial digital interface, an
optional external system clock signal, and an I2Cconnection to the on-board
serial EEPROM.
The power connector (J4) carries the power supplies. The DAC1220EVM
requires a +5V supply. The board is designed using a single ground net con-
nected to DGND. An AGND pin is also provided and can be connected to
DGND using jumper J5.
The DAC1220 uses separate supplies for its analog and digital sections. A
jumper is inserted in each supply line. These jumpers allow the current of each
supply to be measured independently.
1.4 Controls
The DAC1220EVM is configured using two slide switches. (See Figure 3−7 for
the location of these switches.)
Switch S2 selects the system clock source for the DAC1220. You can select
from the 2.4576MHz crystal or an external clock.
Switch S2 selects the reference input. One position selects the external refer-
ence input pins on the analog connector (J1); the other position selects the on-
board +2.5V reference.

Setting Up
1-4
1.5 Setting Up
The way that one configures the DAC1220EVM depends on how it will be
used. Consequently, there is no one single procedure to follow for setting up
the DAC1220EVM.
Nevertheless, it is useful to remember the following points when you are con-
figuring the board:
-Make certain that you have a +5V power supply connected to the proper
pins on the power connector, J4.
-If you are not measuring the DAC1220 supply current, remember to place
shunts on jumper block J3. Without these shunts, the DAC1220 will not be
powered on, and will not work at all.
-Unless you are using two entirely separate power supplies for analog and
digital sources, place a shorting block on jumper J2. This jumper connects
the analog and digital supplies together, which is the usual method of oper-
ating the DAC1220.
-Check the system clock switch. If the switch is set to EXT, and you have
not connected a clock signal to the external clock input pin on J2 (TOUT),
the DAC1220 will not operate.
