Texas Instruments EVMK2E User manual

EVMK2E Evaluation Module
Quick Start Guide
©2014 Texas Instruments Incorporated

©2014 Texas Instruments Incorporated
EVMK2E Evaluation Module
A
No Functionality
On board XDS200 USB
JTAG(MIPI-60) connector for SoC
COM1 : SoC UART Console
COM2 : BMC UART Console
BMC Reset : Resets the microcontroller
and will reset the entire board
Dip switch for boot configuration :
1111 : No Boot mode/JTAG DSP Little Endian
0010 : NOR SPI ARM Master Boot
USB3 PORT 1(Device and HOST Modes)
USB3 PORT 0(HOST only)
USB control of both SOC COM1 & BMC COM2
F
B
1 press: safe shutdown of SOC;
2 presses within 0.5sec: warm reset;
3 presses within 0.5sec: full reset;
4 presses within 0.5sec: cancel reset
G
C H
DI
J
K
E

http://www.silabs.com/Support%20Documents/Software/Linux_3.x.x_VCP_Driver_Source.zip
Two boot procedures are described below, one for Uboot and one
for CCS.
1) Uboot Steps:
2
1
Ensure EVM configuration
switches are set as shown for
NOR SPI Boot.
3
Connect the USB mini-B
cable to J1
©2014 Texas Instruments Incorporated
Insert pendrive and load USB
For Windows User:
For Linux User:
COM drive by executing the
program\drivers\
CP210xVCPInstaller_x86
program\drivers\
Please download driver from any of below link as per Linux kernel version on PC.
Compile the driver and install it.
For 64-bit systems execute the
http://www.silabs.com/Support%20Documents/Software/Linux_2.6.x_VCP_Driver_Source.zip

4
Open Tera Term,
select COM port, configure
settings, as shown in image.
This serial port settings of
Tera Term is shown as an
example. It is not mandatory
to use only Tera Term as
a serial terminal
©2014 Texas Instruments Incorporated
5
Insert DC-in cable to apply
12V power.
6
Hit any key to stop
On SoC serial port console
a display will be seen,
as shown in image.
auto-boot when prompted.
EVM is now ready for
Uboot applications.
MCSDK Downlink Page:
http://software-dl.ti.com/sdoemb/sdoemb_public_sw/mcsdk/latest/index_FDS.html

2) CCS Steps:
1
Update or install CCS
(V5.5.0.00077 or later) from
MCSDK download page.
2
Ensure EVM configuration
switch are set as shown for
No Boot/JTAG DSP Little
Endian Boot mode.
3
Connect the USB mini-B
cable to XDS200.
44
Insert DCInsert DC--in cable to applyin cable to apply
12V power.12V power.
55
LaunchLaunch CCSCCS.. After CCS isAfter CCS is
opened,opened, EVM is now reaEVM is now readydy
for use.for use.
©2014 Texas Instruments Incorporated

©2014 Texas Instruments Incorporated
Getting Started:
Please see the ‘Getting Started’ chapter in the
MCSDK User Guide for hardware and
software setup:
http://processors.wiki.ti.com/index.php/MCSDK_
User_Guide_for_KeyStone_II.
Important Notes when handling the EVM:
Plug in all the cables before powering
ON the EVM to ensure proper
grounding.
Do not unnecessarily flex the boards,
while inserting cables. Excessive
flexing can break the PCB traces.
Use proper ESD procedures when
handling the EVM.
Warning: Some components on the
EVM may be too hot to touch with your
bare hand when power is on.
Online Documentation
TI device product page
http://www.ti.com/product/66ak2e05
Multicore SDK
http://www.ti.com/tool/bioslinuxmcsdk
http://processors.wiki.ti.com/index.php/M
CSDK_User_Guide_for_KeyStone_II
CCS v5
http://processors.wiki.ti.com/index.php/Categ
ory:Code_Composer _Studio_v5
C663X EVM Information:
https://www.einfochips.com/tI-66ak2e-evm
This link contains:
Hardware & Software details
User Guide
Technical Reference Manual
EVMK2E EVM Support:
Please write to [e-mail]
for technical queries related to this EVM.
eInfochips Address :
eInfochips Limited.
303,Parishram Building,5/B Rashmi Society
Mithakhali Six Road,Navarangpura.
Ahmedabad- 380009.
Gujarat, INDIA.
Tel : [phone].
Fax :[phone].
http://www.einfochips.com/
